1/27/25 1457Z | 1/27/27 1456Z | | !FDC 5/7051 MTW PART 1 OF 5 ODP MANITOWOC COUNTY, MANITOWOC, WI.
TAKEOFF MINIMUMS AND (OBSTACLE) DEPARTURE PROCEDURES AMDT 4...
TAKEOFF OBSTACLE NOTES: RWY 7: TREE 24 FT FROM DER, 260 FT LEFT OF
CENTERLINE, 660 FT MSL.
POLE 29 FT FROM DER, 342 FT RIGHT OF CENTERLINE, 27 FT AGL/643 FT
MSL.
TREES BEGINNING 57 FT FROM DER, 392 FT LEFT OF CENTERLINE, UP TO 72
FT AGL/681 FT MSL.
TREES BEGINNING 437 FT FROM DER, 279 FT LEFT OF CENTERLINE, UP TO
85 FT AGL/691 FT MSL.
TREE 461 FT FROM DER, 397 FT RIGHT OF CENTERLINE, 664 FT MSL.
TREE 711 FT FROM DER, 495 FT RIGHT OF CENTERLINE, 666 FT MSL. RWY
17: TREE 19 FT FROM DER, 459 FT LEFT OF CENTERLINE, 12 FT AGL/653
FT MSL.
UTILITY BUILDING 39 FT FROM DER, 124 FT RIGHT OF CENTERLINE, 2 FT
AGL/651 FT MSL.
BUILDING 989 FT FROM DER, 511 FT RIGHT OF CENTERLINE, 688 FT MSL.
POLES BEGINNING 1236 FT FROM DER, 489 FT RIGHT OF CENTERLINE, UP TO
45 FT AGL/695 FT MSL.
TREE 1332 FT FROM DER, 702 FT LEFT OF CENTERLINE, 687 FT MSL.
TREES, POLES BEGINNING 1493 FT FROM DER, 194 FT LEFT OF CENTERLINE,
2501271457-2701271456EST
END PART 1 OF 5
!FDC 5/7051 MTW PART 2 OF 5 ODP MANITOWOC COUNTY, MANITOWOC, WI.
UP TO 702 FT MSL.
TREE 1682 FT FROM DER, 339 FT LEFT OF CENTERLINE, 707 FT MSL.
TREES BEGINNING 1707 FT FROM DER, 84 FT LEFT OF CENTERLINE, UP TO
708 FT MSL.
TREE 1804 FT FROM DER, 324 FT RIGHT OF CENTERLINE, 706 FT MSL.
TREES BEGINNING 1868 FT FROM DER, 76 FT RIGHT OF CENTERLINE, UP TO
710 FT MSL.
TREES BEGINNING 1950 FT FROM DER, 324 FT LEFT OF CENTERLINE, UP TO
709 FT MSL.
TREES BEGINNING 2071 FT FROM DER, 390 FT LEFT OF CENTERLINE, UP TO
717 FT MSL.
TREES BEGINNING 2086 FT FROM DER, 465 FT LEFT OF CENTERLINE, UP TO
721 FT MSL.
TREES BEGINNING 2088 FT FROM DER, 29 FT RIGHT OF CENTERLINE, UP TO
727 FT MSL.
TREES BEGINNING 2111 FT FROM DER, 114 FT LEFT OF CENTERLINE, UP TO
724 FT MSL.
TREES BEGINNING 2228 FT FROM DER, 55 FT LEFT OF CENTERLINE, UP TO
725 FT MSL.
TREES BEGINNING 2299 FT FROM DER, 116 FT LEFT OF CENTERLINE, UP TO
2501271457-2701271456EST
END PART 2 OF 5
!FDC 5/7051 MTW PART 3 OF 5 ODP MANITOWOC COUNTY, MANITOWOC, WI.
731 FT MSL.
TREE 2429 FT FROM DER, 498 FT RIGHT OF CENTERLINE, 728 FT MSL.
