KJAX
ICAO KJAXIATA JAXLocal JAX
JACKSONVILLE INTL
PublicPUB

9 miles N of JACKSONVILLE, FL, US
View on Map
LiveATC.net: Live Air Traffic - From Their Headsets to You
Status
Operational
Coordinates
30° 29' 39"N 81° 41' 16"W
Elevation
30' MSL
Pattern Alt
1030' MSL
Mag Variation
7°W
Declination
6°W
Fuel
JET A, 100LL
FSS
GAINESVILLE (GNV)
Sectional
JACKSONVILLE
ARTCC
JACKSONVILLE (ZJX)
Data Effective
9/3/26-10/1/26
KJAX VFR
2:56 PM EDT
Broken 25,000'
Scattered 3,900'
10sm
90°F
73°F
29.98"Hg
Calm
AO2 SLP154 CB DSNT W T03220228 $
METAR KJAX 121856Z 10SM SCT039 BKN250 32/23 A2998 RMK AO2 SLP154 CB DSNT W T03220228 $
+ Add Your Business

KJAX FBOs

Promote Listing
Signature Aviation
ASRI: 132.0
Phone: (904) 741-2201
No Rating Available
0 Reviews (Read | Sign In To Write)
Independent
As of 9/10
 100LL JET A JET A (FSII) MOGAS UL94
Self Serve
Full Serve 6.91 9.08
Fuel Notes
Prices include tax
Promote Listing
Sheltair
ASRI: 130.8
Phone: (904) 741-0904
No Rating Available
0 Reviews (Read | Sign In To Write)
Avfuel
As of 9/8
 100LL JET A JET A (FSII) MOGAS UL94
Self Serve
Full Serve 7.14 8.76 8.84
Fuel Notes
Prices include tax

KJAX Aircraft Service & Maintenance

Promote Listing
Precision Airparts Support Services
Phone: (904) 258-3443
No Rating Available
0 Reviews (Read | Sign In To Write)
Promote Listing
Andromeda Systems Inc.
Phone: (904) 637-2029
No Rating Available
0 Reviews (Read | Sign In To Write)

KJAX Other Aviation Services

Promote Listing
Amphenol CIT
Phone: (904) 829-5600
No Rating Available
0 Reviews (Read | Sign In To Write)
X

Send Message to Airport Company
Enter your information and message below.

Your Information

Processing

Weather and Advisory

Digital ATIS 125.85
ASOS 125.85
(904) 549-9655

Common

UNICOM 122.95

Clearance

Clearance Delivery 119.5

Ground

JACKSONVILLE GROUND 121.9

Tower

JACKSONVILLE TOWER 118.3

Arrival

ALCRN STAR 127.0
HOTAR STAR 119.0
270-090
HOTAR STAR 124.9
091-180
HOTAR STAR 127.0
270-090
HOTAR STAR 127.775
181-269
LUNNI STAR 119.0
270-090
LUNNI STAR 124.9
091-180
LUNNI STAR 127.0
270-090
LUNNI STAR 127.775
181-269
MARQO STAR 119.0
270-090
MARQO STAR 124.9
091-180
MARQO STAR 127.0
270-090
MARQO STAR 127.775
181-269
OHDEA STAR 119.0
270-090
OHDEA STAR 124.9
091-180
OHDEA STAR 127.0
270-090
OHDEA STAR 127.775
181-269
POGIE STAR 127.775
QUBEN STAR 119.0
270-090
QUBEN STAR 124.9
091-180
QUBEN STAR 127.0
270-090
QUBEN STAR 127.775
181-269
TEBOW STAR 119.0
270-090
TEBOW STAR 124.9
091-180
TEBOW STAR 127.0
270-090
TEBOW STAR 127.775
181-269

Approach

JACKSONVILLE APPROACH 119.0
Initial Contact
JACKSONVILLE APPROACH 121.3
ABV 6000 FT
JACKSONVILLE APPROACH 124.9
091-180 5000 FT & BLW
JACKSONVILLE APPROACH 127.0
270-090
JACKSONVILLE APPROACH 127.775
181-269
JACKSONVILLE APPROACH 132.775
091-180 ABV 5000 FT
JACKSONVILLE APPROACH 119.0
Secondary - 270-090

