KMSP
MINNEAPOLIS-ST PAUL INTL/WOLD-CHAMBERLAIN
PublicPUB

6 miles S of MINNEAPOLIS, MN
View on Map
LiveATC.net: Live Air Traffic - From Their Headsets to You
Operational
44° 52' 55"N 93° 13' 18"W
842' MSL
1842' MSL
00E
JET A, JET A+, CILI, 100LL
PRINCETON (PNM)
TWIN CITIES
MINNEAPOLIS (ZMP)
7/11/24-8/8/24
KMSP MVFR
3:53 AM CDT
Broken 1,300'
8sm
73°F
69°F
29.96"Hg
150° 7kts
AO2 SLP139 T02280206 58007
KMSP 270853Z 15007KT 8SM BKN013 23/21 A2996 RMK AO2 SLP139 T02280206 58007
Add Your Business

KMSP FBOs

Promote Listing
Signature Aviation
UNICOM: 122.95
Phone: (612) 726-5700
No Rating Available
0 Reviews (Read | Sign In To Write)
Other
As of 7/26
 100LL JET A JET A (FSII) MOGAS UL94
Self Serve
Full Serve 7.40 8.82 8.86
Fuel Notes
Prices include tax
X

Send Message to Airport Company
Enter your information and message below.

Your Information

Processing

Terminal Area Forecast

KMSP
Sat, 7/27 3:41 AM CDT
Sat, 7/27 4:00 AM CDT - Sun, 7/28 7:00 AM CDT
MVFR
4:00 AM CDT - 7:00 AM CDT
Broken 1,500'
6sm
150° 8kts
VFR
7:00 AM CDT - 12:00 PM CDT
Scattered 2,000'
6sm
170° 10kts
VFR
12:00 PM CDT - 9:00 PM CDT
Few 6,000'
6sm
190° 15kts
Gusts 23kts
VFR
9:00 PM CDT - 7:00 AM CDT
Scattered 25,000'
6sm
180° 12kts
KMSP 270841Z 2709/2812 15008KT P6SM BKN015
   FM271200 17010KT P6SM SCT020
   FM271700 19015G23KT P6SM FEW060
   FM280200 18012KT P6SM SCT250
KMSP
Domestic
8/1/241300Z !MSP 07/344 MSP SVC TAR/SSR U/S 2408011300-2408012100
7/29/241200Z !MSP 07/354 MSP AIRSPACE UAS WI AN AREA DEFINED AS 0.3NM RADIUS OF
445435N0932207W (6.3NM NE FCM) SFC-250FT AGL MON-SAT 1200-2000
2407291200-2408092000
7/26/241738Z !MSP 07/357 MSP TWY S BTN TWY D AND TWY S1 CLSD 2407261738-2409162300
7/26/241737Z !MSP 07/356 MSP TWY D BTN TWY C AND TWY S CLSD 2407261737-2409162300
7/23/241856Z !MSP 07/331 MSP RWY 12R/30L SAFETY AREA NOT STD 3IN LIP AT RWY 30L PAPI 2407231856-2410121900
7/23/240840Z !MSP 07/328 MSP RWY 12R/30L AT TWY A1 SAFETY AREA NOT STD NE EDGE 3IN LIP
2407230840-2408232300
7/19/241541Z !MSP 07/294 MSP OBST WATERTOWER LGT (ASN 2023-AGL-18668-OE) 445209N0930852W (3.2NM ESE MSP) 1115FT (198FT AGL) U/S 2407191541-2408192359
7/18/240905Z !MSP 07/272 MSP TWY D BTN RWY 12R/30L AND TWY A EAST SIDE IRREGULAR SFC 2407180905-2410182100
7/17/242022Z !MSP 07/259 MSP TWY G BTN TWY P AND RWY 12L/30R NORTHWEST EDGE IRREGULAR SFC 2407172022-2409302100
7/17/241839Z !MSP 07/258 MSP TWY B BTN TWY A10 AND TWY B8 NORTH EDGE IRREGULAR SFC 2407171839-2409302100
7/17/241334Z !MSP 07/250 MSP TWY Q BTN GATE D2 AND GATE E14 CL MARKING NOT STD 2407171334-2410172300
7/10/242100Z !MSP 07/162 MSP RWY 04/22 BTN TWY Q AND TWY C10 CLSD EXC XNG AT C9 2407102100-2409302000
7/10/241735Z !MSP 07/150 MSP RWY 04/22 CLSD EXC TAX BTN TWY K AND TWY Q 2407101735-2409302200
