3/26/24 1507Z | 3/26/26 1507Z | | !FDC 4/1978 PZQ PART 1 OF 4 ODP PRESQUE ISLE COUNTY,
ROGERS CITY, MI.
TAKEOFF MINIMUMS AND (OBSTACLE) DEPARTURE PROCEDURES AMDT 2...
TAKEOFF OBSTACLE NOTES: RWY 9, TERRAIN 38 FT FROM DER, 205 FT
RIGHT OF CENTERLINE, 671 FT MSL.
TERRAIN 83 FT FROM DER, 501 FT RIGHT OF CENTERLINE, 692 FT MSL.
TREE 104 FT FROM DER, 400 FT LEFT OF CENTERLINE, 678 FT MSL.
TREES BEGINNING 125 FT FROM DER, 261 FT RIGHT OF CENTERLINE, UP TO
706 FT MSL.
TREE 165 FT FROM DER, 496 FT LEFT OF CENTERLINE, 688 FT MSL.
TREE 198 FT FROM DER, 397 FT RIGHT OF CENTERLINE, 31 FT AGL/708 FT
MSL.
TREE 209 FT FROM DER, 423 FT RIGHT OF CENTERLINE, 711 FT MSL.
TREE, TRAVERSE WAYS BEGINNING 215 FT FROM DER, 64 FT LEFT OF
CENTERLINE, UP TO 691 FT MSL.
TRANSMISSION LINES, POLES, TREES, TRAVERSE WAYS BEGINNING 281 FT
FROM DER, 28 FT RIGHT OF CENTERLINE, UP TO 50 FT AGL/726 FT MSL.
TREES BEGINNING 369 FT FROM DER, 326 FT LEFT OF CENTERLINE, UP TO
713 FT MSL.
TREE 432 FT FROM DER, 472 FT LEFT OF CENTERLINE, 714 FT MSL.
TREES, CATENARY WIRES, TRANSMISSION LINES, POLES BEGINNING 505 FT
FROM DER, 72 FT LEFT OF CENTERLINE, UP TO 717 FT MSL.
2403261507-2603261507EST
END PART 1 OF 4
!FDC 4/1978 PZQ PART 2 OF 4 ODP PRESQUE ISLE COUNTY,
ROGERS CITY, MI.
TREE 2056 FT FROM DER, 988 FT RIGHT OF CENTERLINE, 727 FT MSL.
TREE 2146 FT FROM DER, 921 FT RIGHT OF CENTERLINE, 729 FT MSL.
RWY 27, TREE 22 FT FROM DER, 423 FT RIGHT OF CENTERLINE, 705 FT
MSL.
TRAVERSE WAYS, TERRAIN, SIGN, FENCE BEGINNING 23 FT FROM DER, 194
FT LEFT OF CENTERLINE, UP TO 687 FT MSL.
TREE 57 FT FROM DER, 510 FT RIGHT OF CENTERLINE, 706 FT MSL.
TREE 152 FT FROM DER, 408 FT RIGHT OF CENTERLINE, 53 FT AGL/711 FT
MSL.
TREES BEGINNING 221 FT FROM DER, 370 FT RIGHT OF CENTERLINE, UP TO
713 FT MSL.
TREE, TRAVERSE WAYS, FENCE BEGINNING 258 FT FROM DER, 95 FT LEFT OF
CENTERLINE, UP TO 738 FT MSL.
TREE, TRAVERSE WAY BEGINNING 381 FT FROM DER, 109 FT LEFT OF
CENTERLINE, UP TO 741 FT MSL.
TREES, TRAVERSE WAY BEGINNING 405 FT FROM DER, 68 FT RIGHT OF
CENTERLINE, UP TO 719 FT MSL.
TREE 486 FT FROM DER, 451 FT LEFT OF CENTERLINE, 755 FT MSL.
TREES, BUILDING, TERRAIN, POLES, TRANSMISSION LINES, TRAVERSE WAY,
CATENARY WIRES BEGINNING 490 FT FROM DER, 29 FT LEFT OF CENTERLINE,
2403261507-2603261507EST
END PART 2 OF 4
!FDC 4/1978 PZQ PART 3 OF 4 ODP PRESQUE ISLE COUNTY,
ROGERS CITY, MI.
UP TO 761 FT MSL.
TREES, TRAVERSE WAY BEGINNING 557 FT FROM DER, 274 FT RIGHT OF
CENTERLINE, UP TO 724 FT MSL.
TREES, POLES, TRANSMISSION LINES, CATENARY WIRE BEGINNING 730 FT
FROM DER, 101 FT RIGHT OF CENTERLINE, UP TO 741 FT MSL.
TREES BEGINNING 1003 FT FROM DER, 527 FT LEFT OF CENTERLINE, UP TO
765 FT MSL.
TREES BEGINNING 1102 FT FROM DER, 322 FT RIGHT OF CENTERLINE, UP TO
744 FT MSL.
TREES BEGINNING 1490 FT FROM DER, 690 FT LEFT OF CENTERLINE, UP TO
768 FT MSL.
TREES BEGINNING 1586 FT FROM DER, 20 FT LEFT OF CENTERLINE, UP TO
771 FT MSL.
TREE 1854 FT FROM DER, 219 FT RIGHT OF CENTERLINE, 745 FT MSL.
TREES BEGINNING 1857 FT FROM DER, 88 FT RIGHT OF CENTERLINE, UP TO
752 FT MSL.
TREES BEGINNING 2075 FT FROM DER, 1 FT RIGHT OF CENTERLINE, UP TO
761 FT MSL.
TREES BEGINNING 2457 FT FROM DER, 2 FT RIGHT OF CENTERLINE, UP TO
762 FT MSL.
2403261507-2603261507EST
END PART 3 OF 4
!FDC 4/1978 PZQ PART 4 OF 4 ODP PRESQUE ISLE COUNTY,
ROGERS CITY, MI.
TREES BEGINNING 2812 FT FROM DER, 57 FT LEFT OF CENTERLINE, UP TO
775 FT MSL.
TREES BEGINNING 2897 FT FROM DER, 18 FT LEFT OF CENTERLINE, UP TO
111 FT AGL/793 FT MSL. ALL OTHER DATA REMAINS AS PUBLISHED.
2403261507-2603261507EST
END PART 4 OF 4
|