Departure

ARNEY DP 127.0
CROSB DP 127.0
EXBOX DP 124.9
JACKSONVILLE DEPARTURE 119.0
Initial Contact
JACKSONVILLE DEPARTURE 121.3
ABV 6000 FT
JACKSONVILLE DEPARTURE 124.9
091-180 5000 FT & BLW
JACKSONVILLE DEPARTURE 127.0
270-090
JACKSONVILLE DEPARTURE 127.775
181-269
JACKSONVILLE DEPARTURE 132.775
091-180 ABV 5000 FT
JACKSONVILLE DP 127.0
JETIN DP 127.0
SAWGY DP 124.9
JACKSONVILLE DEPARTURE 119.0
Secondary - 270-090

Emergency

Emergency 121.5

Other

CLASS C 124.9
091-180 5000 FT & BLW
CLASS C 127.0
270-090
CLASS C 127.775
181-269
CLASS C 132.775
091-180 ABV 5000 FT
CLASS C/S 119.0
Secondary - 270-090

Terminal Area Forecast

KJAX
Sat, 9/12 1:37 PM EDT
Sat, 9/12 2:00 PM EDT - Sun, 9/13 2:00 PM EDT
VFR
2:00 PM EDT - 6:00 PM EDT
Thunderstorm in vicinity
Broken 25,000'
Broken 4,000'
Scattered 2,500'
6sm
200° 7kts
MVFR
Temporary 2:00 PM EDT - 6:00 PM EDT
Thunderstorm and Rain
Broken 2,500'
3sm
VRB° 15kts
Gusts 25kts
MVFR
Temporary 6:00 PM EDT - 8:00 PM EDT
Thunderstorm and Rain
Broken 2,500'
4sm
Calm
VFR
6:00 PM EDT - 9:00 PM EDT
Showers and Rain and Mist and Thunderstorm in vicinity
Overcast 8,000'
Scattered 3,000'
6sm
130° 7kts
VFR
9:00 PM EDT - 2:00 AM EDT
Showers in vicinity
Overcast 20,000'
Scattered 10,000'
Few 3,000'
6sm
170° 4kts
VFR
2:00 AM EDT - 10:00 AM EDT
Broken 15,000'
Scattered 400'
6sm
Calm
VFR
10:00 AM EDT - 2:00 PM EDT
Broken 25,000'
Broken 8,000'
Scattered 2,000'
6sm
290° 6kts
TAF KJAX 121737Z 1218/1318 20007KT P6SM VCTS SCT025CB BKN040 BKN250
   TEMPO 1218/1222 VRB15G25KT 3SM TSRA BKN025CB
   FM122200 13007KT 6SM SHRA BR VCTS SCT030CB OVC080
   TEMPO 1222/1224 4SM TSRA BKN025CB
   FM130100 17004KT P6SM VCSH FEW030 SCT100 OVC200
   FM130600 00000KT P6SM SCT004 BKN150
   FM131400 29006KT P6SM SCT020 BKN080 BKN250
KJAX
EffectiveExpiresCategoryNOTAM
Domestic
9/17/26
1200Z
9/17/26
2100Z
Runway!JAX 09/018 JAX RWY 14/32 CLSD 2609171200-2609172100
9/14/26
1200Z
9/17/26
2100Z
!JAX 09/019 JAX TWY C CLSD 2609141200-2609172100
9/14/26
1200Z
9/14/26
2100Z
Runway!JAX 09/017 JAX RWY 08/26 CLSD 2609141200-2609142100
9/14/26
1200Z
9/14/26
2100Z
!JAX 09/016 JAX NAV ILS RWY 26 U/S 2609141200-2609142100
9/14/26
1200Z
9/14/26
2100Z
!JAX 09/015 JAX NAV ILS RWY 08 U/S 2609141200-2609142100
9/2/26
1642Z
10/31/26
1700Z
!JAX 09/001 JAX TWY J BTN TWY W AND AIR CARRIER RAMP CLSD 2609021642-2610311700
8/31/26
1854Z
9/30/26
2100Z
