iFlightPlanner



...
TAMPA INTL - Airport Diagram
LiveATC.net: Live Air Traffic - From Their Headsets to You

KTPA
TAMPA INTL
PublicPUB

6 miles W of TAMPA, FL
LiveATC.net: Live Air Traffic - From Their Headsets to You
Operational
27° 58' 32"N 82° 31' 60"W
26' MSL
1026' MSL
05° W (2010)
Jet A, 100LL
SAINT PETERSBURG (PIE)
MIAMI
JACKSONVILLE (ZJX)
9/10/20-10/8/20
KTPA VFR
6:53 AM EDT
Scattered 28,000'
Few 4,200'
10sm
80°F
74°F
29.98"Hg
Calm
AO2 SLP150 T02670233
KTPA 261053Z 00000KT 10SM FEW042 SCT280 27/23 A2998 RMK AO2 SLP150 T02670233

KTPA FBOs, Flight Schools and Ground Support

Sheltair
Freq: 130.600
Phone: (813) 319-8000
No Rating Available
0 Reviews (Read | Sign In To Write)
Avfuel
Fuel as of 8/11 100LL SS-- 100LL FS$6.99 Jet A$6.23 Jet A+-- MoGas--
Signature Flight Support
Freq: 130.000
Phone: (813) 870-3813
No Rating Available
0 Reviews (Read | Sign In To Write)
Shell
Fuel as of 9/23 100LL SS-- 100LL FS$5.76 Jet A$6.03 Jet A+-- MoGas--

KTPA Ground Transportation (Taxi, Limo, Car Service)

No ground transportation services are listed for this airport.

KTPA Hotels

No hotels are listed for this airport.

KTPA Restaurants

No restaurants are listed for this airport.

KTPA Other Airport-Related Businesses

No other airport-related businesses are listed for this airport.
X

Send Message to Airport Company
Enter your information and message below.

Your Information

Processing
122.950 N/A

ATIS

D-ATIS
ARR
126.450
D-ATIS
DEP
128.475

ASOS

ASOS
813-873-7228
126.450

Approach/Departure

APCH/P DEP/P
001-150
118.150
APCH/P DEP/P
220-360
118.800
APCH/P DEP/P
151-219
119.650
APCH/P DEP/P IC
118.500

Clearance Delivery

CD/P
133.600

Emergency

EMERG
121.500

Ground

GND/P
121.700
GND/S
121.350

Tower

LCL/P
119.500
LCL/S
119.050

Other

BAYPO DP
118.800
BLOND STAR
118.800
BRDGE STAR
119.650
CLASS B
151-219
119.650
CLASS B
001-150
119.900
CLASS B
220-360
125.300
CROWD DP
135.500
DADES STAR
135.500
DARBS STAR
118.800
DEAKK STAR
119.650
ENDED DP
118.800
FOOXX STAR
118.800
GANDY DP
119.650
LGTNG DP
118.800
LZARD STAR
135.500
SYKES DP
118.800
TAMPA DP
135.500