6/29/241056Z !MSP 06/532 MSP RWY 17/35 CL MARKINGS OBSC 2406291056-2409301800
6/26/241329Z !MSP 06/482 MSP APRON DEICE PAD FOR RWY 30L NONMOVEMENT AREA BDRY MARKINGS FADED 2406261329-2408312100
6/21/242237Z !MSP 06/420 MSP TWY D CL MARKINGS BTN TWY Q AND TWY P NOT STD 2406212237-2409212359
6/18/241745Z !MSP 06/366 MSP TWY B CL LGT BTN GATE G3 AND TWY A5 U/S 2406181745-2409210500
6/18/241739Z !MSP 06/365 MSP TWY B BTN GATE G5 AND GATE G9 CLSD 2406181739-2409210500
6/18/241537Z !MSP 06/362 MSP TWY A BTN TWY A4 AND TWY A5 CLSD TO ACFT WINGSPAN MORE THAN 214FT 2406181537-2409070500
6/11/241511Z !MSP 06/214 MSP TWY A5 CLSD TO XNG SW BOUND ACFT WINGSPAN MORE THAN 125FT 2406111511-2409112200
6/10/241342Z !MSP 06/196 MSP OBST CRANE (ASN UNKNOWN) 445121N0931407W (.57NM S APCH END RWY 35)
UNKNOWN (117FT AGL) FLAGGED 2406101342-2412062000
6/8/241411Z !MSP 06/175 MSP RWY 22 PAPI U/S 2406081411-2409302100
6/8/241410Z !MSP 06/174 MSP RWY 04 PAPI U/S 2406081410-2409302100
6/8/241409Z !MSP 06/173 MSP RWY 30R PAPI U/S 2406081409-2409302100
6/3/241947Z !MSP 06/067 MSP TWY G ELEVATED RWY GUARD LGT AT RWY 12L/30R U/S 2406031947-2409302100
6/3/241222Z !MSP 06/061 MSP APRON DEICE PAD FOR RWY 12L CLSD 2406031222-2409212200
6/3/241221Z !MSP 06/060 MSP TWY C BTN TWY C9 AND TWY C10, TWY C BTN TWY P AND TWY C9 CLSD 2406031221-2409212200
6/3/241214Z !MSP 06/058 MSP TWY C10, P1, P2, P3, P4, P8, P9, P10, R8, R9, R10, TWY M BTN RWY 12L/30R AND TWY Q CLSD 2406031214-2409212200
6/3/241212Z !MSP 06/059 MSP RWY 12L/30R CLSD EXC XNG AT TWY G 2406031212-2409212200
6/3/241210Z !MSP 06/057 MSP TWY P BTN TWY P1 AND TWY P4, TWY P BTN TWY C AND TWY P10 CLSD 2406031210-2409212200
6/3/241200Z !MSP 06/054 MSP TWY R BTN TWY R7 AND TWY R10 CLSD 2406031200-2409212200
6/3/241200Z !MSP 06/053 MSP RWY 12L/30R RWY STATUS LGT SYSTEM U/S 2406031200-2409302355
6/3/240400Z !MSP 06/034 MSP NAV ILS RWY 12L U/S 2406030400-2409302100
6/3/240400Z !MSP 06/033 MSP RWY 30R ALS U/S 2406030400-2409302100
6/3/240400Z !MSP 06/032 MSP NAV ILS RWY 04 U/S 2406030400-2409302100
6/3/240400Z !MSP 06/031 MSP RWY 22 ALS U/S 2406030400-2409302100
6/3/240400Z !MSP 06/030 MSP RWY 04 ALS U/S 2406030400-2409302100
6/3/240400Z !MSP 06/029 MSP NAV ILS RWY 30R U/S 2406030400-2409302100
6/3/240400Z !MSP 06/028 MSP RWY 12L ALS U/S 2406030400-2409302100
6/3/240400Z !MSP 06/027 MSP NAV ILS RWY 22 U/S 2406030400-2409302100
6/3/240400Z !MSP 06/026 MSP RWY 12L PAPI U/S 2406030400-2409302100
5/30/242038Z !MSP 05/596 MSP OBST CRANE (ASN 2024-AGL-751-OE) 445128N0931400W (1.5NM SSW MSP) 913FT (100FT AGL) FLAGGED AND LGTD 2405302038-2412022300
5/14/241239Z !MSP 05/220 MSP TWY P SFC MARKINGS BTN TWY G AND TWY P4 NOT STD 2405141239-2408131200