!JAX 08/058 JAX APRON SOUTHWEST AIR CARRIER RAMP DIRECTION MARKINGS REMOVED 2608311854-2609302100
8/31/26
1801Z
11/29/26
1901Z
!JAX 08/057 JAX OBST TOWER LGT (ASR 1210177) 303705.70N0813937.80W (7.6NM NE JAX) 308.7FT (295.9FT AGL) U/S 2608311801-2611291901
8/31/26
1647Z
9/30/26
2100Z
Runway!JAX 08/056 JAX RWY 26 BAK-14 ARST SYSTEM U/S 2608311647-2609302100
8/31/26
1333Z
12/31/26
2200Z
!JAX 08/055 JAX OBST CRANE (ASN 2024-ASO-15074-NRA) 302914N0814046W (0.6NM SE JAX) 148FT (125FT AGL) FLAGGED AND LGTD 2608311333-2612312200
8/26/26
1515Z
11/24/26
1615Z
!JAX 08/042 JAX OBST TOWER LGT (ASR 1028649) 302650.20N0814303.00W (3.2NM SSW JAX) 279.9FT (259.8FT AGL) U/S 2608261515-2611241615
8/7/26
1741Z
!JAX 08/011 JAX NAV DINNS LOM NDB U/S 2608071741-2802252111EST
7/30/26
0957Z
10/28/26
0957Z
!JAX 07/067 JAX OBST TOWER LGT (ASR 1028617) 302757.00N0813531.10W (5.2NM ESE JAX) 305.1FT (289.0FT AGL) U/S 2607300957-2610280957
7/29/26
1834Z
12/31/26
2200Z
!JAX 07/065 JAX OBST CRANE (ASN 2026-ASO-4226-NRA) 302924N0814209W (0.8NM WSW JAX) 224FT (200FT AGL) FLAGGED AND LGTD 2607291834-2612312200
7/28/26
1238Z
10/31/26
1200Z
!JAX 07/064 JAX APRON WEST AIR CARRIER RAMP BTN TWY J AND TWY P CLSD 2607281238-2610311200
7/18/26
1239Z
10/16/26
1239Z
!JAX 07/055 JAX OBST TOWER LGT (ASR 1000462) 303742.50N0813933.10W (8.2NM NE JAX) 288.1FT (267.1FT AGL) U/S 2607181239-2610161239
7/13/26
1928Z
9/13/26
2100Z
!JAX 07/041 JAX TWY V CLSD 2607131928-2609132100
6/26/26
1124Z
!JAX 06/049 JAX NAV ILS RWY 26 OM U/S 2606261124-2706042000EST
6/20/26
1215Z
9/18/26
1215Z
!JAX 06/037 JAX OBST TOWER LGT (ASR 1029358) 303715.20N0813809.10W (8.1NM NNE JAX) 325.1FT (303.1FT AGL) U/S 2606201215-2609181215
1/20/26
0502Z
12/31/26
0500Z
!JAX 01/036 JAX OBST CRANE (ASN UNKNOWN) 302930N0814123W (0.7NM S APCH END RWY 08)
154FT (130FT AGL) FLAGGED AND LGTD 2601200502-2612310500
11/6/25
0256Z
11/4/26
0459Z
!JAX 11/017 JAX OBST CRANE (ASN 2024-ASO-5714-NRA) 302932N0814108W (0.2NM SE JAX) 279FT (250FT AGL) FLAGGED AND LGTD 2511060256-2611040459
11/6/25
0255Z
11/4/26
0459Z
!JAX 11/016 JAX OBST CRANE (ASN 2024-ASO-5713-NRA) 302928N0814109W (0.2NM SSE JAX) 279FT (250FT AGL) FLAGGED AND LGTD 2511060255-2611040459
11/6/25
0255Z
11/4/26
0459Z
!JAX 11/015 JAX OBST CRANE (ASN 2024-ASO-5718-NRA) 302934N0814117W (0.1NM SSW JAX) 279FT (250FT AGL) FLAGGED AND LGTD 2511060255-2611040459
11/6/25
0254Z
11/4/26
0459Z
