| Domestic |
|
12/20/221444Z
|
!GYL 12/007 GYL OBST TOWER LGT (ASR 1024928) 444716.00N0935430.00W (7.6NM ENE GYL) 1299.9FT (290.0FT AGL) U/S 2212201444-2312312359
|
| FDC |
|
10/25/231613Z
|
!FDC 3/0952 GYL ODP GLENCOE MUNI, GLENCOE, MN.
TAKEOFF MINIMUMS AND (OBSTACLE) DEPARTURE PROCEDURES ORIG...
TAKEOFF OBSTACLE NOTES: RWY 31, TEMPORARY VEHICLE EQUIPMENT, BEGINNING 530FT FROM DER, BEGINNING 304FT LEFT OF CENTERLINE, 20 AGL/UP TO 1016 MSL (2022-AGL-11864/65/67/68/69/70/71, 11882/83/84/85-NRA). ALL OTHER DATA REMAINS AS PUBLISHED. 2310251613-2405161613EST
|
|
8/7/231949Z
|
!FDC 3/9716 GYL PART 1 OF 3 ODP GLENCOE MUNI, GLENCOE, MN.
TAKEOFF MINIMUMS AND (OBSTACLE) DEPARTURE PROCEDURES ORIG...
TAKEOFF OBSTACLE NOTES: RWY 13: LIGHT POLES, ELECTRICAL SYSTEM,
TERRAINS BEGINNING 9 FT FROM DER, 16 FT RIGHT OF CENTERLINE, UP TO
2 FT AGL/993 FT MSL.
LIGHT POLES BEGINNING 9 FT FROM DER, 16 FT LEFT OF CENTERLINE, UP
TO 2 FT AGL/993 FT MSL.
TERRAINS BEGINNING 65 FT FROM DER, 345 FT RIGHT OF CENTERLINE, UP
TO 995 FT MSL.
TREE 253 FT FROM DER, 256 FT RIGHT OF CENTERLINE, 1001 FT MSL.
TREES BEGINNING 348 FT FROM DER, 392 FT RIGHT OF CENTERLINE, UP TO
1041 FT MSL. RWY 31: TERRAIN 6 FT FROM DER, 212 FT RIGHT OF
CENTERLINE, 993 FT MSL.
LIGHT POLES BEGINNING 10 FT FROM DER, 16 FT RIGHT OF CENTERLINE, UP
TO 2 FT AGL/994 FT MSL.
LIGHT POLE, ELECTRICAL SYSTEM, SIGN, TERRAIN BEGINNING 10 FT FROM
DER, 17 FT LEFT OF CENTERLINE, UP TO 2 FT AGL/994 FT MSL.
TREES, LIGHT POLE, TERRAIN BEGINNING 32 FT FROM DER, 76 FT RIGHT OF
CENTERLINE, UP TO 61 FT AGL/1053 FT MSL.
TREES, POLES BEGINNING 189 FT FROM DER, 400 FT RIGHT OF CENTERLINE,
UP TO 68 FT AGL/1057 FT MSL.
1074 FT MSL. 2308071949-2508071949EST
END PART 1 OF 3
!FDC 3/9716 GYL PART 2 OF 3 ODP GLENCOE MUNI, GLENCOE, MN.
BUILDING 294 FT FROM DER, 574 FT LEFT OF CENTERLINE, 16 FT AGL/1011
FT MSL.
BUILDING, TRAVERSE WAY BEGINNING 392 FT FROM DER, 399 FT LEFT OF
CENTERLINE, UP TO 39 FT AGL/1032 FT MSL.
POLES, TRAVERSE WAY, BUILDING BEGINNING 563 FT FROM DER, 460 FT
LEFT OF CENTERLINE, UP TO 55 FT AGL/1052 FT MSL.
TREES BEGINNING 757 FT FROM DER, 486 FT RIGHT OF CENTERLINE, UP TO
1075 FT MSL.
TREES BEGINNING 810 FT FROM DER, 461 FT RIGHT OF CENTERLINE, UP TO
1077 FT MSL.
TREES BEGINNING 842 FT FROM DER, 393 FT RIGHT OF CENTERLINE, UP TO
1078 FT MSL.
TREE 1078 FT FROM DER, 675 FT RIGHT OF CENTERLINE, 1080 FT MSL.
TREE 1097 FT FROM DER, 664 FT RIGHT OF CENTERLINE, 1084 FT MSL.
TREES BEGINNING 1177 FT FROM DER, 22 FT RIGHT OF CENTERLINE, UP TO
1085 FT MSL.
TREE 2856 FT FROM DER, 37 FT LEFT OF CENTERLINE, 1067 FT MSL.
TREE 2877 FT FROM DER, 215 FT LEFT OF CENTERLINE, 1071 FT MSL.
TREES BEGINNING 2883 FT FROM DER, 51 FT LEFT OF CENTERLINE, UP TO
1073 FT MSL.
1074 FT MSL. 2308071949-2508071949EST
END PART 2 OF 3
!FDC 3/9716 GYL PART 3 OF 3 ODP GLENCOE MUNI, GLENCOE, MN.
TREES BEGINNING 2949 FT FROM DER, 36 FT LEFT OF CENTERLINE, UP TO
1074 FT MSL. 2308071949-2508071949EST
END PART 3 OF 3
|
|
7/26/231736Z
|
!FDC 3/3007 GYL IAP GLENCOE MUNI, GLENCOE, MN.
RNAV (GPS) RWY 13, ORIG-A...
LNAV/VNAV DA 1360/HAT 367 ALL CATS.
2307261736-2507261736EST
|
|
7/25/231441Z
|
!FDC 3/2003 GYL IAP GLENCOE MUNI, GLENCOE, MN.
RNAV (GPS) RWY 31, AMDT 1...
NOTE: VGSI AND RNAV GLIDEPATH NOT COINCIDENT (VGSI 3.00/TCH 28)..
2307251441-2507251441EST
|
