HARRY REID INTL - Airport Diagram
LiveATC.net: Live Air Traffic - From Their Headsets to You

KLAS
ICAO KLASIATA LASLocal LAS
HARRY REID INTL
PublicPUB

5 miles S of LAS VEGAS, NV, US
View on Map
LiveATC.net: Live Air Traffic - From Their Headsets to You
Status
Operational
Coordinates
36° 04' 49"N 115° 09' 09"W
Elevation
2183' MSL
Pattern Alt
3183' MSL
Mag Variation
11°E
Declination
11°E
Fuel
JET A-1+, 100LL, 100
FSS
RENO (RNO)
Sectional
LAS VEGAS
ARTCC
LOS ANGELES (ZLA)
Data Effective
2/19/26-3/19/26
KLAS VFR
8:56 AM PST
Scattered 20,000'
10sm
51°F
25°F
30.41"Hg
060° 3kts
AO2 SLP297 T01061039
METAR KLAS 221656Z 06003KT 10SM SCT200 11/M04 A3041 RMK AO2 SLP297 T01061039
+ Add Your Business

KLAS FBOs

Promote Listing
Atlantic Aviation
UNICOM: 128.85
Phone: (702) 736-1830
No Rating Available
0 Reviews (Read | Sign In To Write)
Independent
As of 2/11
 100LL JET A JET A (FSII) MOGAS UL94
Self Serve
Full Serve 9.89 8.56
Fuel Notes
Prices include tax
Promote Listing
Signature Aviation
UNICOM: 128.875
Phone: (702) 739-1100
No Rating Available
0 Reviews (Read | Sign In To Write)
Independent
As of 2/18
 100LL JET A JET A (FSII) MOGAS UL94
Self Serve
Full Serve 9.89 8.36
Fuel Notes
Prices include tax

KLAS Aircraft Service & Maintenance

Promote Listing
Duncan Aviation - Las Vegas
Phone: (702) 262-6142
Fax: (702) 262-6739
No Rating Available
0 Reviews (Read | Sign In To Write)

KLAS Other Aviation Services

Promote Listing
Denmar Technical Services
Phone: (775) 284-5580
Fax: (775) 284-5588
No Rating Available
0 Reviews (Read | Sign In To Write)
X

Send Message to Airport Company
Enter your information and message below.

Your Information

Processing

Weather and Advisory

Digital ATIS 132.4
(702) 736-0950
ASOS (702) 582-5334

Common

UNICOM 122.95
ALL ACFT CTC RAMP CTL ON FREQ 124.4 FOR OPS AT A, B, C GATES, AND GA, CUSTOMS; CTC RAMP CTL FREQ 127.9 FOR OPNS AT D AND E GATES AND CARGO RAMP PRIOR TO ENTERING RAMP OR PUSHING BACK FM GATE OR PRKG SPOT. RAMP CTL OPR HRS 0500-0100L. WHEN RAMP IS CLSD (0100-0500L) BROADCAST ALL NON-MOVEMENT AREA OPNS ON UNICOM 122.95.

Clearance

Clearance Delivery 118.0

Ground

LAS VEGAS GROUND 121.1
E OF RWY 01R/19L
LAS VEGAS GROUND 121.9
W OF RWY 01L/19R
Ramp Control 124.4
A, B, C GATES & GA, CUSTOMS.
Ramp Control 127.9
D, E GATES & CARGO.
Ramp Control 130.0
RAMP ALTERNATE FREQUENCY

Tower

LAS VEGAS TOWER 118.75
RWY 01L/19R, 01R/19L
LAS VEGAS TOWER 119.9
RWY 08L/26R, 08R/26L

Arrival

ARRIVAL 120.45
VFR ARR
BLAID STAR 119.775
CHOWW STAR 119.775
COKTL STAR 125.025
CRESO STAR 125.475
GAMES STAR 125.025
PROPS;
GAMES STAR 125.025
ISHEE STAR 119.775
JAYSN STAR 125.025
LARKK STAR 125.025
PUMLE STAR 125.025
RKSTR STAR 119.775
RNDRZ STAR 125.025