!JAX 11/014 JAX OBST CRANE (ASN 2024-ASO-5717-NRA) 302934N0814119W (0.1NM SSW JAX) 279FT (250FT AGL) FLAGGED AND LGTD 2511060254-2611040459
11/6/25
0253Z
11/4/26
0459Z
!JAX 11/013 JAX OBST CRANE (ASN 2024-ASO-5716-NRA) 302930N0814119W (0.1NM SSW JAX) 279FT (250FT AGL) FLAGGED AND LGTD 2511060253-2611040459
11/6/25
0252Z
11/4/26
0459Z
!JAX 11/012 JAX OBST CRANE (ASN 2024-ASO-5715-NRA) 302929N0814119W (0.2NM SSW JAX) 279FT (250FT AGL) FLAGGED AND LGTD 2511060252-2611040459
FDC
8/31/26
1447Z
!FDC 6/9385 JAX IAP JACKSONVILLE INTL, JACKSONVILLE, FL.
RNAV (GPS) Z RWY 32, AMDT 3A...
LNAV MDA 460/HAT 436 ALL CATS, VIS CATS C/D 1 1/4. TEMPORARY CRANE 148 MSL 3351FT N OF RWY 32 (2024-ASO-15074-NRA).
2608311447-2701151447EST
7/27/26
1500Z
!FDC 6/8944 JAX IAP JACKSONVILLE INTL, JACKSONVILLE, FL.
RNAV (GPS) Z RWY 14, AMDT 2E...
RNAV (GPS) Z RWY 32, AMDT 3A...
RNAV (GPS) Z RWY 8, AMDT 2E...
CIRCLING MDA 640/HAA 610 ALL CATS. TEMPORARY CRANES 279 MSL 536FT S OF JAX AIRPORT (2024-ASO-5713/5715 THRU 5718-NRA). TEMPORARY CRANES 176 MSL 2409FT SE OF JAX AIRPORT (2024-ASO-15242 THRU 15248-NRA). TEMPORARY CRANES 179 MSL 4785FT SE OF JAX AIRPORT (2025-ASO-1151/1152-NRA).
2607271500-2702031500EST
7/27/26
1500Z
!FDC 6/8943 JAX IAP JACKSONVILLE INTL, JACKSONVILLE, FL.
RNAV (GPS) Z RWY 26, AMDT 2F...
CIRCLING CAT A/B/C MDA 640/HAA 610. TEMPORARY CRANES 279 MSL 536FT S OF JAX AIRPORT (2024-ASO-5713/5715 THRU 5718-NRA). TEMPORARY CRANES 176 MSL 2409FT SE OF JAX AIRPORT (2024-ASO-15242 THRU 15248-NRA). TEMPORARY CRANES 179 MSL 4785FT SE OF JAX AIRPORT (2025-ASO-1151/1152-NRA).
2607271500-2702031500EST
7/27/26
1500Z
!FDC 6/8942 JAX IAP JACKSONVILLE INTL, JACKSONVILLE, FL.
ILS Y OR LOC Y RWY 26, AMDT 3A...
CIRCLING MDA 640/HAA 610 ALL CATS. ZETRI FIX MINIMUMS (DUAL VOR RECEIVERS REQUIRED): CIRCLING MDA 640/HAA 610 ALL CATS. TEMPORARY CRANES 279 MSL 536FT S OF JAX AIRPORT (2024-ASO-5713/5715 THRU 5718-NRA). TEMPORARY CRANES 176 MSL 2409FT SE OF JAX AIRPORT (2024-ASO-15242 THRU 15248-NRA). TEMPORARY CRANES 179 MSL 4785FT SE OF JAX AIRPORT (2025-ASO-1151/1152-NRA).
2607271500-2702031500EST
7/27/26
1500Z
!FDC 6/8941 JAX IAP JACKSONVILLE INTL, JACKSONVILLE, FL.
ILS Y OR LOC Y RWY 8, AMDT 14...
VOR/DME RWY 32, AMDT 2E...
CIRCLING CAT A/B/C/D MDA 640/HAA 610. TEMPORARY CRANES 279 MSL 536FT S OF JAX AIRPORT (2024-ASO-5713/5715 THRU 5718-NRA). TEMPORARY CRANES 176 MSL 2409FT SE OF JAX AIRPORT (2024-ASO-15242 THRU 15248-NRA). TEMPORARY CRANES 179 MSL 4785FT SE OF JAX AIRPORT (2025-ASO-1151/1152-NRA).