Terminal Area Forecast

KTPA
Sat, 9/26 5:00 AM EDT
Sat, 9/26 5:00 AM EDT - Sun, 9/27 8:00 AM EDT
VFR
5:00 AM EDT - 2:00 PM EDT
Scattered 4,000'
> 6sm
N/A
VRB° 3kts
VFR
2:00 PM EDT - 4:00 PM EDT
Scattered 10,000'
> 6sm
N/A
250° 6kts
VFR
4:00 PM EDT - 7:00 PM EDT
Scattered 10,000'
> 6sm
N/A
280° 7kts
VFR
7:00 PM EDT - 11:00 PM EDT
Few 10,000'
> 6sm
N/A
310° 6kts
VFR
11:00 PM EDT - 8:00 AM EDT
Few 15,000'
> 6sm
N/A
VRB° 3kts
KTPA 260900Z 2609/2712 VRB03KT P6SM SCT040
   FM261800 25006KT P6SM SCT100
   FM262000 28007KT P6SM SCT100
   FM262300 31006KT P6SM FEW100
   FM270300 VRB03KT P6SM FEW150
KTPA NOTAMs
Domestic
9/28/201200Z !TPA 09/236 TPA SVC MBST/WS DETECTION SYSTEM NOT AVBL 2009281200-2009282000
9/26/201130Z !TPA 09/249 TPA OBST CRANE (ASN UNKNOWN) 275803N0823044W (1.2NM SE
TPA) 103FT (74FT AGL) FLAGGED AND LGTD 2009261130-2009261800
9/24/201831Z !TPA 09/260 TPA TWY C4, C5, C6 CLSD 2009241831-2011192100
9/24/201827Z !TPA 09/259 TPA TWY C CL MARKINGS BTN TWY G2 AND TWY G5 NOT STD 2009241827-2011302100
9/24/201334Z !TPA 09/258 TPA TWY C1, C2, C3, D1, D2, D3, F1, TWY C BTN TWY C1 AND RWY 10/28, TWY D BTN TWY D1 AND TWY F2, TWY S BTN TWY C AND TWY D CLSD 2009241334-2011192300
9/23/200944Z !TPA 09/245 TPA OBST TOWER LGT (ASR 1046091) 280113.00N0823630.00W (4.7NM NW TPA) 473.8FT (465.9FT AGL) U/S 2009230944-2010080943
9/22/201509Z !TPA 09/242 TPA TWY S LOCATION SIGN SOUTH SIDE BTN TWY R3 AND TWY D OBSC 2009221509-2011010300
9/21/201200Z !TPA 09/162 TPA RWY 28 PAPI U/S 2009211200-2010102200
9/21/201200Z !TPA 09/161 TPA RWY 10 PAPI U/S 2009211200-2010102200
9/21/200635Z !TPA 09/235 TPA OBST TOWER LGT (ASR 1037021) 280445.20N0823354.70W (6.4NM NNW TPA) 240.2FT (204.1FT AGL) U/S 2009210635-2010060535
9/19/201603Z !TPA 09/234 TPA OBST TOWER LGT (ASR 1220913) 280013.90N0823021.80W (2.3NM NE TPA) 216.9FT (187.0FT AGL) U/S 2009191603-2010040400
9/19/201139Z !TPA 09/232 TPA APRON TXL G BTN TWY G6 AND TXL U CLSD TO ACFT WINGSPAN MORE THAN 118FT 2009191139-2011042100
9/19/201139Z !TPA 09/231 TPA APRON TXL G SFC MARKINGS NOT STD BTN TWY G6 AND TXL U 2009191139-2011192200
9/17/202220Z !TPA 09/217 TPA TWY E SFC MARKINGS BTN GND RUNUP ENCLOSURE RAMP AND AIRBORNE NORTH RAMP NOT STD 2009172220-2010312300
9/17/201320Z !TPA 09/199 TPA APRON TXL F SOUTH OF TWY F1 CLSD 2009171320-2011192200
9/17/200054Z !TPA 09/189 TPA TWY B1, B2, TWY B BTN TWY V AND TWY C CLSD 2009170054-2011032200
9/11/200807Z !TPA 09/145 TPA TWY J LGT BTN TXL K AND TWY L OBSC 2009110807-2009302200