Approach

LAS VEGAS APPROACH 119.775
EAST
LAS VEGAS APPROACH 125.025
WEST

Departure

FRNCK DP 133.95
RWY 8L/R
GIDGT DP 133.95
HOOVER DP 125.9
RWY 19L/R, RWY 26L/R
HOOVER DP 133.95
RWY 1L/R, RWY 8L/R
JOHKR DP 125.9
LAS VEGAS DEPARTURE 125.9
LAS VEGAS DEPARTURE 133.95
LOHLA DP 125.9
RWY 1L/R, RWY 8L/R
LOHLA DP 133.95
RWY 19L/R, RWY 26L/R
MCCARRAN DP 125.9
NIITZ DP 125.9
RWY 19L/R, RWY 26L/R
NIITZ DP 133.95
RWY 1L/R, RWY 8L/R
RADYR DP 125.9
RASLR DP 125.9
RWY 19L/R, RWY 26L/R
RASLR DP 133.95
RWY 1L/R, RWY 8L/R
RATPK DP 125.9
RWY 8L/R
RATPK DP 133.95
RWY 1L/R, RWY 19L/R, RWY 26L/R
TRALR DP 133.95
RWY 1L/R, RWY 8L/R

Flight Service

Flight Service 122.4
(RNO)

Emergency

Emergency 121.5

Other

CLASS B 119.775
030-110 LAS
CLASS B 125.025
200-300 LAS
CLASS B 125.475
110-200 LAS

Terminal Area Forecast

KLAS
Sun, 2/22 9:20 AM PST
Sun, 2/22 10:00 AM PST - Mon, 2/23 4:00 PM PST
VFR
10:00 AM PST - 7:00 PM PST
Scattered 20,000'
6sm
040° 5kts
VFR
7:00 PM PST - 6:00 AM PST
Few 20,000'
6sm
240° 5kts
VFR
6:00 AM PST - 11:00 AM PST
Few 20,000'
6sm
VRB° 5kts
VFR
11:00 AM PST - 4:00 PM PST
Few 20,000'
6sm
080° 5kts
TAF KLAS 221720Z 2218/2324 04005KT P6SM SCT200
   FM230300 24005KT P6SM FEW200
   FM231400 VRB05KT P6SM FEW200
   FM231900 08005KT P6SM FEW200
KLAS
EffectiveExpiresCategoryNOTAM
Domestic
2/24/26
1400Z
2/24/26
2300Z
!LAS 02/169 LAS OBST CRANE (ASN UNKNOWN) 360308N1151043W (1.5NM SW APCH END RWY 01R) 2372FT (110FT AGL) FLAGGED NOT LGTD 2602241400-2602242300
2/24/26
0500Z
2/24/26
1100Z
!LAS 02/168 LAS COM REMOTE COM OUTLET 122.4 U/S 2602240500-2602241100
2/23/26
0000Z
2/23/26
0200Z
!LAS 02/165 LAS AIRSPACE UAS WI AN AREA DEFINED AS 0.3NM RADIUS OF
361641N1150023W (10.0NM NE VGT) SFC-700FT AGL 2602230000-2602230200
2/17/26
1500Z
3/21/26
0001Z
!LAS 02/099 LAS OBST CRANE (ASN 2025-AWP-13419-OE) 360737N1150845W (2.8NM NE LAS) 2224FT (200FT AGL) FLAGGED AND LGTD 2602171500-2603210001
2/3/26
0200Z
4/29/26
2300Z
!LAS 01/141 LAS OBST CRANE (ASN UNKNOWN) 360456N1150816W (0.72NM ENE LAS)
2171FT (105FT AGL) FLAGGED AND LGTD 2602030200-2604292300
1/28/26
1500Z
3/19/26
0100Z
!LAS 01/113 LAS OBST CRANE LGT (ASN 2025-AWP-13070-OE) 360826N1150936W (3.6NM N LAS) 2711FT (650FT AGL) U/S 2601281500-2603190100