4/29/242135Z !MSP 04/452 MSP TWY C CL MARKINGS BTN HUMPHREY REMOTE APN NORTH AND TWY D NOT STD 2404292135-2409302300
4/16/241541Z !MSP 04/225 MSP OBST CRANE (ASN UNKNOWN) 445624N0931134W (4.2NM NNE MSP)
UNKNOWN (220FT AGL) FLAGGED 2404161541-2509012100
FDC
7/26/241511Z !FDC 4/8458 MSP IAP MINNEAPOLIS-ST PAUL INTL/WOLD-CHAMBERLAIN, MINNEAPOLIS, MN.
LOC RWY 22, AMDT 2...
MISSED APPROACH: CLIMBING LEFT TURN TO 3000 DIRECT FGT VORTAC AND HOLD S, RT, 358.03 INBOUND.
RADAR REQUIRED FOR PROCEDURE ENTRY EXCEPT FOR ACFT EQUIPPED WITH SUITABLE RNAV SYSTEM WITH GPS,
GEP VORTAC OUT OF SERVICE. 2407261511-2408301511EST
7/26/241511Z !FDC 4/8456 MSP SID MINNEAPOLIS-ST PAUL INTL/WOLD-CHAMBERLAIN, MINNEAPOLIS, MN.
LEINY SIX DEPARTURE (RNAV)...
DEPARTURE PROCEDURE : GPS REQUIRED,
GEP VORTAC OUT OF SERVICE. 2407261511-2408301511EST
7/26/241511Z !FDC 4/8454 MSP IAP MINNEAPOLIS-ST PAUL INTL/WOLD-CHAMBERLAIN, MINNEAPOLIS, MN.
ILS Z OR LOC RWY 35, AMDT 5...
ILS RWY 35 (SA CAT I), AMDT 5...
ILS RWY 35 (CAT II AND III), AMDT 5...
MISSED APPROACH: CLIMB TO 1600 THEN CLIMBING LEFT TURN TO 3000 ON HEADING 180 AND ON FGT VORTAC R-258 TO LYDIA INT/FGT 12.80 DME AND HOLD. (DME REQUIRED),
GEP VORTAC OUT OF SERVICE. 2407261511-2408301511EST
7/26/241511Z !FDC 4/8452 MSP IAP MINNEAPOLIS-ST PAUL INTL/WOLD-CHAMBERLAIN, MINNEAPOLIS, MN.
LOC RWY 4, AMDT 2...
PROCEDURE NA EXCEPT FOR AIRCRAFT EQUIPPED WITH SUITABLE RNAV SYSTEM WITH GPS,
GEP VORTAC OUT OF SERVICE. 2407261511-2408301511EST
7/26/241511Z !FDC 4/8451 MSP SID MINNEAPOLIS-ST PAUL INTL/WOLD-CHAMBERLAIN, MINNEAPOLIS, MN.
COULT SEVEN DEPARTURE...
KBREW TWO DEPARTURE...
WLSTN SEVEN DEPARTURE...
DEPARTURE PROCEDURE NA EXCEPT FOR AIRCRAFT EQUIPPED WITH SUITABLE RNAV SYSTEM WITH GPS,
GEP VORTAC OUT OF SERVICE. 2407261511-2408301511EST
7/26/241511Z !FDC 4/8449 MSP IAP MINNEAPOLIS-ST PAUL INTL/WOLD-CHAMBERLAIN, MINNEAPOLIS, MN.
ILS OR LOC RWY 30L, AMDT 47...
ILS RWY 30L (CAT II), AMDT 47...
PROCEDURE NA EXCEPT FOR ACFT EQUIPPED WITH SUITABLE RNAV SYSTEM WITH GPS,
GEP VORTAC OUT OF SERVICE. 2407261511-2408301511EST
7/26/241511Z !FDC 4/8447 MSP IAP MINNEAPOLIS-ST PAUL INTL/WOLD-CHAMBERLAIN, MINNEAPOLIS, MN.
LOC RWY 17, AMDT 1B...
RADAR REQUIRED FOR PROCEDURE ENTRY EXCEPT FOR AIRCRAFT EQUIPPED WITH SUITABLE RNAV SYSTEM WITH GPS,
GEP VORTAC OUT OF SERVICE. 2407261511-2408301511EST
7/26/241511Z !FDC 4/8446 MSP IAP MINNEAPOLIS-ST PAUL INTL/WOLD-CHAMBERLAIN, MINNEAPOLIS, MN.
ILS V RWY 35 (CONVERGING), AMDT 5...
MISSED APPROACH: CLIMBING LEFT TURN TO 3000 ON HEADING 180 AND ON FGT VORTAC R-258 TO LYDIA INT/FGT 12.80 DME AND HOLD (DME REQUIRED),
GEP VORTAC OUT OF SERVICE. 2407261511-2408301511EST
7/26/241511Z !FDC 4/8445 MSP IAP MINNEAPOLIS-ST PAUL INTL/WOLD-CHAMBERLAIN, MINNEAPOLIS, MN.
ILS OR LOC RWY 30R, AMDT 16...