TREES BEGINNING 2507 FT FROM DER, 150 FT RIGHT OF CENTERLINE, UP TO
733 FT MSL.
TREES BEGINNING 2587 FT FROM DER, 24 FT LEFT OF CENTERLINE, UP TO
735 FT MSL.
TREES BEGINNING 2740 FT FROM DER, 179 FT LEFT OF CENTERLINE, UP TO
739 FT MSL.
TREES BEGINNING 2741 FT FROM DER, 11 FT RIGHT OF CENTERLINE, UP TO
741 FT MSL.
TREES BEGINNING 2840 FT FROM DER, 15 FT LEFT OF CENTERLINE, UP TO
745 FT MSL.
TREES BEGINNING 3029 FT FROM DER, 288 FT RIGHT OF CENTERLINE, UP TO
747 FT MSL.
TREES BEGINNING 3203 FT FROM DER, 77 FT LEFT OF CENTERLINE, UP TO
99 FT AGL/747 FT MSL.
SMOKESTACK 1.2 NM FROM DER, 1936 FT LEFT OF CENTERLINE, 310 FT
AGL/893 FT MSL. RWY 25: TREE 496 FT FROM DER, 402 FT RIGHT OF
CENTERLINE, 664 FT MSL.
TREE 676 FT FROM DER, 634 FT RIGHT OF CENTERLINE, 81 FT AGL/730 FT
2501271457-2701271456EST
END PART 3 OF 5
!FDC 5/7051 MTW PART 4 OF 5 ODP MANITOWOC COUNTY, MANITOWOC, WI.
MSL.
TREES, TRAVERSE WAYS BEGINNING 682 FT FROM DER, 93 FT RIGHT OF
CENTERLINE, UP TO 85 FT AGL/732 FT MSL.
TRAVERSE WAY 744 FT FROM DER, ON CENTERLINE, 676 FT MSL.
POLE 746 FT FROM DER, 290 FT LEFT OF CENTERLINE, 28 FT AGL/678 FT
MSL.
POLE 772 FT FROM DER, 436 FT LEFT OF CENTERLINE, 31 FT AGL/681 FT
MSL.
TREES BEGINNING 857 FT FROM DER, 581 FT LEFT OF CENTERLINE, UP TO
700 FT MSL.
TREE 1339 FT FROM DER, 601 FT LEFT OF CENTERLINE, 702 FT MSL.
TREES BEGINNING 1351 FT FROM DER, 251 FT RIGHT OF CENTERLINE, UP TO
101 FT AGL/745 FT MSL.
TREES BEGINNING 1604 FT FROM DER, 470 FT LEFT OF CENTERLINE, UP TO
708 FT MSL.
TREES BEGINNING 1870 FT FROM DER, 203 FT LEFT OF CENTERLINE, UP TO
722 FT MSL.
TREES BEGINNING 2199 FT FROM DER, 410 FT LEFT OF CENTERLINE, UP TO
743 FT MSL. RWY 35: TRAVERSE WAYS BEGINNING AT DER, 50 FT LEFT OF
CENTERLINE, UP TO 15 FT AGL/661 FT MSL.
2501271457-2701271456EST
END PART 4 OF 5
!FDC 5/7051 MTW PART 5 OF 5 ODP MANITOWOC COUNTY, MANITOWOC, WI.
TREES BEGINNING 158 FT FROM DER, 481 FT RIGHT OF CENTERLINE, UP TO
660 FT MSL.
TREES BEGINNING 496 FT FROM DER, 549 FT RIGHT OF CENTERLINE, UP TO
669 FT MSL.
TREE 819 FT FROM DER, 614 FT RIGHT OF CENTERLINE, 683 FT MSL.
TREES BEGINNING 894 FT FROM DER, 620 FT RIGHT OF CENTERLINE, UP TO
700 FT MSL.
TREES BEGINNING 1177 FT FROM DER, 646 FT RIGHT OF CENTERLINE, UP TO
711 FT MSL.
TREE 1862 FT FROM DER, 710 FT LEFT OF CENTERLINE, 698 FT MSL.
TREE 1988 FT FROM DER, 724 FT LEFT OF CENTERLINE, 711 FT MSL.
TREE 2006 FT FROM DER, 859 FT LEFT OF CENTERLINE, 717 FT MSL.
2501271457-2701271456EST
END PART 5 OF 5
|