1/27/26
1928Z
4/29/26
2300Z
!LAS 01/137 LAS OBST CRANE (ASN UNKNOWN) 360616N1150903W (0.4NM NNE APCH END RWY 19L)
UNKNOWN (79FT AGL) FLAGGED AND LGTD 2601271928-2604292300
1/27/26
1926Z
4/29/26
2300Z
!LAS 01/136 LAS OBST CRANE (ASN 2024-AWP-5082-NRA) 360508N1151011W (0.9NM WNW LAS) 2429FT (275FT AGL) FLAGGED AND LGTD 2601271926-2604292300
1/27/26
1924Z
4/29/26
2300Z
!LAS 01/135 LAS OBST CRANE (ASN 2024-AWP-5078-NRA) 360510N1151012W (0.9NM WNW LAS) 2427FT (275FT AGL) FLAGGED AND LGTD 2601271924-2604292300
1/27/26
1923Z
4/29/26
2300Z
!LAS 01/134 LAS OBST CRANE (ASN 2024-AWP-5074-NRA) 360512N1151013W (1.0NM WNW LAS) 2302FT (150FT AGL) FLAGGED AND LGTD 2601271923-2604292300
1/27/26
1922Z
4/29/26
2300Z
!LAS 01/133 LAS OBST CRANE (ASN UNKNOWN) 360502N1150748W (1.1NM ENE LAS)
2180FT (140FT AGL) FLAGGED AND LGTD 2601271922-2604292300
1/27/26
1919Z
4/29/26
2300Z
!LAS 01/132 LAS OBST CRANE (ASN 2024-AWP-7796-NRA) 360451N1150850W (0.2NM ENE LAS) 2266FT (170FT AGL) FLAGGED AND LGTD 2601271919-2604292300
1/27/26
1917Z
4/29/26
2300Z
!LAS 01/131 LAS OBST CRANE (ASN 2024-AWP-7792-NRA) 360509N1150910W (0.4NM N LAS) 2244FT (140FT AGL) FLAGGED AND LGTD 2601271917-2604292300
1/27/26
1916Z
4/29/26
2300Z
!LAS 01/130 LAS OBST CRANE (ASN 2025-AWP-5047-OE) 360559N1151016W (1.5NM NW LAS) 2530FT (416FT AGL) FLAGGED AND LGTD 2601271916-2604292300
1/27/26
1912Z
4/29/26
2300Z
!LAS 01/129 LAS AD AP CLSD TO NON SKED TRANSIENT GA ACFT EXC 24HR PPR 702-261-7775 2601271912-2604292300
1/27/26
1912Z
4/29/26
2300Z
!LAS 01/128 LAS OBST SILO (ASN 2023-AWP-3561-NRA) 360508N1150742W (1.2NM ENE LAS) 2108FT (80FT AGL) FLAGGED AND LGTD 2601271912-2604292300
9/26/25
2240Z
9/26/26
2359Z
!LAS 09/270 LAS NAV TACAN DME 080-097 BEYOND 14NM SFC-10000FT UNUSABLE 2509262240-2609262359
9/26/25
2239Z
9/26/26
2359Z
!LAS 09/269 LAS NAV TACAN DME 033-045 BEYOND 26NM SFC-9000FT UNUSABLE 2509262239-2609262359
9/26/25
2238Z
9/26/26
2359Z
!LAS 09/268 LAS NAV TACAN DME 170-218 BEYOND 25NM SFC-11000FT UNUSABLE 2509262238-2609262359
9/26/25
2237Z
9/26/26
2359Z
!LAS 09/267 LAS NAV TACAN DME 102-170 BEYOND 22NM SFC-12000FT UNUSABLE 2509262237-2609262359
9/26/25
2236Z
9/26/26
2359Z
