8/6/25 1911Z | 8/6/27 1911Z | | !FDC 5/2218 JSV PART 1 OF 3 ODP SALLISAW MUNI, SALLISAW, OK.
TAKEOFF MINIMUMS AND (OBSTACLE) DEPARTURE PROCEDURES AMDT 2...
TAKEOFF OBSTACLE NOTES: RWY 17: FENCE 108 FT FROM DER, 398 FT
RIGHT OF CENTERLINE, 13 FT AGL/521 FT MSL.
TREES BEGINNING 181 FT FROM DER, 299 FT LEFT OF CENTERLINE, UP TO
46 FT AGL/557 FT MSL.
TREES BEGINNING 277 FT FROM DER, 127 FT LEFT OF CENTERLINE, UP TO
70 FT AGL/581 FT MSL.
POLE 491 FT FROM DER, 626 FT RIGHT OF CENTERLINE, 37 FT AGL/547 FT
MSL.
TREES, POLES BEGINNING 625 FT FROM DER, 25 FT RIGHT OF CENTERLINE,
UP TO 571 FT MSL.
TREES BEGINNING 1213 FT FROM DER, 594 FT LEFT OF CENTERLINE, UP TO
58 FT AGL/588 FT MSL.
TREES BEGINNING 1355 FT FROM DER, 363 FT LEFT OF CENTERLINE, UP TO
88 FT AGL/595 FT MSL.
TREE 2213 FT FROM DER, 181 FT RIGHT OF CENTERLINE, 573 FT MSL. RWY
35: FENCE 77 FT FROM DER, 497 FT LEFT OF CENTERLINE, 5 FT AGL/535
FT MSL.
FENCE 168 FT FROM DER, 386 FT LEFT OF CENTERLINE, 5 FT AGL/536 FT
MSL.
2508061911-2708061911EST
END PART 1 OF 3
!FDC 5/2218 JSV PART 2 OF 3 ODP SALLISAW MUNI, SALLISAW, OK.
TREES, FENCE, POLES, TRANSMISSION LINES BEGINNING 179 FT FROM DER,
21 FT LEFT OF CENTERLINE, UP TO 64 FT AGL/595 FT MSL.
FENCE 202 FT FROM DER, 300 FT RIGHT OF CENTERLINE, 5 FT AGL/535 FT
MSL.
TREE 566 FT FROM DER, 243 FT RIGHT OF CENTERLINE, 21 FT AGL/555 FT
MSL.
POLE 661 FT FROM DER, 221 FT RIGHT OF CENTERLINE, 23 FT AGL/558 FT
MSL.
TREE, POLE BEGINNING 770 FT FROM DER, 379 FT RIGHT OF CENTERLINE,
UP TO 41 FT AGL/577 FT MSL.
TREES, TRANSMISSION LINES, POLES BEGINNING 1039 FT FROM DER, 64 FT
RIGHT OF CENTERLINE, UP TO 55 FT AGL/591 FT MSL.
POLE 1517 FT FROM DER, 497 FT LEFT OF CENTERLINE, 54 FT AGL/598 FT
MSL.
POLES BEGINNING 1518 FT FROM DER, 115 FT LEFT OF CENTERLINE, UP TO
60 FT AGL/605 FT MSL.
POLE 1722 FT FROM DER, 869 FT RIGHT OF CENTERLINE, 71 FT AGL/600 FT
MSL.
SIGN, POLES BEGINNING 1759 FT FROM DER, 116 FT RIGHT OF CENTERLINE,
UP TO 76 FT AGL/605 FT MSL.
2508061911-2708061911EST
END PART 2 OF 3
!FDC 5/2218 JSV PART 3 OF 3 ODP SALLISAW MUNI, SALLISAW, OK.
SIGNS, TREE BEGINNING 1985 FT FROM DER, 465 FT LEFT OF CENTERLINE,
UP TO 72 FT AGL/618 FT MSL.
SIGN, TREE BEGINNING 2579 FT FROM DER, 593 FT LEFT OF CENTERLINE,
UP TO 96 FT AGL/644 FT MSL.
SIGNS, TOWERS, TREES, POLE BEGINNING 2858 FT FROM DER, 605 FT LEFT
OF CENTERLINE, UP TO 113 FT AGL/665 FT MSL.
2508061911-2708061911EST
END PART 3 OF 3
|
