12/5/231607Z
|
!FDC 3/0988 SAR PART 1 OF 2 ODP SPARTA COMMUNITY-HUNTER FLD,
SPARTA, IL.
TAKEOFF MINIMUMS AND (OBSTACLE) DEPARTURE PROCEDURES AMDT 1...
TAKEOFF OBSTACLE NOTES: NOTE: RWY 18, TAKEOFF OBSTACLE NOTES: NOTE:
RWY 18, NOTE: RWY 18: SIGN 11 FT FROM DER, 151 FT RIGHT OF
CENTERLINE, 1 FT AGL/526 FT MSL. POLE 39 FT FROM DER, 503 FT RIGHT
OF CENTERLINE, 554 FT MSL. POLE 41 FT FROM DER, 495 FT RIGHT OF
CENTERLINE, 27 FT AGL/555 FT MSL. TREE 118 FT FROM DER, 144 FT LEFT
OF CENTERLINE, 526 FT MSL. POLE, BUILDING, TRAVERSE WAY BEGINNING
282 FT FROM DER, 144 FT RIGHT OF CENTERLINE, UP TO 29 FT AGL/557 FT
MSL. POLE, BUILDING BEGINNING 694 FT FROM DER, 370 FT RIGHT OF
CENTERLINE, UP TO 40 FT AGL/572 FT MSL. POLE BEGINNING 1312 FT FROM
DER, 248 FT RIGHT OF CENTERLINE, UP TO 40 FT AGL/573 FT MSL. POLE
BEGINNING 1687 FT FROM DER, 370 FT RIGHT OF CENTERLINE, UP TO 41 FT
AGL/574 FT MSL. TREE 1780 FT FROM DER, 68 FT LEFT OF CENTERLINE,
570 FT MSL. TREE, TRANSMISSION LINE, POLE BEGINNING 1782 FT FROM
DER, 8 FT RIGHT OF CENTERLINE, UP TO 582 FT MSL. TREES BEGINNING
1790 FT FROM DER, 21 FT LEFT OF CENTERLINE, UP TO 577 FT MSL. TREES
BEGINNING 1795 FT FROM DER, 193 FT LEFT OF CENTERLINE, UP TO 580 FT
MSL. TOWER, TREE BEGINNING 1837 FT FROM DER, 488 FT RIGHT OF
CENTERLINE, UP TO 53 FT AGL/590 FT MSL. TREES BEGINNING 2089 FT
FROM DER, 231 FT LEFT OF CENTERLINE, UP TO 582 FT MSL. TREE 2475 FT
ALL OTHER DATA REMAINS AS PUBLISHED. 2312051607-2512051607EST
END PART 1 OF 2
!FDC 3/0988 SAR PART 2 OF 2 ODP SPARTA COMMUNITY-HUNTER FLD,
SPARTA, IL.
FROM DER, 225 FT LEFT OF CENTERLINE, 589 FT MSL. TREE 2656 FT FROM
DER, 426 FT LEFT OF CENTERLINE, 590 FT MSL. TREE 3074 FT FROM DER,
337 FT RIGHT OF CENTERLINE, 606 FT MSL. TREES BEGINNING 3078 FT
FROM DER, 202 FT RIGHT OF CENTERLINE, UP TO 611 FT MSL. TREE 3199
FT FROM DER, 1126 FT LEFT OF CENTERLINE, 603 FT MSL. TREE 3219 FT
FROM DER, 1180 FT RIGHT OF CENTERLINE, 615 FT MSL. TREE 3902 FT
FROM DER, 1321 FT RIGHT OF CENTERLINE, 630 FT MSL. TANK 5237 FT
FROM DER, 666 FT RIGHT OF CENTERLINE, 138 FT AGL/669 FT MSL. NOTE:
RWY 36, NOTE: RWY 36: TREES BEGINNING 173 FT FROM DER, 168 FT LEFT
OF CENTERLINE, UP TO 605 FT MSL.
TREE 611 FT FROM DER, 564 FT RIGHT OF CENTERLINE, 602 FT MSL. TREES
BEGINNING 746 FT FROM DER, 413 FT RIGHT OF CENTERLINE, UP TO 619 FT
MSL.
ALL OTHER DATA REMAINS AS PUBLISHED. 2312051607-2512051607EST
END PART 2 OF 2
|