!LAS 09/266 LAS NAV TACAN DME 224-336 BEYOND 35NM SFC-15000FT UNUSABLE 2509262236-2609262359
9/26/25
2234Z
9/26/26
2359Z
!LAS 09/265 LAS NAV TACAN DME BEYOND 40NM UNUSABLE 2509262234-2609262359
9/26/25
2228Z
9/26/26
2359Z
!LAS 09/264 LAS NAV VOR 080-097 BEYOND 36NM SFC-10000FT UNUSABLE 2509262228-2609262359
9/26/25
2227Z
9/26/26
2359Z
!LAS 09/263 LAS NAV VOR 033-045 BEYOND 26NM SFC-9000FT UNUSABLE 2509262227-2609262359
9/26/25
2226Z
9/26/26
2359Z
!LAS 09/262 LAS NAV VOR 170-218 BEYOND 25NM SFC-11000FT UNUSABLE 2509262226-2609262359
9/26/25
2225Z
9/26/26
2359Z
!LAS 09/261 LAS NAV VOR 102-170 BEYOND 22NM SFC-12000FT UNUSABLE 2509262225-2609262359
9/26/25
2222Z
9/26/26
2359Z
!LAS 09/260 LAS NAV VOR BEYOND 40NM UNUSABLE 2509262222-2609262359
4/6/25
0000Z
3/30/26
2359Z
!LAS 04/038 LAS AIRSPACE UAS WI AN AREA DEFINED AS .1NM RADIUS OF 360132N1151102W (4NM SW LAS) SFC-400FT AGL 2504060000-2603302359
FDC
2/23/26
1600Z
!FDC 6/8037 LAS IAP HARRY REID INTL, LAS VEGAS, NV.
VOR RWY 26L/R, AMDT 4B...
VOR/DME-A, ORIG-E...
PROCEDURE NA EXCEPT FOR ACFT EQUIPPED WITH SUITABLE RNAV SYSTEM WITH GPS,
LAS VORTAC OUT OF SERVICE. 2602231600-2603021341EST
2/23/26
1600Z
!FDC 6/8036 LAS SID HARRY REID INTL, LAS VEGAS, NV.
MCCARRAN EIGHT DEPARTURE...
DEPARTURE PROCEDURE TAKE-OFF RUNWAYS 26L/R NA EXCEPT FOR ACFT EQUIPPED WITH SUITABLE RNAV SYSTEM WITH GPS,
LAS VORTAC OUT OF SERVICE. 2602231600-2603021341EST
2/23/26
1600Z
!FDC 6/8035 LAS SID HARRY REID INTL, LAS VEGAS, NV.
HOOVER EIGHT DEPARTURE...
DEPARTURE PROCEDURE TAKE-OFF RUNWAYS 26L/R NA EXCEPT FOR ACFT EQUIPPED WITH SUITABLE RNAV SYSTEM WITH GPS.
DOVE CREEK TRANSITION NA EXCEPT FOR ACFT EQUIPPED WITH SUITABLE RNAV SYSTEM WITH GPS,
LAS VORTAC OUT OF SERVICE. 2602231600-2603021341EST
2/22/26
0951Z
3/22/26
0951Z
!FDC 6/7976 LAS SID HARRY REID INTL, LAS VEGAS, NV.
MCCARRAN EIGHT DEPARTURE...
TWENTYNINE PALMS TRANSITION NA EXCEPT FOR ACFT EQUIPPED WITH SUITABLE RNAV SYSTEM WITH GPS,
GFS VOR OUT OF SERVICE. 2602220951-2603220951EST
2/20/26
0647Z
3/22/26
0647Z
!FDC 6/7343 LAS SID HARRY REID INTL, LAS VEGAS, NV.
HOOVER EIGHT DEPARTURE...
DEPARTURE PROCEDURE.
BAVPE TRANSITION NA EXCEPT FOR ACFT EQUIPPED WITH SUITABLE RNAV SYSTEM WITH GPS,
