10/21/25 1403Z | 10/31/27 1403Z | | !FDC 5/3762 LBT PART 1 OF 3 ODP LUMBERTON RGNL, LUMBERTON, NC.
TAKEOFF MINIMUMS AND (OBSTACLE) DEPARTURE PROCEDURES AMDT 3...
TAKE-OFF MINIMUMS RWY 31: 300-1 1/8 OR STANDARD WITH MINIMUM CLIMB
OF 251 FT PER NM T0 400, OR ALTERNATIVELY. WITH STANDARD TAKEOFF
MINIMUMS AND A NORMAL 200FT PER NM CLIMB GRADIENT, TAKEOFF MUST
OCCUR NO LATER THAN 2100 FT PRIOR TO DER.
TAKEOFF OBSTACLE NOTES: NOTE: RWY 05: LIGHT POLES, UTILITY BUILDING
BEGINNING 11 FT FROM DER, 115 FT LEFT OF CENTERLINE, UP TO 2 FT
AGL/124 FT MSL. TREE 92 FT FROM DER, 496 FT RIGHT OF CENTERLINE,
171 FT MSL. TREE, POLE, BUILDING BEGINNING 94 FT FROM DER, 254 FT
RIGHT OF CENTERLINE, UP TO 192 FT MSL. TREE 1463 FT FROM DER, 781
FT LEFT OF CENTERLINE, 168 FT MSL. TREE 1563 FT FROM DER, 743 FT
LEFT OF CENTERLINE, 182 FT MSL. TREES BEGINNING 1682 FT FROM DER,
649 FT LEFT OF CENTERLINE, UP TO 212 FT MSL. TREE 1685 FT FROM DER,
932 FT RIGHT OF CENTERLINE, 205 FT MSL. TREES BEGINNING 1697 FT
FROM DER, 612 FT RIGHT OF CENTERLINE, UP TO 210 FT MSL. TREES
BEGINNING 1774 FT FROM DER, 254 FT RIGHT OF CENTERLINE, UP TO 220
FT MSL. TREE, VEHICLE ON ROAD BEGINNING 1812 FT FROM DER, 104 FT
LEFT OF CENTERLINE, UP TO 219 FT MSL. TREES BEGINNING 1817 FT FROM
DER, 357 FT RIGHT OF CENTERLINE, UP TO 221 FT MSL. TREES BEGINNING
1856 FT FROM DER, 212 FT RIGHT OF CENTERLINE, UP TO 223 FT MSL.
2510211403-2710311403EST
END PART 1 OF 3
!FDC 5/3762 LBT PART 2 OF 3 ODP LUMBERTON RGNL, LUMBERTON, NC.
TAKEOFF OBSTACLE NOTES: NOTE: RWY 13: FENCE 2 FT FROM DER, 264 FT
RIGHT OF CENTERLINE, 8 FT AGL/129 FT MSL. TREE, FENCE, POLE
BEGINNING 55 FT FROM DER, 24 FT LEFT OF CENTERLINE, UP TO 222 FT
MSL. VEHICLE ON ROAD, FENCE BEGINNING 75 FT FROM DER, 123 FT RIGHT
OF CENTERLINE, UP TO 136 FT MSL. TREES BEGINNING 302 FT FROM DER, 1
FT RIGHT OF CENTERLINE, UP TO 152 FT MSL. TREES BEGINNING 466 FT
FROM DER, 119 FT RIGHT OF CENTERLINE, UP TO 161 FT MSL. TREE 714 FT
FROM DER, 289 FT RIGHT OF CENTERLINE, 164 FT MSL. TREE 837 FT FROM
DER, 421 FT RIGHT OF CENTERLINE, 186 FT MSL. TREE 921 FT FROM DER,
546 FT RIGHT OF CENTERLINE, 200 FT MSL. TREES BEGINNING 954 FT FROM
DER, 487 FT RIGHT OF CENTERLINE, UP TO 208 FT MSL.
TAKEOFF OBSTACLE NOTES: NOTE: RWY 23: TREE 59 FT FROM DER, 435 FT
RIGHT OF CENTERLINE, 130 FT MSL. TREE 1132 FT FROM DER, 766 FT
RIGHT OF CENTERLINE, 155 FT MSL. TREES BEGINNING 1880 FT FROM DER,
861 FT LEFT OF CENTERLINE, UP TO 201 FT MSL. TREE 2059 FT FROM DER,
870 FT LEFT OF CENTERLINE, 209 FT MSL. TREES BEGINNING 2149 FT FROM
DER, 870 FT LEFT OF CENTERLINE, UP TO 210 FT MSL. TREE 2277 FT FROM
DER, 889 FT RIGHT OF CENTERLINE, 193 FT MSL. TREE 2455 FT FROM DER,
916 FT RIGHT OF CENTERLINE, 209 FT MSL. TREE 2633 FT FROM DER, 964
FT RIGHT OF CENTERLINE, 219 FT MSL. TREE 2704 FT FROM DER, 1176 FT
2510211403-2710311403EST
END PART 2 OF 3
!FDC 5/3762 LBT PART 3 OF 3 ODP LUMBERTON RGNL, LUMBERTON, NC.
RIGHT OF CENTERLINE, 220 FT MSL. TREES BEGINNING 2708 FT FROM DER,
20 FT RIGHT OF CENTERLINE, UP TO 228 FT MSL. TREES BEGINNING 2958
FT FROM DER, 33 FT LEFT OF CENTERLINE, UP TO 226 FT MSL. TREE 3819
FT FROM DER, 841 FT LEFT OF CENTERLINE, 227 FT MSL. TREE 4126 FT
FROM DER, 437 FT RIGHT OF CENTERLINE, 239 FT MSL. TREES BEGINNING
4162 FT FROM DER, 332 FT RIGHT OF CENTERLINE, UP TO 243 FT MSL.
TAKEOFF OBSTACLE NOTES: NOTE: RWY 31: TREE, SIGN BEGINNING 77 FT
FROM DER, 155 FT RIGHT OF CENTERLINE, UP TO 180 FT MSL. TREE 196 FT
FROM DER, 394 FT LEFT OF CENTERLINE, 144 FT MSL. TREE 525 FT FROM
DER, 411 FT LEFT OF CENTERLINE, 147 FT MSL. TREE, SIGN, POLE
BEGINNING 981 FT FROM DER, 414 FT LEFT OF CENTERLINE, UP TO 171 FT
MSL. TREE 1338 FT FROM DER, 381 FT RIGHT OF CENTERLINE, 199 FT MSL.
TREE 1391 FT FROM DER, 579 FT RIGHT OF CENTERLINE, 208 FT MSL. TREE
1403 FT FROM DER, 864 FT RIGHT OF CENTERLINE, 211 FT MSL. TREES
BEGINNING 1467 FT FROM DER, 254 FT RIGHT OF CENTERLINE, UP TO 219
FT MSL. TREE 1929 FT FROM DER, 615 FT LEFT OF CENTERLINE, 225 FT
MSL. TOWER, ANTENNA BEGINNING 5168 FT FROM DER, 1711 FT RIGHT OF
CENTERLINE, UP TO 150 FT AGL/286 FT MSL.
2510211403-2710311403EST
END PART 3 OF 3
|