MISSED APPROACH: CLIMB TO 1300, THEN CLIMBING RIGHT TURN TO 3000 ON HEADING 130 AND MSP VOR/DME R-096 TO KANAC INT/MSP 13.13 DME AND HOLD,
GEP VORTAC OUT OF SERVICE. 2407261511-2408301511EST
5/8/241813Z !FDC 4/1044 MSP ODP MINNEAPOLIS-ST PAUL
INTL/WOLD-CHAMBERLAIN, MINNEAPOLIS, MN.
TAKEOFF MINIMUMS AND (OBSTACLE) DEPARTURE PROCEDURES AMDT 12...
RWY 12L, 300-1 1/2 OR STANDARD WITH A MINIMUM CLIMB OF 277 FT PER
NM TO 1100, OR ALTERNATIVELY, WITH STANDARD TAKEOFF MINIMUMS AND A
NORMAL 200 FT PER NM CLIMB GRADIENT, TAKEOFF MUST OCCUR NO LATER
THAN 1300 FT PRIOR TO DER. ADD TAKEOFF OBSTACLE NOTE: RWY 12L,
TRANSMISSION LINE 1 NM FROM DER, 1818' LEFT OF CENTERLINE, 77'
AGL/832' MSL. TREE 1.1 NM FROM DER, 1691' LEFT OF CENTERLINE, 92'
AGL/991' MSL. LIGHT POLE AND CAMERA ON WALL BEGINNING 398' FROM
DER, 561' RIGHT OF CENTERLINE, UP TO 23' AGL/832' MSL.
ALL OTHER DATA REMAINS AS PUBLISHED. 2405081813-2605051813EST
5/6/241645Z !FDC 4/9258 MSP IAP MINNEAPOLIS-ST PAUL INTL/WOLD-CHAMBERLAIN, MINNEAPOLIS, MN.
ILS OR LOC RWY 12L, AMDT 11...
ILS OR LOC RWY 12R, AMDT 12...
ILS OR LOC RWY 30L, AMDT 47...
ILS OR LOC RWY 30R, AMDT 16...
ILS Z OR LOC RWY 35, AMDT 5...
ALTERNATE MINIMUMS STANDARD EXCEPT: LOC: CAT D 900-2 3/4, CAT E 1000-3.
2405061645-2605061645EST
3/6/241911Z !FDC 4/3853 MSP SID MINNEAPOLIS-ST PAUL
INTL/WOLD-CHAMBERLAIN, MINNEAPOLIS, MN.
ZMBRO SEVEN DEPARTURE...
CHANGE TOP ALTITUDE TO READ "ASSIGNED BY ATC".
CHANGE DEPARTURE ROUTE DESCRIPTION TO READ: TAKEOFF ALL RWYS: CLIMB
ON ASSIGNED HEADING FOR RADAR VECTORS TO INTERCEPT MSP R-138, THEN
ON DEPICTED ROUTE TO ZEMBRO, THEN ON TRANSITION. MAINTAIN ATC
ASSIGNED ALTITUDE, EXPECT FILED ALTITUDE 10 MINUTES AFTER
DEPARTURE.
ALL AIRCRAFT: ATC CROSSING RESTRICTIONS AND CLIMB GRADIENTS: IF
UNABLE TO ACCEPT CROSSING RESTRICTIONS AND CLIMB RATES ADVISE ATC
PRIOR TO TAXI.
RWY 12L/R: FOR ASSIGNED HEADINGS FROM 060 CW TO 100, CROSS MSP 7
DME ARC AT OR ABOVE 3500, RWY 12L: 540 FT/NM TO 3500, 12R: 542
FT/NM TO 3500.
RWY 17: FOR ASSIGNED HEADINGS FROM 230 CW TO 285, CROSS MSP 7 DME
ARC AT OR ABOVE 3500, 512 FT/NM TO 3500.
RWYS 30L/R: FOR ASSIGNED HEADINGS FROM 220 CW TO 360, CROSS MSP 7
DME ARC AT OR ABOVE 3500, 380 FT/NM TO 3500.
DISREGARD CHART NOTE: NON-DME AIRCRAFT RWYS 12L/R (FOR ASSIGNED
060º CW 100º). 2403061911-2603061911EST
3/6/241911Z !FDC 4/3851 MSP SID MINNEAPOLIS-ST PAUL
INTL/WOLD-CHAMBERLAIN, MINNEAPOLIS, MN.
WLSTN SEVEN DEPARTURE...
CHANGE TOP ALTITUDE TO READ "ASSIGNED BY ATC".
CHANGE DEPARTURE ROUTE DESCRIPTION TO READ: TAKEOFF ALL RWYS: CLIMB
ON ASSIGNED HEADING FOR RADAR VECTORS TO INTERCEPT GEP R-072, THEN
ON DEPICTED ROUTE TO WLSTN, THEN ON TRANSITION. MAINTAIN ATC
ASSIGNED ALTITUDE, EXPECT FILED ALTITUDE 10 MINUTES AFTER
DEPARTURE.