PGS VOR OUT OF SERVICE. 2602200647-2603220647EST
2/19/26
2100Z
2/27/26
2218Z
!FDC 6/6335 LAS SID HARRY REID INTL, LAS VEGAS, NV.
HOOVER EIGHT DEPARTURE...
DRAKE TRANSITION, PEACH SPRINGS TRANSITION NA EXCEPT FOR ACFT EQUIPPED WITH SUITABLE RNAV SYSTEM WITH GPS,
PGS VOR/DME OUT OF SERVICE. 2602192100-2602272218EST
2/17/26
1931Z
!FDC 6/5265 LAS IAP HARRY REID INTL, LAS VEGAS, NV.
ILS OR LOC RWY 1L, AMDT 4...
S-ILS 1L DA 2527/HAT 351, VIS 1 ALL CATS.
CIRCLING CAT A MDA 3040/HAA 859.
LOC MAP I-CUA 1.7 DME. S-LOC 1L VIS ALL CATS 1 1/2. VDP NA.
NOTE PROFILE NOTE: I-CUA LOC UNUSABLE 0.20 NM FROM THRESHOLD.
DISREGARD NOTE: FOR INOP ALS, INCREASE S-ILS 1L ALL CATS VISIBILITY 7/8 SM.
2602171931-2609291931EST
2/16/26
2100Z
!FDC 6/4518 LAS IAP HARRY REID INTL, LAS VEGAS, NV.
RNAV (RNP) RWY 8R, ORIG...
RNP .30 DA 2689/HAT 532, VIS 1 1/2 ALL CATS.
TEMP CRANE 2376 MSL, 1.2NM W OF RWY 8R (2025-AWP-19068-OE).
2602162100-2604301658EST
2/16/26
2100Z
!FDC 6/4514 LAS ODP HARRY REID INTL, LAS VEGAS, NV.
TAKEOFF MINIMUMS AND (OBSTACLE) DEPARTURE PROCEDURES AMDT 8...
TAKE-OFF MINIMUMS: RWY 26L, STANDARD WITH MINIMUM CLIMB OF 300FT PER NM TO 2900.. RWY 26R, 500-2 3/4 OR STD WITH A MINIMUM CLIMB OF 295 FEET PER NM TO 2900. TEMPORARY CRANE 2.2NM FROM DER, ON CENTERLINE, 300FT AGL/ 2680FT MSL (2025-AWP-3755-OE). TEMPORARY CRANE 1.2NM FROM DER, 2100FT LEFT OF CENTERLINE, 112 AGL/2376 MS (2025-AWP-19068-OE).
ALL OTHER DATA REMAINS AS PUBLISHED. 2602162100-2604301655EST
12/22/25
1805Z
!FDC 5/2605 LAS IAP HARRY REID INTL, LAS VEGAS, NV.
ILS Y OR LOC Y RWY 26L, ORIG...
ILS Y OR LOC Y RWY 26R, ORIG...
ILS Z OR LOC Z RWY 26L, AMDT 8...
ILS Z OR LOC Z RWY 26R, AMDT 21...
RNAV (GPS) RWY 1R, AMDT 5...
RNAV (GPS) Y RWY 19L, AMDT 3A...
RNAV (GPS) Y RWY 19R, AMDT 3B...
VOR RWY 26L/R, AMDT 4B...
CIRCLING CAT A MDA 3040/HAA 859.
2512221805-2608031804EST
12/6/25
2300Z
!FDC 5/5551 LAS IAP HARRY REID INTL, LAS VEGAS, NV.
VOR/DME-A, ORIG-E...
CIRCLING CATS B MDA 3200/HAT 1017, VSI CAT B 1 1/2. TEMP CRANES 2845 MSL, 2.6 NM N OF KLAS AIRPORT (2025-AWP-178 THRU 182-OE)..
2512062300-2611302046EST
12/6/25
2300Z
!FDC 5/5550 LAS IAP HARRY REID INTL, LAS VEGAS, NV.
ILS Y OR LOC Y RWY 26L, ORIG...
ILS Y OR LOC Y RWY 26R, ORIG...