2607271500-2702031500EST
7/27/26
1500Z
!FDC 6/8940 JAX IAP JACKSONVILLE INTL, JACKSONVILLE, FL.
ILS Y OR LOC Y RWY 14, AMDT 8...
CIRCLING MDA 640/HAA 610 ALL CATS. KUYER FIX MINIMUMS (DME REQUIRED): CIRCLING MDA 640/HAA 610 ALL CATS. TEMPORARY CRANES 279 MSL 536FT S OF JAX AIRPORT (2024-ASO-5713/5715 THRU 5718-NRA). TEMPORARY CRANES 176 MSL 2409FT SE OF JAX AIRPORT (2024-ASO-15242 THRU 15248-NRA). TEMPORARY CRANES 179 MSL 4785FT SE OF JAX AIRPORT (2025-ASO-1151/1152-NRA).
2607271500-2702031500EST
7/27/26
1500Z
!FDC 6/8938 JAX IAP U.S. DOD JACKSONVILLE INTL, JACKSONVILLE, FL.
HI-ILS Z OR LOC Z RWY 14, AMDT 4...
CIRCLING CAT C MDA 640/HAA 610, VIS CAT C 1 3/4. TEMPORARY CRANES 279 MSL 536FT S OF JAX AIRPORT (2024-ASO-5713/5715 THRU 5718-NRA).
2607271500-2702031500EST
7/27/26
1454Z
!FDC 6/8937 JAX IAP U.S. DOD JACKSONVILLE INTL, JACKSONVILLE, FL.
HI - TACAN RWY 14, AMDT 4C...
S-14* CAT C/D/E MDA 520/493, VIS CAT C/D/E 1. CIRCLING CAT C MDA 640/HAA 610, VIS CAT C 1 3/4. *WHEN ALS INOP, INCREASE VIS TO 1 3/8 SM. TEMPORARY CRANES 279 MSL 536FT S OF JAX AIRPORT (2024-ASO-5713/5715 THRU 5718-NRA).
2607271454-2702031454EST
7/27/26
1454Z
!FDC 6/8936 JAX IAP JACKSONVILLE INTL, JACKSONVILLE, FL.
HI-ILS Z OR LOC Z RWY 26, AMDT 3A...
CIRCLING CAT C/D MDA 640/HAA 610, VIS CAT C 1 3/4. ZETRI FIX MINIMUMS (DUAL VOR RECEIVERS REQUIRED): CIRCLING CAT C/D MDA 640/HAA 610, VIS CAT C 1 3/4. TEMPORARY CRANES 279 MSL 536FT S OF JAX AIRPORT (2024-ASO-5713/5715 THRU 5718-NRA).
2607271454-2702031454EST
3/30/26
2017Z
!FDC 6/5956 JAX IAP U.S. DOD JACKSONVILLE INTL, JACKSONVILLE, FL.
HI-ILS Z OR LOC Z RWY 14, AMDT 4...
ILS Y OR LOC Y RWY 14, AMDT 8...
PROCEDURE NA.
2603302017-2712012017EST
12/1/25
1815Z
!FDC 5/2959 JAX IAP JACKSONVILLE INTL, JACKSONVILLE, FL.
HI-ILS Z OR LOC Z RWY 26, AMDT 3...
TERMINAL ROUTE FROM AMG VORTAC TO BIGS NA.
2512011815-2712011815EST
Yes
ALL
JACKSONVILLE INTL AIRPORT
14201 PECAN PARK ROAD
JACKSONVILLE, FL 32218
Phone: 904-741-2000
MR. TERRY DLUGOS
14201 PECAN PARK ROAD
JACKSONVILLE, FL 32218
Phone: (904) 741-3866
GAINESVILLE FSS (GNV)
Toll Free: 1-800-WX-BRIEF
JAX
Sunset to Sunrise
--
N/A
Yes - Lighted
Yes
No
Hanger, Tie-Down
Landing Rights Airport
NOT an Airport of Entry
Major
Minor
None
None
Air Freight
Avionics
Cargo Handling
Charter Service
Annual Surveying