ALL AIRCRAFT: ATC CROSSING RESTRICTIONS AND CLIMB GRADIENTS: IF
UNABLE TO ACCEPT CROSSING RESTRICTIONS AND CLIMB RATES ADVISE ATC
PRIOR TO TAXI.
RWY 12L/R: FOR ASSIGNED HEADINGS FROM 060 CW TO 100, CROSS MSP 7
DME ARC AT OR ABOVE 3500, RWY 12L: 540 FT/NM TO 3500, 12R: 542
FT/NM TO 3500.
RWY 17: FOR ASSIGNED HEADINGS FROM 230 CW TO 285, CROSS MSP 7 DME
ARC AT OR ABOVE 3500, 512 FT/NM TO 3500.
RWYS 30L/R: FOR ASSIGNED HEADINGS FROM 220 CW TO 360, CROSS MSP 7
DME ARC AT OR ABOVE 3500, 380 FT/NM TO 3500.
DISREGARD CHART NOTE: NON-DME AIRCRAFT RWYS 12L/R (FOR ASSIGNED
060º CW 100º).
CHART: MRA AT OR ABOVE 9000 FT AT DWIYT.
CHART: MRA AT OR ABOVE 12000 FT AT WLSTN. 2403061911-2603061911EST
3/6/241911Z !FDC 4/3849 MSP SID MINNEAPOLIS-ST PAUL
INTL/WOLD-CHAMBERLAIN, MINNEAPOLIS, MN.
SMERF SEVEN DEPARTURE (RNAV)...
CHANGE TOP ALTITUDE TO READ "ASSIGNED BY ATC".
CHANGE DEPARTURE ROUTE DESCRIPTION TO READ: TAKEOFF RWY 4: CLIMB
ON HEADING 045 DEGREES TO 2100, FOR VECTORS TO CROSS ZOGAP AT OR
ABOVE 5000, THENCE&
TAKEOFF ALL OTHER RWYS: CLIMB ON ASSIGNED HEADING FOR RADAR VECTORS
TO CROSS ZOGAP AT OR ABOVE 5000, THENCE&
&ON DEPICTED ROUTE TO SMERF. MAINTAIN ATC ASSIGNED ALTITUDE, EXPECT
FILED ALTITUDE 10 MINUTES AFTER DEPARTURE.
ALL AIRCRAFT: ATC CROSSING RESTRICTIONS AND CLIMB GRADIENTS: IF
UNABLE TO ACCEPT CROSSING RESTRICTIONS AND CLIMB RATES ADVISE ATC
PRIOR TO TAXI.
RWY 12L/R: FOR ASSIGNED HEADINGS FROM 060 CW TO 100, CROSS MSP 7
DME ARC AT OR ABOVE 3500, RWY 12L: 540 FT/NM TO 3500, 12R: 542
FT/NM TO 3500.
RWY 17: FOR ASSIGNED HEADINGS FROM 230 CW TO 285, CROSS MSP 7 DME
ARC AT OR ABOVE 3500, 512 FT/NM TO 3500.
RWYS 30L/R: FOR ASSIGNED HEADINGS FROM 220 CW TO 360, CROSS MSP 7
DME ARC AT OR ABOVE 3500, 380 FT/NM TO 3500.
2403061911-2603061911EST
3/6/241911Z !FDC 4/3847 MSP SID MINNEAPOLIS-ST PAUL
INTL/WOLD-CHAMBERLAIN, MINNEAPOLIS, MN.
ROCHESTER ONE DEPARTURE...
CHANGE TOP ALTITUDE TO READ "ASSIGNED BY ATC".
CHANGE DEPARTURE ROUTE DESCRIPTION TO READ: TAKEOFF ALL RWYS: CLIMB
ON ASSIGNED HEADING FOR RADAR VECTORS TO FGT VORTAC, THEN ON
DEPICTED ROUTE TO RST VOR/DME, THEN ON TRANSITION. MAINTAIN ATC
ASSIGNED ALTITUDE, EXPECT FILED ALTITUDE 10 MINUTES AFTER
DEPARTURE.
ALL AIRCRAFT: ATC CROSSING RESTRICTIONS AND CLIMB GRADIENTS: IF
UNABLE TO ACCEPT CROSSING RESTRICTIONS AND CLIMB RATES ADVISE ATC
PRIOR TO TAXI.
RWY 12L/R: FOR ASSIGNED HEADINGS FROM 060 CW TO 100, CROSS MSP 7
DME ARC AT OR ABOVE 3500, RWY 12L: 540 FT/NM TO 3500, 12R: 542
FT/NM TO 3500.
RWY 17: FOR ASSIGNED HEADINGS FROM 230 CW TO 285, CROSS MSP 7 DME
ARC AT OR ABOVE 3500, 512 FT/NM TO 3500.
RWYS 30L/R: FOR ASSIGNED HEADINGS FROM 220 CW TO 360, CROSS MSP 7
DME ARC AT OR ABOVE 3500, 380 FT/NM TO 3500.
DISREGARD CHART NOTE: NON-DME AIRCRAFT RWYS 12L/R (FOR ASSIGNED
