3/6/231341Z
|
!FDC 3/3215 TIX PART 1 OF 5 ODP SPACE COAST RGNL, TITUSVILLE, FL.
TAKEOFF MINIMUMS AND (OBSTACLE) DEPARTURE PROCEDURES ORIG...
NOTE: RWY 9, LIGHT POLES 2 FT FROM DER, 39 FT RIGHT OF CENTERLINE,
1 FT AGL/32 FT MSL.
LIGHT POLES BEGINNING 2 FT FROM DER, 31 FT LEFT OF CENTERLINE, UP
TO 1 FT AGL/32 FT MSL.
SIGN, LIGHT POLES BEGINNING 37 FT FROM DER, 88 FT RIGHT OF
CENTERLINE, UP TO 3 FT AGL/34 FT MSL.
SIGN, LIGHT POLES BEGINNING 39 FT FROM DER, 89 FT LEFT OF
CENTERLINE, UP TO 3 FT AGL/34 FT MSL.
TREE 341 FT FROM DER, 582 FT LEFT OF CENTERLINE, 61 FT MSL.
TREES BEGINNING 506 FT FROM DER, 478 FT LEFT OF CENTERLINE, UP TO
70 FT MSL.
POLE, TREE BEGINNING 622 FT FROM DER, 72 FT RIGHT OF CENTERLINE, UP
TO 53 FT AGL/86 FT MSL.
TREES BEGINNING 753 FT FROM DER, 662 FT LEFT OF CENTERLINE, UP TO
77 FT MSL.
TREE, POLE BEGINNING 911 FT FROM DER, 12 FT LEFT OF CENTERLINE, UP
TO 83 FT MSL.
TREE, POLE BEGINNING 1286 FT FROM DER, 346 FT LEFT OF CENTERLINE,
UP TO 92 FT MSL.
ALL OTHER DATA REMAINS AS PUBLISHED. 2303061341-2503061341EST
END PART 1 OF 5
!FDC 3/3215 TIX PART 2 OF 5 ODP SPACE COAST RGNL, TITUSVILLE, FL.
TREE, POLE BEGINNING 1439 FT FROM DER, 294 FT LEFT OF CENTERLINE,
UP TO 97 FT MSL.
TREES BEGINNING 2052 FT FROM DER, 305 FT LEFT OF CENTERLINE, UP TO
99 FT MSL.
NOTE: RWY 18, LIGHT POLES 39 FT FROM DER, 114 FT RIGHT OF
CENTERLINE, 3 FT AGL/35 FT MSL.
LIGHT POLES 40 FT FROM DER, 113 FT LEFT OF CENTERLINE, 3 FT AGL/36
FT MSL.
TREE 1054 FT FROM DER, 216 FT RIGHT OF CENTERLINE, 63 FT MSL.
TREE 1085 FT FROM DER, 192 FT LEFT OF CENTERLINE, 66 FT MSL.
TREE 1086 FT FROM DER, 121 FT RIGHT OF CENTERLINE, 65 FT MSL.
TREE 1214 FT FROM DER, 590 FT LEFT OF CENTERLINE, 79 FT MSL.
TREE 1295 FT FROM DER, 195 FT RIGHT OF CENTERLINE, 68 FT MSL.
TREE 1297 FT FROM DER, 843 FT LEFT OF CENTERLINE, 81 FT MSL.
TREE 1327 FT FROM DER, 239 FT RIGHT OF CENTERLINE, 69 FT MSL.
TREE 1452 FT FROM DER, 265 FT RIGHT OF CENTERLINE, 72 FT MSL.
TREES BEGINNING 1521 FT FROM DER, 203 FT LEFT OF CENTERLINE, UP TO
88 FT MSL.
TREES BEGINNING 1596 FT FROM DER, 638 FT LEFT OF CENTERLINE, UP TO
95 FT MSL.
ALL OTHER DATA REMAINS AS PUBLISHED. 2303061341-2503061341EST
END PART 2 OF 5
!FDC 3/3215 TIX PART 3 OF 5 ODP SPACE COAST RGNL, TITUSVILLE, FL.