9/9/201130Z !TPA 09/108 TPA RWY 01R PAPI U/S 2009091130-2011192200
9/9/201130Z !TPA 09/107 TPA NAV ILS RWY 01R LOC/DME U/S 2009091130-2011192200
9/9/201130Z !TPA 09/106 TPA RWY 19L PAPI U/S 2009091130-2011192200
9/9/201130Z !TPA 09/105 TPA RWY 19L ALS U/S 2009091130-2011192200
9/9/201130Z !TPA 09/104 TPA NAV ILS RWY 19L LOC/GP/IM U/S 2009091130-2011192200
9/9/201130Z !TPA 09/102 TPA RWY 01R/19L CLSD 2009091130-2011192100
9/8/200552Z !TPA 09/092 TPA TWY J CL MARKINGS BTN TWY J2 AND TWY V NOT STD 2009080552-2101312300
9/4/201853Z !TPA 09/051 TPA TWY W CL MARKINGS BTN TWY W5 AND TWY W6 NOT STD 2009041853-2101312300
9/4/201851Z !TPA 09/049 TPA RWY 01L/19R CL MARKINGS NOT STD 2009041851-2101312300
9/4/201850Z !TPA 09/048 TPA RWY 19R LEAD OFF CL MARKINGS AT TWY W4 NOT STD 2009041850-2101312300
9/4/201850Z !TPA 09/047 TPA RWY 19R LEAD OFF CL MARKINGS AT TWY W3 NOT STD
2009041850-2101312300
9/4/201433Z !TPA 09/046 TPA TWY A LOCATION SIGN SOUTH SIDE BTN TWY V AND TWY W MISSING 2009041433-2012312300
9/2/202308Z !TPA 09/016 TPA OBST TOWER LGT (ASR 1250334) 275852.10N0823106.10W (0.9NM ENE TPA) 191.6FT (158.8FT AGL) U/S 2009022308-2010022359
8/27/200402Z !TPA 08/272 TPA RWY 19R RAI LGT U/S 2008270402-2106072000EST
8/24/200742Z !TPA 08/247 TPA TWY S EDGE LGT BTN TWY E AND TWY S1 OBSC 2008240742-2010102200
8/24/200741Z !TPA 08/246 TPA TWY N EDGE LGT BTN TWY C AND TWY N4 OBSC 2008240741-2010102200
8/22/202152Z !TPA 08/223 TPA TWY C7 HLDG PSN MARKINGS NOT STD 2008222152-2010022200
8/22/200633Z !TPA 08/222 TPA TWY C EDGE MARKINGS BTN TWY C6 AND TWY C7 WEST SIDE NOT STD 2008220633-2010022200
8/22/200631Z !TPA 08/221 TPA TWY C7 SFC PAINTED HLDG PSN SIGNS NOT STD 2008220631-2010022200
8/22/200552Z !TPA 08/220 TPA TWY C CL MARKINGS BTN TWY C6 AND TWY C7 NOT STD 2008220552-2010022200
8/19/201953Z !TPA 08/192 TPA TWY C LOCATION SIGN WEST SIDE FOR TWY J OBSC 2008191953-2010010400
8/19/201950Z !TPA 08/191 TPA TWY C LOCATION SIGN WEST SIDE BTN TWY J AND TWY N OBSC 2008191950-2010010400
7/30/200802Z !TPA 07/298 TPA TWY E BTN AIRBORNE NORTH RAMP AND APCH END RWY 19L CLSD TO ACFT WINGSPAN MORE THAN 118FT 2007300802-2108022300
7/28/201121Z !TPA 07/277 TPA RWY 19L TDZ CL MARKING OBSC 2007281121-2010312300
5/1/201000Z !TPA 04/170 TPA OBST CRANE (ASN UNKNOWN) 275652N0822801W (2.15NM NW TPA)
320FT (300FT AGL) FLAGGED AND LGTD DLY 1000-2300 2005011000-2111302300
3/29/200548Z !TPA 03/160 TPA OBST CRANE (ASN 2019-ASO-4859-NRA) 275750N0823212W (0.7NM SSW TPA) 245FT (232FT AGL) FLAGGED AND LGTD 2003290548-2012312300