060º CW 100º). 2403061911-2603061911EST
3/6/241911Z !FDC 4/3845 MSP SID MINNEAPOLIS-ST PAUL
INTL/WOLD-CHAMBERLAIN, MINNEAPOLIS, MN.
LEINY SIX DEPARTURE (RNAV)...
CHANGE TOP ALTITUDE TO READ "ASSIGNED BY ATC".
CHANGE DEPARTURE ROUTE DESCRIPTION TO READ: TAKEOFF RWY 4: CLIMB
ON HEADING 045 DEGREES TO 2100, FOR VECTORS TO TONKA, THENCE&
TAKEOFF ALL OTHER RWYS: CLIMB ON ASSIGNED HEADING FOR RADAR VECTORS
TO TONKA, THENCE&
&ON DEPICTED ROUTE TO LEINY. MAINTAIN ATC ASSIGNED ALTITUDE, EXPECT
FILED ALTITUDE 10 MINUTES AFTER DEPARTURE.
ALL AIRCRAFT: ATC CROSSING RESTRICTIONS AND CLIMB GRADIENTS: IF
UNABLE TO ACCEPT CROSSING RESTRICTIONS AND CLIMB RATES ADVISE ATC
PRIOR TO TAXI.
RWY 12L/R: FOR ASSIGNED HEADINGS FROM 060 CW TO 100, CROSS MSP 7
DME ARC AT OR ABOVE 3500, RWY 12L: 540 FT/NM TO 3500, 12R: 542
FT/NM TO 3500.
RWY 17: FOR ASSIGNED HEADINGS FROM 230 CW TO 285, CROSS MSP 7 DME
ARC AT OR ABOVE 3500, 512 FT/NM TO 3500.
RWYS 30L/R: FOR ASSIGNED HEADINGS FROM 220 CW TO 360, CROSS MSP 7
DME ARC AT OR ABOVE 3500, 380 FT/NM TO 3500.
2403061911-2603061911EST
3/6/241911Z !FDC 4/3835 MSP SID MINNEAPOLIS-ST PAUL
INTL/WOLD-CHAMBERLAIN, MINNEAPOLIS, MN.
COULT SEVEN DEPARTURE...
CHANGE TOP ALTITUDE TO READ "ASSIGNED BY ATC".
CHANGE DEPARTURE ROUTE DESCRIPTION TO READ: TAKEOFF ALL RWYS: CLIMB
ON ASSIGNED HEADING FOR RADAR VECTORS TO INTERCEPT GEP R-119, THEN
ON DEPICTED ROUTE TO COULT, THEN ON TRANSITION. MAINTAIN ATC
ASSIGNED ALTITUDE, EXPECT FILED ALTITUDE 10 MINUTES AFTER
DEPARTURE.
ALL AIRCRAFT: ATC CROSSING RESTRICTIONS AND CLIMB GRADIENTS: IF
UNABLE TO ACCEPT CROSSING RESTRICTIONS AND CLIMB RATES ADVISE ATC
PRIOR TO TAXI.
RWY 12L/R: FOR ASSIGNED HEADINGS FROM 060 CW TO 100, CROSS MSP 7
DME ARC AT OR ABOVE 3500, RWY 12L: 540 FT/NM TO 3500, 12R: 542
FT/NM TO 3500.
RWY 17: FOR ASSIGNED HEADINGS FROM 230 CW TO 285, CROSS MSP 7 DME
ARC AT OR ABOVE 3500, 512 FT/NM TO 3500.
RWYS 30L/R: FOR ASSIGNED HEADINGS FROM 220 CW TO 360, CROSS MSP 7
DME ARC AT OR ABOVE 3500, 380 FT/NM TO 3500.
DISREGARD CHART NOTE: NON-DME AIRCRAFT RWYS 12L/R (FOR ASSIGNED
060º CW 100º). 2403061911-2603061911EST
12/20/231634Z !FDC 3/8117 MSP SID MINNEAPOLIS-ST PAUL INTL/WOLD-CHAMBERLAIN, MINNEAPOLIS, MN.
COULT SEVEN DEPARTURE...
MINIMUM ALTITUDE AT TAXEE 4600. EAU VORTAC RESTRICTED. 2312201634-2512201634EST
Yes
ALL
METRO ARPT CMSN
6040 28TH AVE S
MINNEAPOLIS, MN 55450-2799
Phone: 612-726-8100
BRIAN RYKS
6040 28TH AVE S
MINNEAPOLIS, MN 55450-2799
Phone: 612-726-8100
PRINCETON FSS (PNM)
Toll Free: 1-800-WX-BRIEF
MSP
--
--
N/A
Yes - Lighted
No
Yes
Hanger, Tie-Down
Landing Rights Airport
NOT an Airport of Entry
0
26
136
0
16
0
Major
Major
High Pressure
High Pressure
Air Freight
Avionics
Cargo Handling
Charter Service

