KLNN
ICAO KLNNIATA LNNLocal LNN
LAKE COUNTY EXEC
PublicPUB

3 miles NNE of WILLOUGHBY, OH, US
View on Map
LiveATC.net: Live Air Traffic - From Their Headsets to You
Status
Operational
Coordinates
41° 41' 02"N 81° 23' 23"W
Elevation
626' MSL
Pattern Alt
1626' MSL
Mag Variation
9°W
Declination
8°W
Fuel
JET A, 100LL
FSS
CLEVELAND (CLE)
Sectional
DETROIT
ARTCC
CLEVELAND (ZOB)
Data Effective
10/1/26-10/29/26
KLNN VFR
2:35 PM EDT
Clear
10sm
62°F
46°F
30.23"Hg
320° 5kts
AO1 T01670076
METAR KLNN 221835Z AUTO 32005KT 10SM CLR 17/08 A3023 RMK AO1 T01670076
+ Add Your Business

KLNN FBOs

Promote Listing
Classic Jet Center
UNICOM: 122.725
Phone: (440) 942-7092
No Rating Available
0 Reviews (Read | Sign In To Write)
Avfuel
As of 10/21
 100LL JET A JET A (FSII) MOGAS UL94
Self Serve
Full Serve 9.15 8.85 8.97
Fuel Notes
Prices include tax

KLNN Aircraft Service & Maintenance

Promote Listing
TT Electronics Integrated Manufacturing Services Inc.
Phone: (440) 358-5202
No Rating Available
0 Reviews (Read | Sign In To Write)
X

Send Message to Airport Company
Enter your information and message below.

Your Information

Processing

Weather and Advisory

AWOS-3PT 119.225
(440) 942-0809

Common

CTAF 122.725
ACTVT REIL RWY 05, 23, 10, & 28; MIRL RWY 05/23 & 10/28 - CTAF. PAPI RWY 05, 23, 10, & 28 OPR CONSLY.
UNICOM 122.725

Arrival

BRWNZ STAR 126.55
ROKNN STAR 126.55
ROLLN STAR 126.55
TRYBE STAR 126.55

Approach

CLEVELAND APPROACH 125.35

Departure

CLEVELAND DEPARTURE 125.35

Terminal Area Forecast

KCLE (27nm)
Thu, 10/22 1:29 PM EDT
Thu, 10/22 2:00 PM EDT - Fri, 10/23 8:00 PM EDT
VFR
2:00 PM EDT - 8:00 PM EDT
Few 25,000'
6sm
360° 6kts
VFR
8:00 PM EDT - 2:00 PM EDT
Sky Clear
6sm
VRB° 3kts
VFR
2:00 PM EDT - 8:00 PM EDT
Few 20,000'
6sm
030° 7kts
TAF KCLE 221729Z 2218/2324 36006KT P6SM FEW250
   FM230000 VRB03KT P6SM SKC
   FM231800 03007KT P6SM FEW200
KLNN
EffectiveExpiresCategoryNOTAM
Domestic
10/22/26
2359Z
Runway!LNN 10/006 LNN RWY 23 PAPI U/S 2610222359-2704222111EST
10/22/26
2359Z
Runway!LNN 10/005 LNN RWY 28 PAPI U/S 2610222359-2704222111EST
10/22/26
2359Z
Runway!LNN 10/004 LNN RWY 05 PAPI U/S 2610222359-2704222111EST
9/25/26
1735Z
12/26/26
0459Z
Runway!LNN 09/014 LNN RWY 10/28 VASI U/S 2609251735-2612260459
9/22/26
2111Z
10/22/26
2359Z
Runway!LNN 09/012 LNN RWY 23 PAPI U/S 2609222111-2610222359
9/22/26
2110Z
10/22/26
2359Z
Runway!LNN 09/011 LNN RWY 28 PAPI U/S 2609222110-2610222359
9/22/26
2110Z
10/22/26
2359Z
Runway!LNN 09/010 LNN RWY 05 PAPI U/S 2609222110-2610222359
9/11/26
2353Z
12/11/26
0053Z
!LNN 09/005 LNN OBST TOWER LGT (ASR 1238783) 414243.90N0812144.40W (2.1NM NE LNN) 766.1FT (160.1FT AGL) U/S 2609112353-2612110053
FDC
3/20/26
1527Z
!FDC 6/1677 LNN IAP LAKE COUNTY EXEC, WILLOUGHBY, OH.
RNAV (GPS) RWY 5, ORIG-D...
PROCEDURE NA.
2603201527-2610301527EST
No
0700-2100
FOR ATTENDANT OR FUEL SVC AFT HRS CALL 440-942-7092, 2300-0600 BY PRIOR ARNGMT ONLY.
LAKE DEVELOPMENT AUTHORITY
105 MAIN ST STE B-501
PAINESVILLE, OH 44077
Phone: 440-350-5342
NICHOLAS BELLUARDO
1825 LOST NATION RD
WILLOUGHBY, OH 44094
Phone: 440-350-5343
CLEVELAND FSS (CLE)
Toll Free: 1-800-WX-BRIEF
LNN
--
ACTVT REIL RWY 05, 23, 10, & 28; MIRL RWY 05/23 & 10/28 - CTAF. PAPI RWY 05, 23, 10, & 28 OPR CONSLY.
N/A
Yes - Lighted
Yes
Yes
Hanger, Tie-Down
NOT a Landing Rights Airport
NOT an Airport of Entry
Major
Major
None
High & Low Pressure
Avionics
Charter Service
Pilot Instruction
Aircraft Rental