2/5/201057Z !TPA 02/041 TPA NAV ILS RWY 19L OM U/S 2002051057-2012182000EST
2/5/201056Z !TPA 02/040 TPA NAV ILS RWY 19L COSME LOM U/S 2002051056-2012182000EST
FDC
9/25/201421Z !FDC 0/1764 TPA IAP TAMPA INTL, TAMPA, FL.
LOC RWY 1R, AMDT 4...
ZELTO FIX MINIMUMS (DUAL VOR RECEIVERS OR DME REQUIRED)
CIRCLING CATS A/B MDA 660/HAA 634.
TEMPORARY CRANES 350 MSL 2.07NM SE OF KTPA (2020-ASO-6634/6642-OE).
2009251421-2011021421EST
9/25/201421Z !FDC 0/1761 TPA IAP TAMPA INTL, TAMPA, FL.
RNAV (GPS) RWY 19R, AMDT 2C...
RNAV (GPS) RWY 1L, AMDT 2C...
RNAV (GPS) RWY 28, AMDT 1B...
RNAV (GPS) Z RWY 19L, AMDT 2E...
CIRCLING CATS A/B/C/D MDA 660/HAA 634.
TEMPORARY CRANES 350 MSL 2.07NM SE OF KTPA (2020-ASO-6634/6642-OE).
2009251421-2011021421EST
9/25/201421Z !FDC 0/1760 TPA IAP TAMPA INTL, TAMPA, FL.
ILS OR LOC RWY 19L, AMDT 40D...
ILS OR LOC RWY 19R, AMDT 6...
ILS OR LOC RWY 1L, AMDT 18...
RNAV (GPS) RWY 10, AMDT 2A...
RNAV (GPS) RWY 1R, AMDT 3...
CIRCLING CATS A/B MDA 660/HAA 634.
TEMPORARY CRANES 350 MSL 2.07NM SE OF KTPA (2020-ASO-6634/6642-OE).
2009251421-2011021421EST
9/23/201311Z !FDC 0/9407 TPA IAP TAMPA INTL, TAMPA, FL.
RNAV (RNP) Y RWY 19L, AMDT 1E...
RNP 0.23 DA 377/HAT 351 ALL CATS.
TEMPORARY CRANE 91 MSL 4617FT NW OF RWY 19L (2020-ASO-11744-OE).
2009231311-2103301307EST
9/1/202256Z !FDC 0/2413 TPA SID TAMPA INTL, TAMPA, FL.
LGTNG THREE DEPARTURE...
TAMPA SEVEN DEPARTURE...
TAKEOFF MINIMUMS: RWY 19L: 200-1 1/2 OR STANDARD WITH MINIMUM CLIMB
OF 245FT PER NM TO 300, OR ALTERNATIVELY, WITH STANDARD TAKEOFF
MINIMUMS AND A NORMAL 200FT PER NM CLIMB GRADIENT, TAKEOFF MUST
OCCUR NO LATER THAN 1500FT PRIOR TO DEPARTURE END OF RUNWAY.
TAKEOFF OBSTACLE NOTES: RWY 19L: TEMPORARY CRANES BEGINNING 2604FT
FROM DER, 963FT RIGHT OF CENTERLINE, UP TO 100FT AGL/115FT MSL
(2019-ASO-16288-OE, 2019-ASO-18466/67/68/69/71-OE).
ALL OTHER DATA REMAINS AS PUBLISHED. 2009012256-2104132256EST
9/1/202256Z !FDC 0/2412 TPA ODP TAMPA INTL, TAMPA, FL.
TAKEOFF MINIMUMS AND (OBSTACLE) DEPARTURE PROCEDURES AMDT 10...
TAKEOFF MINIMUMS: RWY 19L, 200-1 1/2 OR STANDARD WITH MINIMUM CLIMB
OF 245FT PER NM TO 300, OR ALTERNATIVELY, WITH STANDARD TAKEOFF
MINIMUMS AND A NORMAL 200FT PER NM CLIMB GRADIENT, TAKEOFF MUST
OCCUR NO LATER THAN 1500FT PRIOR TO DEPARTURE END OF RUNWAY.
TAKEOFF OBSTACLE NOTES: RWY 19L, TEMPORARY CRANES BEGINNING 2604FT
FROM DER, 963FT RIGHT OF CENTERLINE, UP TO 100FT AGL/115FT MSL
(2019-ASO-16288-OE, 2019-ASO-18466/67/68/69/71-OE).
ALL OTHER DATA REMAINS AS PUBLISHED. 2009012256-2104132256EST