ILS Z OR LOC Z RWY 26L, AMDT 8...
ILS Z OR LOC Z RWY 26R, AMDT 21...
RNAV (GPS) RWY 1R, AMDT 5...
RNAV (GPS) Y RWY 19L, AMDT 3A...
RNAV (GPS) Y RWY 19R, AMDT 3B...
VOR RWY 26L/R, AMDT 4B...
CIRCLING CATS B/C MDA 3200/HAT 1017, VSI CAT B 1 1/2, CAT C 3.
TEMP CRANES 2845 MSL, 2.6 NM N OF KLAS AIRPORT (2025-AWP-178 THRU 182-OE).
2512062300-2611302046EST
9/10/25
1351Z
!FDC 5/1012 LAS ODP HARRY REID INTL, LAS VEGAS, NV.
TAKEOFF MINIMUMS AND (OBSTACLE) DEPARTURE PROCEDURES AMDT 8...
TAKE-OFF MINIMUMS: RWY 1L, 300-1 OR STANDARD WITH MINIMUM CLIMB OF 338 FT/NM TO 2300. RWY 19L, STANDARD WITH MINIMUM CLIMB OF 276 FT/NM TO 490. RWY 26R, 400-2 1/2 OR STANDARD WITH MINIMUM CLIMB OF 272 FT/NM TO 2400.
ALL OTHER DATA REMAINS AS PUBLISHED. 2509101351-2709101351EST
7/31/25
2300Z
!FDC 5/9079 LAS ODP HARRY REID INTL, LAS VEGAS, NV.
TAKEOFF MINIMUMS AND (OBSTACLE) DEPARTURE PROCEDURES AMDT 8...
ADD TAKEOFF OBSTACLE NOTE: RWY 19R, SIGN 2136FT FROM DER, 1029FT RIGHT OF CENTERLINE, 70FT AGL/ 2289FT MSL (2022-AWP-24232-OE).
ADD TAKEOFF OBSTACLE NOTE: RWY 26L, SIGN 4474FT FROM DER, 880FT LEFT OF CENTERLINE, 70FT AGL/ 2289FT MSL (2022-AWP-24232-OE).
ALL OTHER DATA REMAINS AS PUBLISHED. 2507312300-2707312254EST
7/11/25
1527Z
!FDC 5/7019 LAS IAP HARRY REID INTL, LAS VEGAS, NV.
VOR/DME-A, ORIG-E...
PROCEDURE NA.
2507111527-2707111526EST
6/24/25
1747Z
!FDC 5/8248 LAS SID HARRY REID INTL, LAS VEGAS, NV.
HOOVER EIGHT DEPARTURE...
DISREGARD NOTE: TURBOJETS ONLY. ALL OTHER DATA REMAINS AS PUBLISHED. 2506241747-2706241747EST
9/11/24
1402Z
!FDC 4/3822 LAS IAP HARRY REID INTL, LAS VEGAS, NV.
VOR/DME-A, ORIG-E...
ALTERNATE MINIMUMS: CAT A, B 900-2, CAT C 1100-3, CAT D 1400-3.
2409111402-2609111402EST
Yes
ALL
CLARK COUNTY
P O BOX 11005
LAS VEGAS, NV 89111
Phone: 702-261-5211
BRIAN FREEBURG
5757 WAYNE NEWTON BLVD
LAS VEGAS, NV 89119
Phone: 702-261-5333
RENO FSS (RNO)
Toll Free: 1-800-WX-BRIEF
LAS
Sunset to Sunrise
--
N/A
Yes - Lighted
No
No
Hanger, Tie-Down
Landing Rights Airport
NOT an Airport of Entry
Major
Major
High Pressure
High & Low Pressure
Air Freight
Air Ambulance
Avionics
Cargo Handling
Charter Service
Pilot Instruction
Aircraft Rental
Aircraft Sales
Annual Surveying

