12/3/25 1345Z | | | !FDC 5/3632 LHV PART 1 OF 3 ODP WILLIAM T PIPER MEML,
LOCK HAVEN, PA.
TAKEOFF MINIMUMS AND (OBSTACLE) DEPARTURE PROCEDURES AMDT 1...
DEPARTURE PROCEDURE. TAKEOFFMINIMUMS: RWY 27R: STANDARD WITH
MINIMUM CLIMB OF 407 FT/NM TO 2500 OR 2400-3 FOR VCOA.
TEXTUAL DEPARTURE PROCEDURES: RWY 27R CLIMB ON HEADING 273.33 TO
2500 BEFORE PROCEEDING ON COURSE.
VISUAL CLIMB OVER AIRPORT: RWY 27R: OBTAIN ATC APPROVAL FOR VCOA
WHEN REQUESTING IFR CLEARANCE. CLIMB IN VISUAL CONDITIONS TO CROSS
WILLIAM T. PIPER MEMORIAL AIRPORT AT OR ABOVE 2800 BEFORE
PROCEEDING ON COURSE.
TAKEOFF OBSTACLE NOTE:
RWY 27R: UTILITY BUILDING 9 FT FROM DER, 124 FT RIGHT OF
CENTERLINE, 5 FT AGL/559 FT MSL.
UTILITY BUILDING 9 FT FROM DER, 125 FT LEFT OF CENTERLINE, 4 FT
AGL/558 FT MSL.
BUILDING 50 FT FROM DER, 415 FT RIGHT OF CENTERLINE, 20 FT AGL/577
FT MSL.
FENCE, TREE BEGINNING 50 FT FROM DER, 231 FT LEFT OF CENTERLINE, UP
TO 9 FT AGL/564 FT MSL.
POLE 132 FT FROM DER, 349 FT RIGHT OF CENTERLINE, 28 FT AGL/585 FT
MSL.
1A. 2512031345-PERM
END PART 1 OF 3
!FDC 5/3632 LHV PART 2 OF 3 ODP WILLIAM T PIPER MEML,
LOCK HAVEN, PA.
TREE 151 FT FROM DER, 303 FT LEFT OF CENTERLINE, 572 FT MSL.
BUILDING 181 FT FROM DER, 537 FT RIGHT OF CENTERLINE, 29 FT AGL/587
FT MSL.
TREE 259 FT FROM DER, 340 FT RIGHT OF CENTERLINE, 612 FT MSL.
TREE, VEHICLE ON ROAD BEGINNING 269 FT FROM DER, 6 FT RIGHT OF
CENTERLINE, UP TO 630 FT MSL.
BUILDINGS, POLES, VEHICLE ON ROAD BEGINNING 493 FT FROM DER, 16 FT
LEFT OF CENTERLINE, UP TO 57 FT AGL/611 FT MSL.
TREE, BUILDING, BUILDING, POLE BEGINNING 650 FT FROM DER, 77 FT
RIGHT OF CENTERLINE, UP TO 640 FT MSL.
TREE, BUILDING, POLE, BUILDING BEGINNING 831 FT FROM DER, 134 FT
LEFT OF CENTERLINE, UP TO 620 FT MSL.
TREE, POLE, BUILDING, BUILDING BEGINNING 906 FT FROM DER, 9 FT
RIGHT OF CENTERLINE, UP TO 642 FT MSL.
TREE, BUILDING, POLE BEGINNING 1154 FT FROM DER, 23 FT LEFT OF
CENTERLINE, UP TO 623 FT MSL.
TREE, TOWER BEGINNING 1672 FT FROM DER, 21 FT LEFT OF CENTERLINE,
UP TO 631 FT MSL.
TREES BEGINNING 2409 FT FROM DER, 10 FT RIGHT OF CENTERLINE, UP TO
643 FT MSL.
1A. 2512031345-PERM
END PART 2 OF 3
!FDC 5/3632 LHV PART 3 OF 3 ODP WILLIAM T PIPER MEML,
LOCK HAVEN, PA.
BUILDING 3477 FT FROM DER, 1403 FT RIGHT OF CENTERLINE, 667 FT MSL.
TREES, VEHICLE ON ROAD BEGINNING 1.3 NM FROM DER, 1544 FT RIGHT OF
CENTERLINE, 847 FT MSL.
TREES, VEHICLE ON ROAD BEGINNING 1.4 NM FROM DER, 1284 FT RIGHT OF
CENTERLINE, UP TO 927 FT MSL.
TREES, VEHICLE ON ROAD BEGINNING 1.5 NM FROM DER, 1031 FT RIGHT OF
CENTERLINE, UP TO 951 FT MSL.
TREE, TOWER BEGINNING 1.7 NM FROM DER, 128 FT RIGHT OF CENTERLINE,
UP TO 1021 FT MSL.
TREES BEGINNING 2.4 NM FROM DER, 2162 FT RIGHT OF CENTERLINE, UP TO
1063 FT MSL.
TREE 2.5 NM FROM DER, 1879 FT RIGHT OF CENTERLINE, 1066 FT MSL.
THIS IS TAKEOFF MINIMUMS AND (OBSTACLE) DEPARTURE PROCEDURES, AMDT
1A. 2512031345-PERM
END PART 3 OF 3
|
