12/9/24 2241Z | 12/11/26 2241Z | | !FDC 4/3801 JQF PART 1 OF 4 ODP CONCORD-PADGETT RGNL, CONCORD, NC.
TAKEOFF MINIMUMS AND (OBSTACLE) DEPARTURE PROCEDURES AMDT 3A...
TAKEOFF OBSTACLE NOTES: RWY 2: LIGHT POLE 13 FT FROM DER, 5 FT
RIGHT OF CENTERLINE, 2 FT AGL/705 FT MSL.
TREES BEGINNING 1778 FT FROM DER, 931 FT RIGHT OF CENTERLINE, UP TO
772 FT MSL.
TREE, TRAVERSE WAYS, POLE BEGINNING 2108 FT FROM DER, 575 FT RIGHT
OF CENTERLINE, UP TO 783 FT MSL.
TREES, TRAVERSE WAYS, FENCES, TRAMWAY, SIGNS BEGINNING 2233 FT FROM
DER, ON CENTERLINE, UP TO 786 FT MSL.
TRAVERSE WAY 2390 FT FROM DER, 56 FT LEFT OF CENTERLINE, 766 FT
MSL.
TREE 2391 FT FROM DER, 1028 FT LEFT OF CENTERLINE, 767 FT MSL.
BUILDING, TREES, FENCE BEGINNING 2432 FT FROM DER, 63 FT RIGHT OF
CENTERLINE, UP TO 794 FT MSL.
TREE, POLE BEGINNING 2454 FT FROM DER, 389 FT LEFT OF CENTERLINE,
UP TO 772 FT MSL.
TREES BEGINNING 2526 FT FROM DER, 767 FT LEFT OF CENTERLINE, UP TO
773 FT MSL.
TREES BEGINNING 2535 FT FROM DER, 3 FT RIGHT OF CENTERLINE, UP TO
805 FT MSL.
2412092241-2612112241EST
END PART 1 OF 4
!FDC 4/3801 JQF PART 2 OF 4 ODP CONCORD-PADGETT RGNL, CONCORD, NC.
TREES, POLE BEGINNING 2558 FT FROM DER, 81 FT LEFT OF CENTERLINE,
UP TO 12 FT AGL/785 FT MSL.
TREES BEGINNING 2730 FT FROM DER, 198 FT LEFT OF CENTERLINE, UP TO
788 FT MSL.
TREES, BUILDING, UTILITY BUILDING, TANK BEGINNING 2804 FT FROM DER,
ON AND RIGHT OF CENTERLINE, UP TO 807 FT MSL.
TREE 2830 FT FROM DER, 842 FT LEFT OF CENTERLINE, 790 FT MSL.
TREES BEGINNING 2859 FT FROM DER, 349 FT LEFT OF CENTERLINE, UP TO
793 FT MSL.
TREES BEGINNING 2911 FT FROM DER, 226 FT LEFT OF CENTERLINE, UP TO
53 FT AGL/796 FT MSL.
TREE, POLES BEGINNING 3003 FT FROM DER, 352 FT LEFT OF CENTERLINE,
UP TO 803 FT MSL.
POLE 3086 FT FROM DER, 1188 FT LEFT OF CENTERLINE, 806 FT MSL.
TREES, TANK, TERRAINS BEGINNING 3099 FT FROM DER, 17 FT LEFT OF
CENTERLINE, UP TO 813 FT MSL.
POLES, UTILITY BUILDING, TREES BEGINNING 3230 FT FROM DER, 15 FT
LEFT OF CENTERLINE, UP TO 818 FT MSL.
TREE 3563 FT FROM DER, 204 FT RIGHT OF CENTERLINE, 81 FT AGL/814 FT
MSL.
2412092241-2612112241EST
END PART 2 OF 4
!FDC 4/3801 JQF PART 3 OF 4 ODP CONCORD-PADGETT RGNL, CONCORD, NC.
RWY 20: TREE 4 FT FROM DER, 469 FT RIGHT OF CENTERLINE, 15 FT
AGL/646 FT MSL.
TREE 419 FT FROM DER, 581 FT LEFT OF CENTERLINE, 659 FT MSL.
TREES BEGINNING 740 FT FROM DER, 8 FT RIGHT OF CENTERLINE, UP TO
678 FT MSL.
TREES BEGINNING 760 FT FROM DER, 29 FT LEFT OF CENTERLINE, UP TO
688 FT MSL.
TREES BEGINNING 902 FT FROM DER, 2 FT LEFT OF CENTERLINE, UP TO 693
FT MSL.
TREES BEGINNING 1085 FT FROM DER, 3 FT RIGHT OF CENTERLINE, UP TO
683 FT MSL.
TREES BEGINNING 1349 FT FROM DER, 1 FT RIGHT OF CENTERLINE, UP TO
98 FT AGL/684 FT MSL.
TREES BEGINNING 1518 FT FROM DER, 38 FT RIGHT OF CENTERLINE, UP TO
93 FT AGL/685 FT MSL.
TREES BEGINNING 1546 FT FROM DER, 8 FT RIGHT OF CENTERLINE, UP TO
709 FT MSL.
TREES BEGINNING 1680 FT FROM DER, 47 FT RIGHT OF CENTERLINE, UP TO
712 FT MSL.
TREES BEGINNING 1845 FT FROM DER, 254 FT LEFT OF CENTERLINE, UP TO
2412092241-2612112241EST
END PART 3 OF 4
!FDC 4/3801 JQF PART 4 OF 4 ODP CONCORD-PADGETT RGNL, CONCORD, NC.
86 FT AGL/696 FT MSL.
POLE 2667 FT FROM DER, 148 FT LEFT OF CENTERLINE, 103 FT AGL/715 FT
MSL.
POLES BEGINNING 3047 FT FROM DER, 197 FT RIGHT OF CENTERLINE, UP TO
108 FT AGL/744 FT MSL.
POLE 3228 FT FROM DER, 163 FT LEFT OF CENTERLINE, 102 FT AGL/723 FT
MSL.
ELECTRICAL SYSTEM 1.3 NM FROM DER, 484 FT RIGHT OF CENTERLINE, 140
FT AGL/852 FT MSL. ALL OTHER DATA REMAINS AS PUBLISHED.
2412092241-2612112241EST
END PART 4 OF 4
|