Runway 04/22

11006 ft. x 150 ft.
CONC
Good
GRVD
HIGH
105/R/B/W/T
100,000lbs
200,000lbs
400,000lbs
850,000lbs
  Runway 04 Runway 22
True Heading 45°225°
Traffic Pattern Left Left
Markings PIR PIR
Markings Condition GOOD GOOD
Latitude 44° 52' 20"N 44° 53' 37"N
Longitude 93° 14' 18"W 93° 12' 30"W
Elevation 834' 830'
Threshold Crossing Height 76 ft. AGL 61 ft. AGL
Visual Glide Path Angle 3° 3°
Visual Slope Indicator P4L P4L
Approach Lights MALSR MALSR
Centerline Lights No No
Runway End Identifier Lights No No

Runway 12L/30R

8200 ft. x 150 ft.
CONC
Fair
GRVD
HIGH
105/R/B/W/T
100,000lbs
200,000lbs
400,000lbs
850,000lbs
  Runway 12L Runway 30R
True Heading 121°301°
Traffic Pattern Left Left
Markings PIR PIR
Markings Condition GOOD GOOD
Latitude 44° 53' 35"N 44° 52' 53"N
Longitude 93° 13' 16"W 93° 11' 38"W
Elevation 839' 820'
Threshold Crossing Height 79 ft. AGL 71 ft. AGL
Visual Glide Path Angle 3° 3°
Visual Slope Indicator P4L P4L
Approach Lights ALSF2 MALSF
Centerline Lights Yes Yes
Runway End Identifier Lights No No

