3/10/25 1630Z | 3/10/27 1630Z | | !FDC 5/0895 IKW PART 1 OF 6 ODP JACK BARSTOW, MIDLAND, MI.
TAKEOFF MINIMUMS AND (OBSTACLE) DEPARTURE PROCEDURES ORIG...
TAKE-OFF MINIMUMS: RWY 24: 300-2 1/2 OR STANDARD WITH MINIMUM CLIMB
OF 205 FT/NM TO 1100. TAKEOFF OBSTACLE NOTES: NOTE: RWY 6: LIGHT
POLES 39 FT FROM DER, 113 FT LEFT OF CENTERLINE, 3 FT AGL/637 FT
MSL.
LIGHT POLES 39 FT FROM DER, 113 FT RIGHT OF CENTERLINE, 4 FT
AGL/636 FT MSL.
TREE 59 FT FROM DER, 485 FT RIGHT OF CENTERLINE, 672 FT MSL.
TREE 305 FT FROM DER, 481 FT RIGHT OF CENTERLINE, 704 FT MSL.
TREE, VEGETATION BEGINNING 375 FT FROM DER, 227 FT RIGHT OF
CENTERLINE, UP TO 728 FT MSL.
TREES BEGINNING 896 FT FROM DER, 48 FT LEFT OF CENTERLINE, UP TO
675 FT MSL.
TREES BEGINNING 1003 FT FROM DER, 420 FT LEFT OF CENTERLINE, UP TO
682 FT MSL.
TREES BEGINNING 1145 FT FROM DER, 80 FT RIGHT OF CENTERLINE, UP TO
735 FT MSL.
TREES BEGINNING 1296 FT FROM DER, 69 FT LEFT OF CENTERLINE, UP TO
717 FT MSL.
TREES BEGINNING 1454 FT FROM DER, 54 FT LEFT OF CENTERLINE, UP TO
742 FT MSL.. 2503101630-2703101630EST
END PART 1 OF 6
!FDC 5/0895 IKW PART 2 OF 6 ODP JACK BARSTOW, MIDLAND, MI.
734 FT MSL.
TREES BEGINNING 1576 FT FROM DER, 19 FT LEFT OF CENTERLINE, UP TO
753 FT MSL. TAKEOFF OBSTACLE NOTES: NOTE: RWY 18: BUILDING 19 FT
FROM DER, 425 FT LEFT OF CENTERLINE, 14 FT AGL/634 FT MSL.
LIGHT POLES 40 FT FROM DER, 113 FT RIGHT OF CENTERLINE, 4 FT
AGL/623 FT MSL.
TREE 147 FT FROM DER, 467 FT RIGHT OF CENTERLINE, 678 FT MSL.
BUILDING 177 FT FROM DER, 421 FT LEFT OF CENTERLINE, 23 FT AGL/642
FT MSL.
TREE 235 FT FROM DER, 481 FT RIGHT OF CENTERLINE, 704 FT MSL.
TREES BEGINNING 322 FT FROM DER, 405 FT LEFT OF CENTERLINE, UP TO
684 FT MSL.
TREE, POLE BEGINNING 363 FT FROM DER, 87 FT RIGHT OF CENTERLINE, UP
TO 716 FT MSL.
TREES BEGINNING 417 FT FROM DER, 490 FT LEFT OF CENTERLINE, UP TO
698 FT MSL.
TREES BEGINNING 1206 FT FROM DER, 88 FT LEFT OF CENTERLINE, UP TO
701 FT MSL.
TREE 1780 FT FROM DER, 250 FT LEFT OF CENTERLINE, 703 FT MSL.
TREE 1945 FT FROM DER, 56 FT LEFT OF CENTERLINE, 706 FT MSL.
742 FT MSL.. 2503101630-2703101630EST
END PART 2 OF 6
!FDC 5/0895 IKW PART 3 OF 6 ODP JACK BARSTOW, MIDLAND, MI.
TREES BEGINNING 2317 FT FROM DER, 946 FT RIGHT OF CENTERLINE, UP TO
718 FT MSL.
TREE 2923 FT FROM DER, 1168 FT RIGHT OF CENTERLINE, 721 FT MSL.
TREE 3793 FT FROM DER, 30 FT RIGHT OF CENTERLINE, 726 FT MSL.
TAKEOFF OBSTACLE NOTES: NOTE: RWY 24: SIGN, LIGHT POLES BEGINNING
14 FT FROM DER, 112 FT LEFT OF CENTERLINE, UP TO 3 FT AGL/622 FT
MSL.
POLE, LIGHT POLES BEGINNING 16 FT FROM DER, 113 FT RIGHT OF
CENTERLINE, UP TO 11 FT AGL/631 FT MSL.
