12/30/24 1314Z | 1/5/27 1314Z | | !FDC 4/1868 OBE PART 1 OF 4 ODP OKEECHOBEE COUNTY, OKEECHOBEE, FL.
TAKEOFF MINIMUMS AND (OBSTACLE) DEPARTURE PROCEDURES ORIG...
TAKEOFF OBSTACLE NOTES: RWY 05: LIGHT POLE 10 FT FROM DER, 114 FT
LEFT OF CENTERLINE, 3 FT AGL/34 FT MSL. LIGHT POLE 10 FT FROM DER,
115 FT RIGHT OF CENTERLINE, 4 FT AGL/34 FT MSL. FENCE 61 FT FROM
DER, 399 FT RIGHT OF CENTERLINE, 7 FT AGL/36 FT MSL. FENCE 151 FT
FROM DER, 480 FT RIGHT OF CENTERLINE, 9 FT AGL/38 FT MSL. TREE 656
FT FROM DER, 474 FT RIGHT OF CENTERLINE, 66 FT MSL. TREE 691 FT
FROM DER, 494 FT RIGHT OF CENTERLINE, 76 FT MSL. TREES BEGINNING
696 FT FROM DER, 141 FT RIGHT OF CENTERLINE, UP TO 77 FT MSL. TREE
1047 FT FROM DER, 117 FT LEFT OF CENTERLINE, 61 FT MSL. TREE 1048
FT FROM DER, 562 FT LEFT OF CENTERLINE, 65 FT MSL. TREE 1056 FT
FROM DER, 665 FT LEFT OF CENTERLINE, 77 FT MSL. TREES, POLE
BEGINNING 1056 FT FROM DER, 15 FT LEFT OF CENTERLINE, UP TO 100 FT
MSL. TREES, POLES BEGINNING 1112 FT FROM DER, 62 FT RIGHT OF
CENTERLINE, UP TO 83 FT MSL. TREES, TRANSMISSION LINE BEGINNING
1155 FT FROM DER, 67 FT LEFT OF CENTERLINE, UP TO 101 FT MSL.
TREES, TRANSMISSION LINE BEGINNING 1431 FT FROM DER, 17 FT RIGHT OF
CENTERLINE, UP TO 96 FT MSL. TREES BEGINNING 2053 FT FROM DER, 295
FT LEFT OF CENTERLINE, UP TO 123 FT MSL. TREES BEGINNING 2292 FT
FROM DER, 189 FT RIGHT OF CENTERLINE, UP TO 101 FT MSL. TREE 2724
2412301314-2701051314EST
END PART 1 OF 4
!FDC 4/1868 OBE PART 2 OF 4 ODP OKEECHOBEE COUNTY, OKEECHOBEE, FL.
FT FROM DER, 849 FT RIGHT OF CENTERLINE, 108 FT MSL.
RWY 14: TREES BEGINNING 5 FT FROM DER, 282 FT LEFT OF CENTERLINE,
UP TO 53 FT MSL. TREES BEGINNING 105 FT FROM DER, 306 FT LEFT OF
CENTERLINE, UP TO 58 FT MSL. TREE 117 FT FROM DER, 486 FT RIGHT OF
CENTERLINE, 49 FT MSL. TREES BEGINNING 151 FT FROM DER, 229 FT
RIGHT OF CENTERLINE, UP TO 64 FT MSL. TREES BEGINNING 223 FT FROM
DER, 314 FT LEFT OF CENTERLINE, UP TO 64 FT MSL. TREES BEGINNING
333 FT FROM DER, 24 FT LEFT OF CENTERLINE, UP TO 65 FT MSL. TREES
BEGINNING 453 FT FROM DER, 29 FT RIGHT OF CENTERLINE, UP TO 66 FT
MSL. TREES BEGINNING 857 FT FROM DER, 459 FT RIGHT OF CENTERLINE,
UP TO 77 FT MSL. TREE 863 FT FROM DER, 628 FT RIGHT OF CENTERLINE,
78 FT MSL. TREES BEGINNING 947 FT FROM DER, 675 FT RIGHT OF
CENTERLINE, UP TO 80 FT MSL. TREES BEGINNING 1086 FT FROM DER, 455
FT RIGHT OF CENTERLINE, UP TO 81 FT MSL. TREES BEGINNING 1137 FT
FROM DER, 89 FT RIGHT OF CENTERLINE, UP TO 89 FT MSL. TREE 1291 FT
FROM DER, 247 FT LEFT OF CENTERLINE, 68 FT MSL. TREE 1330 FT FROM
DER, 13 FT LEFT OF CENTERLINE, 69 FT MSL. TREES BEGINNING 1563 FT
FROM DER, 128 FT LEFT OF CENTERLINE, UP TO 87 FT MSL. TREES
BEGINNING 1795 FT FROM DER, 122 FT LEFT OF CENTERLINE, UP TO 91 FT
MSL.