Runway 05/23

5028 ft. x 100 ft.
ASPH
Good
NONE
MED

68,000lbs
80,000lbs
124,000lbs
--
  Runway 05 Runway 23
True Heading 45°225°
Traffic Pattern Left Left
Markings NPI NPI
Markings Condition GOOD GOOD
Latitude 41° 40' 50"N 41° 41' 25"N
Longitude 81° 23' 51"W 81° 23' 04"W
Elevation 624' 620'
Threshold Crossing Height 40 ft. AGL 54 ft. AGL
Visual Glide Path Angle 3.5° 4°
Visual Slope Indicator P4L P4L
Approach Lights
Centerline Lights No No
Runway End Identifier Lights Yes Yes

Runway 10/28

4272 ft. x 100 ft.
ASPH
Fair
NONE
MED

68,000lbs
80,000lbs
124,000lbs
--
  Runway 10 Runway 28
True Heading 91°271°
Traffic Pattern Left Left
Markings NPI NPI
Markings Condition GOOD GOOD
Latitude 41° 40' 57"N 41° 40' 57"N
Longitude 81° 23' 46"W 81° 22' 50"W
Elevation 624' 624'
Threshold Crossing Height 47 ft. AGL 26 ft. AGL
Visual Glide Path Angle 3.5° 3.5°
Visual Slope Indicator P2L P2L
Approach Lights
Centerline Lights No No
Runway End Identifier Lights Yes Yes
A110-1DEER, BIRDS, & OTR WILDLIFE ON & INVOF ARPT.
A110-3PAT WORK NA 2300-0800.
A110-4FOR CD CTC CLEVELAND APCH AT 216-352-2323.
A16CELL 330-903-0132.
A17-M1FOR ATTENDANT OR FUEL SVC AFT HRS CALL 440-942-7092, 2300-0600 BY PRIOR ARNGMT ONLY.
A24LDG FEE FOR ALL COML ACFT BY WT; MULTI-ENG & LRGR.
A57-05ALSO 28:1 OVR +85 FT TREES, 2616 FT DIST, 420 FT R.
A57-28APCH SLP 11:1 TO DTHR OVR +88 FT TREES, 984 FT DIST, 358 FT L.
A81-APTACTVT REIL RWY 05, 23, 10, & 28; MIRL RWY 05/23 & 10/28 - CTAF. PAPI RWY 05, 23, 10, & 28 OPR CONSLY.
LAKE COUNTY EXEC (ICAO: KLNN, IATA: LNN) is a public airport located in WILLOUGHBY, OH, US.
