SIKORSKY - Airport Diagram
LiveATC.net: Live Air Traffic - From Their Headsets to You

KJSD
ICAO KJSDIATA JSDLocal JSD
SIKORSKY
PrivatePVT

3 miles N of STRATFORD, CT, US
View on Map
LiveATC.net: Live Air Traffic - From Their Headsets to You
Status
Operational
Coordinates
41° 14' 50"N 73° 05' 52"W
Elevation
21' MSL
Pattern Alt
1021' MSL
Mag Variation
13°W
Declination
13°W
Fuel
JET A
FSS
BRIDGEPORT (BDR)
Sectional
NEW YORK
ARTCC
NEW YORK (ZNY)
Data Effective
2/19/26-3/19/26
KBDR (5nm) VFR
8:52 AM EDT
Overcast 11,000'
10sm
35°F
20°F
30.49"Hg
050° 4kts
AO2 SLP326 T00171067
METAR KBDR 151252Z 05004KT 10SM OVC110 02/M07 A3049 RMK AO2 SLP326 T00171067
+ Add Your Business

KJSD FBOs

No FBOs (Fixed Base Operators) are listed for this airport.
X

Send Message to Airport Company
Enter your information and message below.

Your Information

Processing

Tower

SIKORSKY TOWER 133.6
0800-SS MON-FRI, 0800-SS SAT-SUN AS REQ
SIKORSKY TOWER 125.2
0800-SS MON-FRI, 0800-SS SAT-SUN AS REQ, Secondary

FAA A/FD Pages

Terminal Area Forecast

KBDR (5nm)
Sun, 3/15 7:20 AM EDT
Sun, 3/15 8:00 AM EDT - Mon, 3/16 8:00 AM EDT
VFR
8:00 AM EDT - 9:00 AM EDT
Broken 10,000'
6sm
VRB° 3kts
VFR
9:00 AM EDT - 12:00 PM EDT
Broken 10,000'
6sm
070° 7kts
VFR
12:00 PM EDT - 4:00 PM EDT
Broken 10,000'
6sm
120° 9kts
VFR
4:00 PM EDT - 12:00 AM EDT
Broken 20,000'
Scattered 8,000'
6sm
120° 11kts
MVFR
12:00 AM EDT - 5:00 AM EDT
Overcast 3,000'
Scattered 1,500'
6sm
100° 10kts
MVFR
Temporary 1:00 AM EDT - 5:00 AM EDT
Light Rain
Overcast 3,000'
Broken 1,500'
6sm
Calm
IFR
5:00 AM EDT - 7:00 AM EDT
Showers and Rain and Mist
Overcast 600'
2sm
110° 13kts
Gusts 27kts
IFR
7:00 AM EDT - 8:00 AM EDT
Showers and Rain and Mist
Overcast 500'
1sm
150° 14kts
Gusts 27kts
TAF KBDR 151120Z 1512/1612 VRB03KT P6SM BKN100
   FM151300 07007KT P6SM BKN100
   FM151600 12009KT P6SM BKN100
   FM152000 12011KT P6SM SCT080 BKN200
   FM160400 10010KT P6SM SCT015 OVC030
   TEMPO 1605/1609 6SM -RA BKN015 OVC030
   FM160900 11013G27KT 2SM SHRA BR OVC006 WS020/14055KT
   FM161100 15014G27KT 1SM SHRA BR OVC005 WS020/16055KT
KJSD
No NOTAM Available
Yes
MON-FRI 0800-SS
SAT-SUN 0800-SS
AS RQRD.
SIKORSKY AIRCRAFT
6900 MAIN STREET
STRATFORD, CT 06614
Phone: 203-386-3873
THEODORE POCWIERZ, JR.
6900 MAIN STREET
STRATFORD, CT 06614
Phone: 203-386-3873
BRIDGEPORT FSS (BDR)
Toll Free: 1-800-WX-BRIEF
FDC
--
FOR PERIMETER LGTS CALL 203-386-4405.
N/A
Yes
No
No
None
NOT a Landing Rights Airport
NOT an Airport of Entry
Minor
Minor
None
None
None

Runway H1

150 ft. x 150 ft.

ASPH
NONE
LOW

--
--
--
--
  Runway H1 Runway
True Heading Not ListedNot Listed
Traffic Pattern
Markings
Markings Condition FAIR
Latitude 41° 15' 12"N N/A
Longitude 73° 05' 22"W N/A
Elevation 11' --
Threshold Crossing Height -- --
Visual Glide Path Angle -- --
Visual Slope Indicator -- --
Approach Lights
Centerline Lights
Runway End Identifier Lights

Runway H2

600 ft. x 600 ft.
ASPH
Good
NONE


--
--
--
--
  Runway H2 Runway
True Heading Not ListedNot Listed
Traffic Pattern
Markings
Markings Condition FAIR
Latitude 41° 15' 10"N N/A
Longitude 73° 05' 28"W N/A
Elevation 16' --
Threshold Crossing Height -- --
Visual Glide Path Angle -- --
Visual Slope Indicator -- --
Approach Lights
Centerline Lights
Runway End Identifier Lights

Runway H3

100 ft. x 100 ft.
ASPH
Good
NONE


--
--
--
--
  Runway H3 Runway
True Heading Not ListedNot Listed
Traffic Pattern
Markings
Markings Condition FAIR
Latitude 41° 14' 50"N N/A
Longitude 73° 05' 52"W N/A
Elevation 20' --
Threshold Crossing Height -- --
Visual Glide Path Angle -- --
Visual Slope Indicator -- --
Approach Lights
Centerline Lights
Runway End Identifier Lights
A110-1EXTSV HEL TESTING WI 15 NMR SFC TO 10000 FT DLY.
A110-2EXTSV BIRD ACTVTY ON & INVOF HELI.
A110-3FOR CD CTC NEW YORK APCH AT 516-683-2963.
A17-D2AS RQRD.
A52-H1PAD FENCED.
A52-H2PAD FENCED.
A81-APTFOR PERIMETER LGTS CALL 203-386-4405.
E111EXISTED PRIOR TO 1959.
SIKORSKY (ICAO: KJSD, IATA: JSD) is a private heliport located in STRATFORD, CT, US.