8/31/201400Z !FDC 0/0436 TPA STAR TAMPA INTERNATIONAL AIRPORT, TAMPA,FL
BRDGE EIGHT ARRIVAL...
BRDGE STAR UNUSABLE FM ROGAN TO BRDGE BLW 5,000 FT.
2008311400-2104010000
7/24/201515Z !FDC 0/4469 TPA IAP TAMPA INTL, TAMPA, FL.
RNAV (GPS) Z RWY 19L, AMDT 2E...
CHART CIRCLING ICON. CIRCLING CAT C MDA 680/HAA 654 VIS 1 3/4, CAT
D MDA 980/HAA 954 VIS 3. ALTERNATE MINIMUMS: STANDARD EXCEPT CAT D
1000-3.
THIS IS RNAV (GPS) Z RWY 19L, AMDT 2F. 2007241515-PERM
7/24/201515Z !FDC 0/4468 TPA IAP TAMPA INTL, TAMPA, FL.
RNAV (GPS) RWY 28, AMDT 1B...
CHART CIRCLING ICON. CIRCLING CAT C MDA 680/HAA 654 VIS 1 3/4, CAT
D MDA 980/HAA 954 VIS 3. ALTERNATE MINIMUMS: STANDARD EXCEPT CAT D
1000-3.
THIS IS RNAV (GPS) RWY 28, AMDT 1C. 2007241515-PERM
7/24/201515Z !FDC 0/4467 TPA IAP TAMPA INTL, TAMPA, FL.
RNAV (GPS) RWY 19R, AMDT 2C...
CHART CIRCLING ICON. CIRCLING CAT C MDA 680/HAA 654 VIS 1 3/4, CAT
D MDA 980/HAA 954 VIS 3. ALTERNATE MINIMUMS: STANDARD EXCEPT CAT
D,E 1000-3.
THIS IS RNAV (GPS) RWY 19R, AMDT 2D. 2007241515-PERM
7/24/201515Z !FDC 0/4466 TPA IAP TAMPA INTL, TAMPA, FL.
RNAV (GPS) RWY 1R, AMDT 3...
CHART CIRCLING ICON.
THIS IS RNAV (GPS) RWY 1R, AMDT 3A. 2007241515-PERM
7/24/201515Z !FDC 0/4465 TPA IAP TAMPA INTL, TAMPA, FL.
RNAV (GPS) RWY 1L, AMDT 2C...
CHART CIRCLING ICON. CIRCLING CAT C MDA 680/HAA 654 VIS 1 3/4, CAT
D MDA 980/HAA 954 VIS 3. ALTERNATE MINIMUMS: STANDARD EXCEPT CAT
D,E 1000-3.
THIS IS RNAV (GPS) RWY 1L, AMDT 2D. 2007241515-PERM
5/22/191328Z !FDC 9/1465 TPA IAP TAMPA INTL, Tampa, FL.
LOC RWY 1R, AMDT 4...
DME REQUIRED EXCEPT FOR ACFT EQUIPPED WITH SUITABLE RNAV SYSTEM
WITH GPS.
1905221328-2105221328EST
5/13/191808Z !FDC 9/6387 TPA IAP TAMPA INTL, Tampa, FL.
ILS OR LOC RWY 19L, AMDT 40D...
S-LOC 19L: NA EXCEPT FOR AIRCRAFT EQUIPPED WITH SUITABLE RNAV
SYSTEM WITH GPS.
COSME (TP) LOM OUT OF SERVICE.
1905131808-2105131808EST
1/24/191613Z !FDC 9/6642 TPA IAP TAMPA INTL, Tampa, FL.
LOC RWY 1R, AMDT 4...
MISSED APPROACH: CLIMB TO 500 THEN CLIMBING RIGHT TURN TO 2000
DIRECT LAL VORTAC AND HOLD.
COSME (TP) LOM OUT OF SERVICE.
1901241613-2101241606EST
Yes
ALL
HILLSBOROUGH CO AVN AUTHORITY
PO BOX 22287
TAMPA, FL 33622
Phone: 813-870-8700
JOHN TILIACOS
PO BOX 22287
TAMPA, FL 33622
Phone: 813-870-8700
SAINT PETERSBURG FSS (PIE)
Toll Free: 1-800-WX-BRIEF
TPA
Sunset to Sunrise
--
Clear-Green
Yes - Lighted
No
No
Hanger, Tie-Down
Landing Rights Airport
Airport of Entry
9
7
57
6
0
0
Major
Major
High & Low Pressure
High & Low Pressure
Avionics
Cargo Handling
Charter Service