2412301314-2701051314EST
END PART 2 OF 4
!FDC 4/1868 OBE PART 3 OF 4 ODP OKEECHOBEE COUNTY, OKEECHOBEE, FL.
RWY 23: LIGHT POLE 9 FT FROM DER, 113 FT RIGHT OF CENTERLINE, 3 FT
AGL/34 FT MSL. LIGHT POLE 9 FT FROM DER, 117 FT LEFT OF CENTERLINE,
4 FT AGL/35 FT MSL. TREE 419 FT FROM DER, 533 FT RIGHT OF
CENTERLINE, 59 FT MSL. TREE 443 FT FROM DER, 308 FT LEFT OF
CENTERLINE, 53 FT MSL. BUILDING 465 FT FROM DER, 588 FT LEFT OF
CENTERLINE, 23 FT AGL/54 FT MSL. BUILDINGS BEGINNING 465 FT FROM
DER, 538 FT LEFT OF CENTERLINE, UP TO 25 FT AGL/56 FT MSL. POLES,
BUILDING, TANK, TREE BEGINNING 830 FT FROM DER, 311 FT LEFT OF
CENTERLINE, UP TO 39 FT AGL/70 FT MSL. POLE 1292 FT FROM DER, 583
FT LEFT OF CENTERLINE, 38 FT AGL/71 FT MSL. TREE 1774 FT FROM DER,
772 FT RIGHT OF CENTERLINE, 87 FT MSL. TREE 2071 FT FROM DER, 758
FT RIGHT OF CENTERLINE, 92 FT MSL. TREE 2158 FT FROM DER, 183 FT
LEFT OF CENTERLINE, 91 FT MSL. UTILITY BUILDING 4052 FT FROM DER,
1436 FT LEFT OF CENTERLINE, 106 FT AGL/138 FT MSL.
RWY 32: TREES, FENCE BEGINNING 83 FT FROM DER, 239 FT RIGHT OF
CENTERLINE, UP TO 48 FT MSL. TREES BEGINNING 386 FT FROM DER, 397
FT RIGHT OF CENTERLINE, UP TO 55 FT MSL. TREES BEGINNING 525 FT
FROM DER, 469 FT RIGHT OF CENTERLINE, UP TO 58 FT MSL. TREES, POLE
BEGINNING 668 FT FROM DER, 583 FT RIGHT OF CENTERLINE, UP TO 87 FT
MSL. TREE 676 FT FROM DER, 206 FT LEFT OF CENTERLINE, 58 FT MSL.
2412301314-2701051314EST
END PART 3 OF 4
!FDC 4/1868 OBE PART 4 OF 4 ODP OKEECHOBEE COUNTY, OKEECHOBEE, FL.
TREES BEGINNING 798 FT FROM DER, 252 FT LEFT OF CENTERLINE, UP TO
60 FT MSL. TREE 1265 FT FROM DER, 28 FT LEFT OF CENTERLINE, 69 FT
MSL. TREE 1313 FT FROM DER, 49 FT LEFT OF CENTERLINE, 80 FT MSL.
TREES BEGINNING 1371 FT FROM DER, 86 FT LEFT OF CENTERLINE, UP TO
82 FT MSL. TREES BEGINNING 1688 FT FROM DER, 16 FT LEFT OF
CENTERLINE, UP TO 89 FT MSL. TREE 1708 FT FROM DER, 10 FT RIGHT OF
CENTERLINE, 89 FT MSL.
2412301314-2701051314EST
END PART 4 OF 4
|