Runway 01L/19R

9770 ft. x 150 ft.
CONC
Good
GRVD
HIGH

120,000lbs
250,000lbs
550,000lbs
1,120,000lbs
  Runway 01L Runway 19R
True Heading 25°205°
Traffic Pattern Left Right
Markings PIR NPI
Markings Condition GOOD GOOD
Latitude 36° 04' 31"N 36° 05' 59"N
Longitude 115° 10' 13"W 115° 09' 23"W
Elevation 2,181' 2,082'
Threshold Crossing Height 63 ft. AGL 80 ft. AGL
Visual Glide Path Angle 3.4° 3.04°
Visual Slope Indicator P4L P4L
Approach Lights MALSF
Centerline Lights No No
Runway End Identifier Lights No Yes

Runway 01R/19L

9769 ft. x 150 ft.
CONC
Good
GRVD
MED

120,000lbs
250,000lbs
550,000lbs
1,120,000lbs
  Runway 01R Runway 19L
True Heading 25°205°
Traffic Pattern Right Left
Markings NPI NPI
Markings Condition GOOD GOOD
Latitude 36° 04' 27"N 36° 05' 55"N
Longitude 115° 10' 03"W 115° 09' 13"W
Elevation 2,175' 2,078'
Threshold Crossing Height 76 ft. AGL 75 ft. AGL
Visual Glide Path Angle 3° 3°
Visual Slope Indicator P4L P4L
Approach Lights
Centerline Lights No No
Runway End Identifier Lights Yes Yes

Runway 08L/26R

14835 ft. x 150 ft.
CONC
Good
GRVD
HIGH

120,000lbs
250,000lbs
550,000lbs
1,120,000lbs
  Runway 08L Runway 26R
True Heading 90°270°
Traffic Pattern Left Left
Markings NPI PIR
Markings Condition GOOD GOOD
Latitude 36° 04' 35"N 36° 04' 35"N
Longitude 115° 10' 17"W 115° 07' 16"W
Elevation 2,183' 2,033'
Threshold Crossing Height 76 ft. AGL 84 ft. AGL
Visual Glide Path Angle 3° 3°
Visual Slope Indicator P4L P4L
Approach Lights MALS
Centerline Lights No No
Runway End Identifier Lights No No