Runway 12R/30L

10000 ft. x 200 ft.
CONC
Good
GRVD
HIGH
106/R/B/W/T
100,000lbs
200,000lbs
400,000lbs
850,000lbs
  Runway 12R Runway 30L
True Heading 121°301°
Traffic Pattern Left Left
Markings PIR PIR
Markings Condition GOOD GOOD
Latitude 44° 53' 16"N 44° 52' 25"N
Longitude 93° 14' 03"W 93° 12' 04"W
Elevation 842' 814'
Threshold Crossing Height 66 ft. AGL 78 ft. AGL
Visual Glide Path Angle 3° 3°
Visual Slope Indicator P4L P4L
Approach Lights ALSF2 ALSF2
Centerline Lights Yes Yes
Runway End Identifier Lights No No

Runway 17/35

8000 ft. x 150 ft.
CONC
Good
GRVD
HIGH
118/R/B/W/T
100,000lbs
200,000lbs
400,000lbs
850,000lbs
  Runway 17 Runway 35
True Heading 170°350°
Traffic Pattern
Markings NPI PIR
Markings Condition GOOD GOOD
Latitude 44° 53' 16"N 44° 51' 58"N
Longitude 93° 14' 32"W 93° 14' 12"W
Elevation 840' 833'
Threshold Crossing Height 60 ft. AGL 71 ft. AGL
Visual Glide Path Angle 3° 3°
Visual Slope Indicator P4R P4L
Approach Lights ALSF2
Centerline Lights Yes Yes
Runway End Identifier Lights Yes No
A110-1TRNG FLTS PROHIBITED. GA FLTS MUST TRMT AT THE FBO OR US CUSTOMS UNLESS APVD BY AMGR.
A110-14133 AW AFLD MGMT - 324.1 REMARKS: CALL LIGHTHOUSE.
A110-15COMMUNICATIONS: MINNEAPOLIS AIR RESERVE STATION JOINT COMD POST - 252.1 REMARKS: CALL NORTHSTAR.
A110-16934 AW AFLD MGMT - PTD 282.675 REMARKS: CALL VIKING OPS.
A110-17REMARKS: ALL ACFT MUST CTC NORTHSTAR ON FREQ 252.1 20 MIN PRIOR ARR.
A110-18ASDE-X IN USE; OPR TRANSPONDERS WITH ALT RPRT MODE & ADS-B ENABLED ON ALL ARPT SFCS.
A110-19UNSKED ACFT AT TRML 2-HUMPHREY REQ TO CTC TRML 2 GATE CONTROL ON 122.95 OR CALL 612-726-5742 PRIOR TO ARR.
A110-2NOISE ABATEMENT PROCEDURES - 612-726-9411. NO STAGE 1 CAT CIVIL ACFT. NIGHT HR 2230-0600.
A110-20ALL GROUP VI ACFT WITH WINGSPAN GREATER THAN 214 FT PPR REQ PRIOR TO ARR - CTC AIRSIDE OPS 612-726-5111.
A110-21RWY STATUS LGTS IN OPRN.
A110-22ALL GA ACFT WITH LESS THAN 20 PAX THAT NEED TO CLEAR US CUSTOMS SHOULD CTC SIGNATURE FLT SUPPORT 128.95 OR 612-726-5700 PRIOR TO ARR.
A110-23ALL GROUP IV AND LRGR ACFT OPRG ON THE PTN OF TWY S ADJ TO DELTA BLDG C RQR THE USE OF WINGWALKERS AND THAT THE VEHICLE SVC ROAD BE CLEAR OF VEHICLES.
A110-3BIRDS ON & INVOF ARPT.
A110-4SIGNATURE FLIGHT SUPPORT 128.95
A110-6MILITARY: ARFC 934 AW OPS 1300-0400Z++ MON-THUR, 1300-2200Z++ FRI, CLSD WKEND AND FEDERAL HOL. UNIT TRNG ASSEMBLY (UTA) WKEND 1330-2200Z++. ALL TRANS ACFT MUST RECEIVE PPR 48 HR PRIOR TO ETA - CTC AIRFIELD MGMT.
A110-7MILITARY RSTD: NO HAZ CL/DIV1.1 OR 1.2 EXPLOSIVES PERMITTED. LOADING OR UNLOADING OF HAZ CL/DIV 1.3, 1.4, 1.5 0R 1.6 MUST BE APV BY ARPT DRCT PRIOR TO FLT.
MINNEAPOLIS-ST PAUL INTL/WOLD-CHAMBERLAIN (ICAO: KMSP, IATA: MSP) is a public airport located in MINNEAPOLIS, MN.
