5/5/25 1409Z | 5/5/27 1408Z | | !FDC 5/5902 PCZ PART 1 OF 4 ODP WAUPACA MUNI, WAUPACA, WI.
TAKEOFF MINIMUMS AND (OBSTACLE) DEPARTURE PROCEDURES AMDT 2...
TAKEOFF OBSTACLE NOTES: RWY 10: UTILITY BUILDING 40 FT FROM DER,
126 FT LEFT OF CENTERLINE, 2 FT AGL/807 FT MSL.
TREES, POLES BEGINNING 980 FT FROM DER, 51 FT LEFT OF CENTERLINE,
UP TO 853 FT MSL.
TREES, TOWER BEGINNING 1167 FT FROM DER, 106 FT LEFT OF CENTERLINE,
UP TO 864 FT MSL.
TREE 1259 FT FROM DER, 107 FT RIGHT OF CENTERLINE, 837 FT MSL.
TREE 1378 FT FROM DER, 265 FT RIGHT OF CENTERLINE, 841 FT MSL.
TREE 1700 FT FROM DER, 288 FT RIGHT OF CENTERLINE, 848 FT MSL.
TREE 1716 FT FROM DER, 474 FT RIGHT OF CENTERLINE, 852 FT MSL.
TREE 2054 FT FROM DER, 501 FT LEFT OF CENTERLINE, 865 FT MSL. RWY
13: UTILITY BUILDING 11 FT FROM DER, 18 FT RIGHT OF CENTERLINE, 2
FT AGL/804 FT MSL.
TREE 34 FT FROM DER, 184 FT RIGHT OF CENTERLINE, 808 FT MSL.
TREES, TRAVERSE WAYS BEGINNING 144 FT FROM DER, 321 FT LEFT OF
CENTERLINE, UP TO 841 FT MSL.
TREE 162 FT FROM DER, 364 FT RIGHT OF CENTERLINE, 809 FT MSL.
TRAVERSE WAYS BEGINNING 212 FT FROM DER, 279 FT RIGHT OF
CENTERLINE, UP TO 815 FT MSL.
903 FT MSL. 2505051409-2705051408EST
END PART 1 OF 4
!FDC 5/5902 PCZ PART 2 OF 4 ODP WAUPACA MUNI, WAUPACA, WI.
TREES BEGINNING 434 FT FROM DER, 329 FT LEFT OF CENTERLINE, UP TO
848 FT MSL.
TRAVERSE WAY 453 FT FROM DER, 397 FT RIGHT OF CENTERLINE, 817 FT
MSL.
TREES BEGINNING 541 FT FROM DER, 129 FT LEFT OF CENTERLINE, UP TO
852 FT MSL.
POLE, TREES, SIGN, TRAVERSE WAY BEGINNING 543 FT FROM DER, 125 FT
RIGHT OF CENTERLINE, UP TO 37 FT AGL/837 FT MSL.
TREES BEGINNING 1066 FT FROM DER, 308 FT RIGHT OF CENTERLINE, UP TO
838 FT MSL.
TREE 1100 FT FROM DER, 521 FT RIGHT OF CENTERLINE, 840 FT MSL.
TREES BEGINNING 1153 FT FROM DER, 417 FT RIGHT OF CENTERLINE, UP TO
857 FT MSL.
TREE 1645 FT FROM DER, 251 FT LEFT OF CENTERLINE, 863 FT MSL.
TREES BEGINNING 1760 FT FROM DER, 407 FT RIGHT OF CENTERLINE, UP TO
872 FT MSL.
TREE 3067 FT FROM DER, 900 FT RIGHT OF CENTERLINE, 880 FT MSL.
TREE 3406 FT FROM DER, 688 FT RIGHT OF CENTERLINE, 891 FT MSL. RWY
28: TERRAINS BEGINNING 33 FT FROM DER, 346 FT RIGHT OF CENTERLINE,
UP TO 848 FT MSL.
903 FT MSL. 2505051409-2705051408EST
END PART 2 OF 4
!FDC 5/5902 PCZ PART 3 OF 4 ODP WAUPACA MUNI, WAUPACA, WI.
TERRAIN 175 FT FROM DER, 486 FT LEFT OF CENTERLINE, 845 FT MSL.
BUILDING 232 FT FROM DER, 505 FT LEFT OF CENTERLINE, 859 FT MSL.
TREE 1080 FT FROM DER, 622 FT RIGHT OF CENTERLINE, 891 FT MSL. RWY
31: TERRAIN 130 FT FROM DER, 464 FT LEFT OF CENTERLINE, 832 FT MSL.
TRAVERSE WAYS BEGINNING 189 FT FROM DER, 498 FT LEFT OF CENTERLINE,
UP TO 847 FT MSL.
TRAVERSE WAY 315 FT FROM DER, 487 FT LEFT OF CENTERLINE, 848 FT
MSL.
TRAVERSE WAY 415 FT FROM DER, 508 FT LEFT OF CENTERLINE, 849 FT
MSL.
POLE, TRAVERSE WAYS, SIGN BEGINNING 512 FT FROM DER, 43 FT LEFT OF
CENTERLINE, UP TO 24 FT AGL/860 FT MSL.
TRAVERSE WAYS BEGINNING 677 FT FROM DER, 79 FT RIGHT OF CENTERLINE,
UP TO 850 FT MSL.
TRAVERSE WAYS BEGINNING 717 FT FROM DER, ON AND RIGHT OF
CENTERLINE, UP TO 851 FT MSL.
TREE 787 FT FROM DER, 565 FT RIGHT OF CENTERLINE, 865 FT MSL.
TREES BEGINNING 838 FT FROM DER, 67 FT RIGHT OF CENTERLINE, UP TO
887 FT MSL.
TREES BEGINNING 962 FT FROM DER, 89 FT LEFT OF CENTERLINE, UP TO
903 FT MSL. 2505051409-2705051408EST
END PART 3 OF 4
!FDC 5/5902 PCZ PART 4 OF 4 ODP WAUPACA MUNI, WAUPACA, WI.
861 FT MSL.
TREES BEGINNING 1080 FT FROM DER, 41 FT RIGHT OF CENTERLINE, UP TO
891 FT MSL.
TREES, TRAVERSE WAYS, POLE BEGINNING 1131 FT FROM DER, 187 FT LEFT
OF CENTERLINE, UP TO 894 FT MSL.
TREES, TRAVERSE WAYS BEGINNING 1485 FT FROM DER, 68 FT LEFT OF
CENTERLINE, UP TO 905 FT MSL.
TREES BEGINNING 1674 FT FROM DER, 210 FT RIGHT OF CENTERLINE, UP TO
896 FT MSL.
TREES BEGINNING 1755 FT FROM DER, 52 FT RIGHT OF CENTERLINE, UP TO
900 FT MSL.
TREES BEGINNING 1943 FT FROM DER, 148 FT LEFT OF CENTERLINE, UP TO
912 FT MSL.
TREES BEGINNING 2197 FT FROM DER, 22 FT RIGHT OF CENTERLINE, UP TO
903 FT MSL. 2505051409-2705051408EST
END PART 4 OF 4
|