NOTE: RWY 27, LIGHT POLES BEGINNING 7 FT FROM DER, 26 FT RIGHT OF
CENTERLINE, UP TO 2 FT AGL/33 FT MSL.
LIGHT POLES BEGINNING 8 FT FROM DER, 26 FT LEFT OF CENTERLINE, UP
TO 2 FT AGL/33 FT MSL.
TREE 47 FT FROM DER, 461 FT RIGHT OF CENTERLINE, 69 FT MSL.
TREE 57 FT FROM DER, 469 FT LEFT OF CENTERLINE, 55 FT MSL.
TREES BEGINNING 322 FT FROM DER, 504 FT RIGHT OF CENTERLINE, UP TO
77 FT MSL.
TREE 427 FT FROM DER, 525 FT LEFT OF CENTERLINE, 59 FT MSL.
TREES BEGINNING 530 FT FROM DER, 460 FT LEFT OF CENTERLINE, UP TO
62 FT MSL.
TREE 738 FT FROM DER, 599 FT RIGHT OF CENTERLINE, 83 FT MSL.
TREE, POLE BEGINNING 853 FT FROM DER, 10 FT RIGHT OF CENTERLINE, UP
TO 85 FT MSL.
POLE 1119 FT FROM DER, 475 FT LEFT OF CENTERLINE, 39 FT AGL/63 FT
MSL.
TREE 1193 FT FROM DER, 28 FT LEFT OF CENTERLINE, 72 FT MSL.
TREES BEGINNING 1205 FT FROM DER, 11 FT LEFT OF CENTERLINE, UP TO
75 FT MSL.
TREES BEGINNING 1228 FT FROM DER, 2 FT LEFT OF CENTERLINE, UP TO 78
ALL OTHER DATA REMAINS AS PUBLISHED. 2303061341-2503061341EST
END PART 3 OF 5
!FDC 3/3215 TIX PART 4 OF 5 ODP SPACE COAST RGNL, TITUSVILLE, FL.
FT MSL.
TREES BEGINNING 1392 FT FROM DER, 576 FT RIGHT OF CENTERLINE, UP TO
91 FT MSL.
TREE 3010 FT FROM DER, 1300 FT LEFT OF CENTERLINE, 112 FT MSL.
NOTE: RWY 36, TREE, POLE BEGINNING 2 FT FROM DER, 440 FT RIGHT OF
CENTERLINE, UP TO 61 FT MSL.
TREES BEGINNING 1325 FT FROM DER, 47 FT RIGHT OF CENTERLINE, UP TO
95 FT MSL.
TREES BEGINNING 1359 FT FROM DER, 107 FT LEFT OF CENTERLINE, UP TO
87 FT MSL.
TREES BEGINNING 1494 FT FROM DER, 2 FT LEFT OF CENTERLINE, UP TO
100 FT MSL.
TREES BEGINNING 1521 FT FROM DER, 36 FT RIGHT OF CENTERLINE, UP TO
98 FT MSL.
TREES BEGINNING 1699 FT FROM DER, 6 FT LEFT OF CENTERLINE, UP TO
103 FT MSL.
TREE 1998 FT FROM DER, 85 FT RIGHT OF CENTERLINE, 99 FT MSL.
TREES BEGINNING 2102 FT FROM DER, 108 FT RIGHT OF CENTERLINE, UP TO
106 FT MSL.
TREES BEGINNING 2505 FT FROM DER, 267 FT RIGHT OF CENTERLINE, UP TO
ALL OTHER DATA REMAINS AS PUBLISHED. 2303061341-2503061341EST
END PART 4 OF 5
!FDC 3/3215 TIX PART 5 OF 5 ODP SPACE COAST RGNL, TITUSVILLE, FL.
110 FT MSL.
ALL OTHER DATA REMAINS AS PUBLISHED. 2303061341-2503061341EST
END PART 5 OF 5
|