Runway 08/26

10000 ft. x 150 ft.
CONC
Good
GRVD
HIGH

120,000lbs
250,000lbs
550,000lbs
1,120,000lbs
  Runway 08 Runway 26
True Heading 71°251°
Traffic Pattern Left Left
Markings PIR PIR
Markings Condition FAIR FAIR
Latitude 30° 29' 46"N 30° 30' 19"N
Longitude 81° 41' 60"W 81° 40' 12"W
Elevation 29' 26'
Threshold Crossing Height 70 ft. AGL 70 ft. AGL
Visual Glide Path Angle 3° 3°
Visual Slope Indicator P4L P4R
Approach Lights ALSF2 MALSR
Centerline Lights Yes Yes
Runway End Identifier Lights No

Runway 14/32

7701 ft. x 150 ft.
CONC
Good
GRVD
HIGH

120,000lbs
250,000lbs
550,000lbs
1,120,000lbs
  Runway 14 Runway 32
True Heading 131°311°
Traffic Pattern Left Left
Markings PIR PIR
Markings Condition GOOD GOOD
Latitude 30° 29' 32"N 30° 28' 42"N
Longitude 81° 42' 03"W 81° 40' 56"W
Elevation 27' 24'
Threshold Crossing Height 70 ft. AGL 67 ft. AGL
Visual Glide Path Angle 3° 3°
Visual Slope Indicator P4L P4L
Approach Lights MALSR
Centerline Lights Yes Yes
Runway End Identifier Lights Yes
A110-1BIRD ACTIVITY INVOF ARPT, WILDLIFE PRESENTLY ON AIRFIELD.
A110-11NON-LOAD BEARING ASPHALT ON WEST AIR CARRIER RAMP BTWN OUTER HIGH MAST LIGHTS AND TERMINAL. AIRCRAFT RQRD TO MAINTAIN TAXI OPS OVER CTRLN ON THE AIR CARRIER RAMP.
A110-12PPR FOR HIGH POWER JET ENGINE RUN UPS CTC APT OPS AT 904-741-2020.
A110-13MILITARY: ANG: OPR DAYS VARY. BASE OPS 1130-2100Z++. OFFL BUS ONLY. PPR FOR ALL TRAN AFCT (CALL FANG OPS) DSN 641-7122/40/25,C 904-741-7122/40/25. PPR NEEDED TO PROCD ON TWY M1, M2, M3 FANG MAIN RAMP AND ALERT RAMP. PPR NO RESTRD TO ONLY 1 HR EARLIER OR LTR THAN APVL TIME, BFR/AFT THOSE TIMES THE NO IS NOT VALID. TRAN SVCS UNAVBL. FOR CURRENT BWC CTC SOF (FANG OPS) 251.25. BASH PHASE II 1 NOV THRU 31 MAR FOR MIGRATORY BIRD ACT. FOR MORE DTLD INFO SEE AP/1.
A110-14ARPT CLSD TO ACFT WINGSPAN MORE THAN 171 FT EXC 6 HR PPR 904-741-2020.
A110-1524 HR PPR FOR ACFT EQUIPPED WITH WEATHER MODIFICATION OR GEOENGINEERING EQPT 904-741-2020.
A110-16PILOTS CONDUCTING EFVS OPS; BE AWARE LED ALS IN USE RWY 14.
A110-3BAK-14 CABLE RAISED FOR TAILHOOK ENGAGEMENT BY TWR ON PILOT REQ ONLY, 1537 FT FM AER 08 AND 1612 FT FM AER 26.
A110-7ARPT CLSD TO INTL GEN AVIATION ARR EXE 6HR PPR ARPT OPS AT 904-741-2020 & CTC U. S. CUSTOMS & SERVICING FBO FOR PROCESSING & INSTRUCTIONS.
A110-8RADIO CONTROLLED ACFT ACTIVITY 3.5 NM 'NNW' OF ARPT.
A110-9SMALL PORTION OF TERMINAL RAMP NOT VISIBLE FM TWR. TWR UNABLE TO DETERMINE IF RAMP IS CLEAR.
A26PPR 24 HRS FOR UNSKED ACR OPNS WITH MORE THAN 30 PSGR SEATS CALL AMGR 904-741-2020.
A39-08/26PCR VALUE: 970/R/A/W/T
A39-14/32PCR VALUE: 1380/R/B/W/T
E60-08_BAK-14BAK-14 BAK-12B(B) (1537 FT).
E60-26_BAK-14BAK-14 BAK-12B-(B) (1612 FT)
JACKSONVILLE INTL (ICAO: KJAX, IATA: JAX) is a public airport located in JACKSONVILLE, FL, US.