Runway 01L/19R

11002 ft. x 150 ft.
CONC
Good
GRVD
HIGH
85 /R/B/W/T
60000 lbs
210000 lbs
358000 lbs
850000 lbs
  Runway 01L Runway 19R
Runway Heading 182°
Traffic Pattern Left Left
Markings PIR PIR
Markings Condition GOOD GOOD
Latitude 27° 57' 48"N 27° 59' 37"N
Longitude 82° 32' 32"W 82° 32' 29"W
Elevation 10.7 ft. 21 ft.
Threshold Crossing Height 71 ft. AGL 71 ft. AGL
Visual Glide Path Angle
Visual Slope Indicator P4L P4L
Approach Lights ALSF2 MALSR
Centerline Lights Yes Yes
Runway End Identifier Lights No No

Runway 01R/19L

8300 ft. x 150 ft.
ASPH CONC
Good
GRVD
HIGH
76 /R/B/W/T
60000 lbs
210000 lbs
358000 lbs
850000 lbs
  Runway 01R Runway 19L
Runway Heading 182°
Traffic Pattern Left Left
Markings PIR PIR
Markings Condition GOOD GOOD
Latitude 27° 57' 52"N 27° 59' 14"N
Longitude 82° 31' 44"W 82° 31' 42"W
Elevation 17.7 ft. 26 ft.
Threshold Crossing Height 71 ft. AGL 61 ft. AGL
Visual Glide Path Angle
Visual Slope Indicator P4L P4L
Approach Lights ALSF2
Centerline Lights Yes Yes
Runway End Identifier Lights Yes No

Runway 10/28

6999 ft. x 150 ft.
ASPH CONC
Fair
GRVD
HIGH
61 /F/A/W/T
75000 lbs
200000 lbs
280000 lbs
380000 lbs
  Runway 10 Runway 28
Runway Heading 92° 272°
Traffic Pattern Left Left
Markings NPI NPI
Markings Condition GOOD GOOD
Latitude 27° 58' 15"N 27° 58' 13"N
Longitude 82° 32' 10"W 82° 30' 52"W
Elevation 14.5 ft. 26.4 ft.
Threshold Crossing Height 42 ft. AGL 50 ft. AGL
Visual Glide Path Angle
Visual Slope Indicator P4L P4L
Approach Lights
Centerline Lights
Runway End Identifier Lights No No
A110-2RY 19L IS NOISE SENSITIVE TO TURBOJET DEPARTURES. RY 01R IS NOISE SENSITIVE TO TURBOJET ARRIVALS. PUBLISHED NOISE ABATEMENT PROCEDURES IN EFFECT.
A110-3ONLY ACFT WITH PRIOR PERMISSION MAY USE TERMINAL APRON; ALL OTHERS USE GA APRON.
A110-4BIRD ACTIVITY ON AND IN VCNTY OF ARPT.
A110-7TWY RSTRS: AIRPLANE DESIGN GRP V OR LGR - TWY N WEST OF TWY L UNAVBL. TWY E NORTH OF TWY J ALSO UNUSBL FOR WINGSPAN GREATER THAN 171 FT UNLESS PPR FROM ARPT OPS.
A110-8TAXILANE F AND TAXILANE R ARE NON-MOVEMENT AREAS. BOTH LCTNS ARE UNAVBL FOR GROUP IV ACFT WITH A WINGSPAN GTR THAN 117 FT WO PPR FROM ARPT OPS. TAXILANE T PPR FROM ARPT OPS RQRD FOR ACFT WITH A WINGSPAN GTR THAN 90 FT.

View hangar and property listings at KTPA, provided by our partner Hangar Network.

No Hangar Network listings are currently available for this airport.

TAMPA INTL (ICAO: KTPA, IATA: TPA) is a public airport located in TAMPA, FL.
