!FDC 3/8091 THA PART 1 OF 5 ODP TULLAHOMA RGNL/WM NORTHERN FLD,
TULLAHOMA, TN.
TAKEOFF MINIMUMS AND (OBSTACLE) DEPARTURE PROCEDURES AMDT 1...
TEXTUAL DEPARTURE PROCEDURE TAKEOFF MINIMUMS AND (OBSTACLE)
DEPARTURE PROCEDURES AMDT ... TAKEOFF OBSTACLE NOTE: RWY 6:
BUILDING, FENCE, TREE BEGINNING 77 FT FROM DER, 393 FT RIGHT OF
CENTERLINE, UP TO 20 FT AGL/1098 FT MSL. TREE 121 FT FROM DER, 505
FT LEFT OF CENTERLINE, 1101 FT MSL. TREES BEGINNING 145 FT FROM
DER, 27 FT RIGHT OF CENTERLINE, UP TO 1110 FT MSL. TREE 200 FT FROM
DER, 380 FT LEFT OF CENTERLINE, 1105 FT MSL. TREES BEGINNING 229 FT
FROM DER, 21 FT LEFT OF CENTERLINE, UP TO 1111 FT MSL. TREES
BEGINNING 585 FT FROM DER, 44 FT LEFT OF CENTERLINE, UP TO 1117 FT
MSL. TREE 593 FT FROM DER, 211 FT RIGHT OF CENTERLINE, 1124 FT MSL.
TREES BEGINNING 612 FT FROM DER, 10 FT RIGHT OF CENTERLINE, UP TO
1134 FT MSL. TREE, POLE, TRANSMISSION LINE BEGINNING 671 FT FROM
DER, 4 FT LEFT OF CENTERLINE, UP TO 1119 FT MSL. TREE, POLE
BEGINNING 1264 FT FROM DER, 1 FT RIGHT OF CENTERLINE, UP TO 1144 FT
MSL. TREE 2190 FT FROM DER, 14 FT LEFT OF CENTERLINE, 1139 FT MSL.
TREE 2345 FT FROM DER, 748 FT LEFT OF CENTERLINE, 1147 FT MSL.
TREES BEGINNING 2360 FT FROM DER, 125 FT LEFT OF CENTERLINE, UP TO
1173 FT MSL. TREE 2390 FT FROM DER, 56 FT RIGHT OF CENTERLINE, 1158
FT MSL. TREE 2424 FT FROM DER, 179 FT RIGHT OF CENTERLINE, 1167 FT
ALL OTHER DATA REMAINS AS PUBLISHED. 2310021350-2405131350EST
