1/27/25 1452Z | 1/27/27 1452Z | | !FDC 5/7040 IWI PART 1 OF 4 ODP WISCASSET, WISCASSET, ME.
TAKEOFF MINIMUMS AND (OBSTACLE) DEPARTURE PROCEDURES AMDT 2...
TAKEOFF OBSTACLE NOTES: RWY 7: NAVAID 29 FT FROM DER, 116 FT LEFT
OF CENTERLINE, 6 FT AGL/59 FT MSL.
TREE 79 FT FROM DER, 470 FT LEFT OF CENTERLINE, 127 FT MSL.
TREES, POLE BEGINNING 130 FT FROM DER, 7 FT LEFT OF CENTERLINE, UP
TO 129 FT MSL.
NAVAID 245 FT FROM DER, 386 FT RIGHT OF CENTERLINE, 19 FT AGL/71 FT
MSL.
TREES BEGINNING 512 FT FROM DER, 347 FT RIGHT OF CENTERLINE, UP TO
104 FT MSL.
TREES BEGINNING 936 FT FROM DER, 449 FT RIGHT OF CENTERLINE, UP TO
105 FT MSL.
TREE 1023 FT FROM DER, 457 FT RIGHT OF CENTERLINE, 111 FT MSL.
TREES BEGINNING 1033 FT FROM DER, 340 FT RIGHT OF CENTERLINE, UP TO
113 FT MSL.
TREES BEGINNING 1446 FT FROM DER, 39 FT RIGHT OF CENTERLINE, UP TO
114 FT MSL.
TREES BEGINNING 1624 FT FROM DER, 76 FT LEFT OF CENTERLINE, UP TO
131 FT MSL.
TREES BEGINNING 1729 FT FROM DER, 165 FT RIGHT OF CENTERLINE, UP TO
TO 215 FT MSL. 2501271452-2701271452EST
END PART 1 OF 4
!FDC 5/7040 IWI PART 2 OF 4 ODP WISCASSET, WISCASSET, ME.
121 FT MSL.
TREE 1831 FT FROM DER, 328 FT RIGHT OF CENTERLINE, 123 FT MSL.
TREE 1844 FT FROM DER, 518 FT RIGHT OF CENTERLINE, 126 FT MSL.
TREES BEGINNING 1871 FT FROM DER, 161 FT RIGHT OF CENTERLINE, UP TO
146 FT MSL.
TREE 2175 FT FROM DER, 678 FT RIGHT OF CENTERLINE, 149 FT MSL.
TREES BEGINNING 2216 FT FROM DER, 91 FT RIGHT OF CENTERLINE, UP TO
156 FT MSL.
TRANSMISSION LINE, TREE BEGINNING 3463 FT FROM DER, 166 FT RIGHT OF
CENTERLINE, UP TO 123 FT AGL/175 FT MSL.
TREE 3471 FT FROM DER, 24 FT LEFT OF CENTERLINE, 144 FT MSL.
TRANSMISSION LINES BEGINNING 3689 FT FROM DER, 446 FT RIGHT OF
CENTERLINE, UP TO 141 FT AGL/205 FT MSL.
TRANSMISSION LINE, TREES BEGINNING 3982 FT FROM DER, 433 FT RIGHT
OF CENTERLINE, UP TO 142 FT AGL/206 FT MSL.
TRANSMISSION LINES BEGINNING 4258 FT FROM DER, 268 FT LEFT OF
CENTERLINE, UP TO 135 FT AGL/194 FT MSL.
TREES BEGINNING 4746 FT FROM DER, 1143 FT LEFT OF CENTERLINE, UP TO
197 FT MSL.
TREES BEGINNING 1.2 NM FROM DER, 1171 FT RIGHT OF CENTERLINE, UP TO
TO 215 FT MSL. 2501271452-2701271452EST
END PART 2 OF 4
!FDC 5/7040 IWI PART 3 OF 4 ODP WISCASSET, WISCASSET, ME.
267 FT MSL.
TREE 1.4 NM FROM DER, 844 FT RIGHT OF CENTERLINE, 282 FT MSL. RWY
25: TREES BEGINNING 26 FT FROM DER, 315 FT LEFT OF CENTERLINE, UP
TO 117 FT MSL.
TREES BEGINNING 74 FT FROM DER, 36 FT RIGHT OF CENTERLINE, UP TO
111 FT MSL.
TREES, BUILDING BEGINNING 199 FT FROM DER, 9 FT LEFT OF CENTERLINE,
UP TO 134 FT MSL.
TREES BEGINNING 794 FT FROM DER, 28 FT RIGHT OF CENTERLINE, UP TO
115 FT MSL.
TREE 1779 FT FROM DER, 913 FT RIGHT OF CENTERLINE, 128 FT MSL.
TREE 1930 FT FROM DER, 944 FT RIGHT OF CENTERLINE, 132 FT MSL.
TREE 2298 FT FROM DER, 897 FT RIGHT OF CENTERLINE, 136 FT MSL.
TREE 2500 FT FROM DER, 1163 FT RIGHT OF CENTERLINE, 149 FT MSL.
TREES BEGINNING 2579 FT FROM DER, 745 FT RIGHT OF CENTERLINE, UP TO
158 FT MSL.
TREES BEGINNING 3126 FT FROM DER, 1261 FT RIGHT OF CENTERLINE, UP
TO 168 FT MSL.
TREES BEGINNING 3288 FT FROM DER, 810 FT RIGHT OF CENTERLINE, UP TO
170 FT MSL.
TO 215 FT MSL. 2501271452-2701271452EST
END PART 3 OF 4
!FDC 5/7040 IWI PART 4 OF 4 ODP WISCASSET, WISCASSET, ME.
TREE 3397 FT FROM DER, 1231 FT RIGHT OF CENTERLINE, 174 FT MSL.
TREE 5054 FT FROM DER, 1746 FT RIGHT OF CENTERLINE, 205 FT MSL.
TREES BEGINNING 5126 FT FROM DER, 1392 FT RIGHT OF CENTERLINE, UP
TO 208 FT MSL.
TREES BEGINNING 5250 FT FROM DER, 1607 FT RIGHT OF CENTERLINE, UP
TO 215 FT MSL. 2501271452-2701271452EST
END PART 4 OF 4
|
