10/3/25 1540Z | 10/3/27 1540Z | | !FDC 5/5893 MQS PART 1 OF 3 ODP CHESTER COUNTY G O CARLSON,
COATESVILLE, PA.
TAKEOFF MINIMUMS AND (OBSTACLE) DEPARTURE PROCEDURES ORIG...
TAKEOFF MINIMUMS: RWY 29, 300-2 1/4 OR STANDARD WITH A MINIMUM
CLIMB OF 204 FT/NM TO 1100, OR ALTERNATIVELY, WITH STANDARD TAKEOFF
MINIMUMS AND A NORMAL 200 FT/NM CLIMB GRADIENT, TAKEOFF MUST OCCUR
NO LATER THAN 1300 FEET PRIOR TO DER.
TAKEOFF OBSTACLE NOTES:
RWY 11: ELECTRICAL SYSTEM 9 FT FROM DER, 122 FT LEFT OF CENTERLINE,
2 FT AGL/661 FT MSL.
TREE 358 FT FROM DER, 458 FT LEFT OF CENTERLINE, 670 FT MSL.
TREE 540 FT FROM DER, 517 FT LEFT OF CENTERLINE, 685 FT MSL.
TREE 555 FT FROM DER, 623 FT LEFT OF CENTERLINE, 700 FT MSL.
TREES BEGINNING 656 FT FROM DER, 389 FT LEFT OF CENTERLINE, UP TO
702 FT MSL.
TREES BEGINNING 775 FT FROM DER, 420 FT LEFT OF CENTERLINE, UP TO
703 FT MSL.
TREES BEGINNING 847 FT FROM DER, 510 FT LEFT OF CENTERLINE, UP TO
709 FT MSL.
TREES BEGINNING 1149 FT FROM DER, 549 FT LEFT OF CENTERLINE, UP TO
710 FT MSL.
RWY 29: ELECTRICAL SYSTEM 9 FT FROM DER, 122 FT RIGHT OF
2510031540-2710031540EST
END PART 1 OF 3
!FDC 5/5893 MQS PART 2 OF 3 ODP CHESTER COUNTY G O CARLSON,
COATESVILLE, PA.
CENTERLINE, 2 FT AGL/639 FT MSL.
BUILDING, TERRAIN BEGINNING 25 FT FROM DER, 317 FT RIGHT OF
CENTERLINE, UP TO 17 FT AGL/655 FT MSL.
POLE, BUILDING BEGINNING 417 FT FROM DER, 547 FT RIGHT OF
CENTERLINE, UP TO 686 FT MSL.
BUILDINGS BEGINNING 505 FT FROM DER, 568 FT RIGHT OF CENTERLINE, UP
TO 691 FT MSL.
TREES, BUILDING BEGINNING 538 FT FROM DER, 518 FT RIGHT OF
CENTERLINE, UP TO 706 FT MSL.
TREES, POLES, BUILDINGS, TRAVERSE WAY, TRANSMISSION LINES, CATENARY
WIRES, TERRAIN BEGINNING 732 FT FROM DER, 207 FT RIGHT OF
CENTERLINE, UP TO 710 FT MSL.
BUILDINGS, POLES, TREES, TRAVERSE WAY BEGINNING 1795 FT FROM DER,
218 FT RIGHT OF CENTERLINE, UP TO 39 FT AGL/719 FT MSL.
TREES, BUILDING BEGINNING 2395 FT FROM DER, 276 FT RIGHT OF
CENTERLINE, UP TO 724 FT MSL.
TREES, BUILDING BEGINNING 2522 FT FROM DER, 202 FT RIGHT OF
CENTERLINE, UP TO 742 FT MSL.
TREE 2665 FT FROM DER, 337 FT RIGHT OF CENTERLINE, 87 FT AGL/743 FT
MSL.
2510031540-2710031540EST
END PART 2 OF 3
!FDC 5/5893 MQS PART 3 OF 3 ODP CHESTER COUNTY G O CARLSON,
COATESVILLE, PA.
TREES BEGINNING 2741 FT FROM DER, 193 FT RIGHT OF CENTERLINE, UP TO
80 FT AGL/744 FT MSL.
TREES BEGINNING 3053 FT FROM DER, 106 FT RIGHT OF CENTERLINE, UP TO
75 FT AGL/747 FT MSL.
TREE 3067 FT FROM DER, 5 FT LEFT OF CENTERLINE, 54 FT AGL/716 FT
MSL.
TREE, POLE BEGINNING 3112 FT FROM DER, 72 FT RIGHT OF CENTERLINE,
UP TO 82 FT AGL/756 FT MSL.
TREE 3202 FT FROM DER, 45 FT LEFT OF CENTERLINE, 60 FT AGL/721 FT
MSL.
TREE 3346 FT FROM DER, 85 FT LEFT OF CENTERLINE, 69 FT AGL/726 FT
MSL.
TREE 3433 FT FROM DER, 33 FT LEFT OF CENTERLINE, 71 FT AGL/728 FT
MSL.
TREES BEGINNING 4086 FT FROM DER, 856 FT RIGHT OF CENTERLINE, UP TO
758 FT MSL.
TREE 1.8 NM FROM DER, 2584 FT RIGHT OF CENTERLINE, 920 FT MSL.
2510031540-2710031540EST
END PART 3 OF 3
|