TREES BEGINNING 268 FT FROM DER, 112 FT RIGHT OF CENTERLINE, UP TO
679 FT MSL.
TREE 426 FT FROM DER, 455 FT LEFT OF CENTERLINE, 678 FT MSL.
TREES BEGINNING 483 FT FROM DER, 326 FT LEFT OF CENTERLINE, UP TO
704 FT MSL.
TREES BEGINNING 736 FT FROM DER, 6 FT LEFT OF CENTERLINE, UP TO 713
FT MSL.
TREES BEGINNING 854 FT FROM DER, 513 FT RIGHT OF CENTERLINE, UP TO
707 FT MSL.
TREES BEGINNING 982 FT FROM DER, 40 FT RIGHT OF CENTERLINE, UP TO
710 FT MSL.
742 FT MSL.. 2503101630-2703101630EST
END PART 3 OF 6
!FDC 5/0895 IKW PART 4 OF 6 ODP JACK BARSTOW, MIDLAND, MI.
TREES BEGINNING 2136 FT FROM DER, 41 FT RIGHT OF CENTERLINE, UP TO
716 FT MSL.
TREES BEGINNING 2154 FT FROM DER, 27 FT LEFT OF CENTERLINE, UP TO
716 FT MSL.
TREES BEGINNING 2317 FT FROM DER, 150 FT RIGHT OF CENTERLINE, UP TO
718 FT MSL.
TREES BEGINNING 2624 FT FROM DER, 104 FT RIGHT OF CENTERLINE, UP TO
727 FT MSL.
TREE 2729 FT FROM DER, 816 FT LEFT OF CENTERLINE, 717 FT MSL.
TREES BEGINNING 2760 FT FROM DER, 109 FT LEFT OF CENTERLINE, UP TO
718 FT MSL.
TREE 2935 FT FROM DER, 570 FT RIGHT OF CENTERLINE, 737 FT MSL.
TREES BEGINNING 3238 FT FROM DER, 45 FT LEFT OF CENTERLINE, UP TO
730 FT MSL.
TOWER 1.9 NM FROM DER, 3248 FT LEFT OF CENTERLINE, 293 FT AGL/921
FT MSL.
TAKEOFF OBSTACLE NOTES: NOTE: RWY 36: TREE 33 FT FROM DER, 375 FT
LEFT OF CENTERLINE, 666 FT MSL.
TREES BEGINNING 194 FT FROM DER, 384 FT RIGHT OF CENTERLINE, UP TO
685 FT MSL.
742 FT MSL.. 2503101630-2703101630EST
END PART 4 OF 6
!FDC 5/0895 IKW PART 5 OF 6 ODP JACK BARSTOW, MIDLAND, MI.
TREES BEGINNING 234 FT FROM DER, 358 FT LEFT OF CENTERLINE, UP TO
705 FT MSL.
TREES BEGINNING 382 FT FROM DER, 359 FT RIGHT OF CENTERLINE, UP TO
699 FT MSL.
TREES BEGINNING 795 FT FROM DER, 424 FT RIGHT OF CENTERLINE, UP TO
707 FT MSL.
TREES BEGINNING 902 FT FROM DER, 371 FT LEFT OF CENTERLINE, UP TO
714 FT MSL.
TREES BEGINNING 952 FT FROM DER, 352 FT LEFT OF CENTERLINE, UP TO
724 FT MSL.
TREES BEGINNING 1095 FT FROM DER, 164 FT RIGHT OF CENTERLINE, UP TO
708 FT MSL.
TREES BEGINNING 1309 FT FROM DER, 272 FT RIGHT OF CENTERLINE, UP TO
711 FT MSL.
TREES BEGINNING 1469 FT FROM DER, 230 FT RIGHT OF CENTERLINE, UP TO
727 FT MSL.
TREE 1473 FT FROM DER, 420 FT RIGHT OF CENTERLINE, 730 FT MSL.
TREES BEGINNING 1550 FT FROM DER, 288 FT RIGHT OF CENTERLINE, UP TO
731 FT MSL.
TREES BEGINNING 1717 FT FROM DER, 532 FT RIGHT OF CENTERLINE, UP TO
742 FT MSL.. 2503101630-2703101630EST
END PART 5 OF 6
!FDC 5/0895 IKW PART 6 OF 6 ODP JACK BARSTOW, MIDLAND, MI.
741 FT MSL.
TREES BEGINNING 1916 FT FROM DER, 638 FT RIGHT OF CENTERLINE, UP TO
742 FT MSL.. 2503101630-2703101630EST
END PART 6 OF 6
|