Runway 08R/26L

10526 ft. x 150 ft.
CONC
Excellent
GRVD
HIGH

120,000lbs
250,000lbs
550,000lbs
1,120,000lbs
  Runway 08R Runway 26L
True Heading 90°270°
Traffic Pattern
Markings NPI PIR
Markings Condition GOOD GOOD
Latitude 36° 04' 25"N 36° 04' 25"N
Longitude 115° 09' 41"W 115° 07' 33"W
Elevation 2,157' 2,048'
Threshold Crossing Height 61 ft. AGL 84 ft. AGL
Visual Glide Path Angle 3° 3°
Visual Slope Indicator P4L P4L
Approach Lights MALSF
Centerline Lights
Runway End Identifier Lights Yes
A110-1EXTSV GLDR/SOARING OPNS WKENDS & HOLS; SR-SS; LAS R187/020; ALTS UP TO BUT NOT INCLG FL180. GLDRS RMN CLEAR OF THE TCA BUT OTHERWISE OPR WI THE ENTIRE SW QUAD OF THE TCA VEIL.
A110-10LGTD GOLF RANGE 1400 FT S OF RWYS 01L/19R AND 01R/19L.
A110-11TIEDOWN FEE.
A110-13(E98) PLUS 64 SHELTERS & 24 SHEDS.
A110-2ALL NON-STD RWY OPNS PPR FM DEPT OF AVN.
A110-20ACFT USING FULL LEN DEP ON RWY 08L USE MINIMAL PWR TIL PASSING THE PWR-UP POINT ON RWY. PWR-UP POINT IS 348 FT EAST OF BLAST PAD AND MKD WITH SIGN AND STD MARKINGS FOR BGNG OF RWY.
A110-25LRG NR OF BIRDS AND BATS INVOF OF ARPT BTWN SS AND SR.
A110-28ACFT DEPG RWY 19R USE MINIMAL PWR UNTIL PASSING THE RWY THLD. RWY 19R THLD HAS STD RWY MARKINGS AND IS 780 FT S OF THE BLAST PAD.
A110-3TBJT DEPS NOT PMTD ON RWY 01R/19L OR RWY 01L/19R 2000-0800. XCPNS FOR WX OR OPNL NECESSITY.
A110-30ACFT OPER NEAR THE INT OF TWYS S, D, G AND THE N END OF TWY Z SHOULD BE ALERT AS THERE ARE CLOSELY ALIGNED TWY CNTRLN AND RADIUS TURNS.
A110-31ACFT THAT DEP FULL LENGTH OF RWYS 01L AND 08L MUST HOLD AT THE SAME HOLD LINE AS THERE IS NO ROOM TO HOLD BTN THE RWY ENDS AND SUCH ACFT SHOULD VERIFY THAT THEY ARE ON THE CORRECT RWY.
A110-32CUST PPR - 702-739-1100/702-736-1830/702-730-6071. GA CUST RSVNS 12 HR PPR. GA CUST & IMG LCT W SIDE BTN FBOS.
A110-33WINGSPAN GTR THAN 135 FT PPR FM DEPT OF AVN TO USE TWY H.
A110-34NMRS HOP ON WEST SIDE OF ARPT.
A110-38ACFT TAX WB ON TWY B NEAR TWY E USE CARE NOT TO ENTER THE RWY ON TWY Y, ACFT TAX WB ON TWY W NEAR TWY E USE CARE NOT TO ENTER THE RWY ON TWY U.
A110-4ACFT MAY EXPERIENCE REFLECTION OF SUN FM GLASS HOTELS LCTD NW OF ARPT. REFLECTION MAY OCCUR AT VARIOUS ALTS, HDGS, & DSTCS FM ARPT.
A110-41RWY STS LGTS ARE IN OPN.
A110-42PLA AUZD BTN 0200 & 0600.
A110-43CTN PAJA INVOF ARPT.
A110-44WHEN SPL EVENT PRKG PPR PROGRAM NOTAM IS ACTV, TSNT ACFT OPERS NOT PERM BASED NEED TO OBTAIN A PPR NR FM AN FBO FOR EA LDG. PPR APPVL & CONFIRMATION NRS CAN BE OBTAINED FM THE SEL FBO AT 702-261-7775. PPR CONFIRMATION NRS SHOULD BE ENTERED IN THE RMKS SECTION OF EACH FLT PLAN.
A110-45ALL ACFT CTC RAMP CTL ON FREQ 124.4 FOR OPS AT A, B, C GATES, AND GA, CUSTOMS; CTC RAMP CTL FREQ 127.9 FOR OPNS AT D AND E GATES AND CARGO RAMP PRIOR TO ENTERING RAMP OR PUSHING BACK FM GATE OR PRKG SPOT. RAMP CTL OPR HRS 0500-0100L. WHEN RAMP IS CLSD (0100-0500L) BROADCAST ALL NON-MOVEMENT AREA OPNS ON UNICOM 122.95.
A110-46PILOTS CONDUCTING EFVS OPS; BE AWARE LED ALS IN USE RWY 26L.
A110-6GA PRKG VERY LTD. FOR PRKG AVAILABILITY CTC EITHER FBO (702) 736-1830 OR (702) 739-1100.
A110-8RWY 08L 589 FT CWY; RWY 26R 645 FT CWY.
A14JAMES CHRISLY 702-261-5125. 24 HR OPS - 702-261-5605/5211.
A39-01L/19RPCR VALUE: 1090/R/B/W/T
A39-01R/19LPCR VALUE: 1230/R/B/W/T
A39-08L/26RPCR VALUE: 1130/R/C/W/T
A39-08R/26LPCR VALUE: 1150/R/B/W/T
A43-26LPAPI UNUSBL BYD 8 DEGS LEFT AND 9 DEGS RIGHT OF CNTRLN.
A57-01LAPCH RATIO 34:1 TO DTHR.
A57-01RAPCH RATIO 23:1 TO DTHR.
A57-08LAPCH RATIO 50:1 TO DTHR.
A57-19LAPCH RATIO 50:1 TO DTHR.
A57-19RAPCH RATIO 20:1 TO DTHR.
HARRY REID INTL (ICAO: KLAS, IATA: LAS) is a public airport located in LAS VEGAS, NV, US.
