iFlightPlanner



...
KERN VALLEY - Airport Diagram
LiveATC.net: Live Air Traffic - From Their Headsets to You

L05
KERN VALLEY
PublicPUB

3 miles S of KERNVILLE, CA
View on Map
LiveATC.net: Live Air Traffic - From Their Headsets to You
Operational
35° 43' 42"N 118° 25' 11"W
2614' MSL
3614' MSL
14E
None Listed
RANCHO MURIETA (RIU)
LOS ANGELES
LOS ANGELES (ZLA)
11/27/25-12/25/25
KTSP (35nm) VFR
10:35 PM PST
Clear
10sm
30°F
21°F
30.25"Hg
120° 4kts
AO2
METAR KTSP 050635Z AUTO 12004KT 10SM CLR M01/M06 A3025 RMK AO2
+ Add Your Business

L05 FBOs

No FBOs (Fixed Base Operators) are listed for this airport.
X

Send Message to Airport Company
Enter your information and message below.

Your Information

Processing
122.8 122.8

No communication frequencies available for this airport.

FAA A/FD Pages

Airport Diagrams

  • No Documents

Airport Minimums

  • No Documents

Departure Procedures

  • No Documents

Hotspot

  • No Documents

Standard Term. Arrival

  • No Documents

Instrument Approach

  • No Documents

Terminal Area Forecast

KBFL (36nm)
Thu, 12/4 9:27 PM PST
Thu, 12/4 10:00 PM PST - Fri, 12/5 10:00 PM PST
MVFR
Temporary 10:00 PM PST - 2:00 AM PST
Broken 1,000'
N/A
Calm
MVFR
10:00 PM PST - 3:00 AM PST
Mist
Sky Clear
3sm
VRB° 5kts
IFR
3:00 AM PST - 10:00 AM PST
Mist
Broken 1,500'
2sm
VRB° 5kts
LIFR
Temporary 4:00 AM PST - 8:00 AM PST
Fog
Broken 300'
0.25sm
Calm
MVFR
10:00 AM PST - 10:00 PM PST
Mist
Scattered 25,000'
4sm
VRB° 5kts
TAF KBFL 050527Z 0506/0606 VRB05KT 3SM BR SKC
   TEMPO 0506/0510 BKN010
   FM051100 VRB05KT 2SM BR BKN015
   TEMPO 0512/0516 1/4SM FG BKN003
   FM051800 VRB05KT 4SM BR SCT250
L05
EffectiveExpiresCategoryNOTAM
Domestic
12/2/25
1627Z
4/1/26
1627Z
!RIU 12/015 L05 OBST TOWER LGT (ASR 1036459) 354220.60N1183334.40W (6.9NM W L05) 7163.7FT (170.9FT AGL) U/S 2512021627-2604011627
No
DALGT
COUNTY OF KERN DEPT OF AIRPORTS
3701 WINGS WAY, SUITE 300
BAKERSFIELD, CA 93308-7026
Phone: 661-391-1800
ERIC GRANT
3701 WINGS WAY, SUITE 300
BAKERSFIELD, CA 93308-7026
Phone: 661-391-1824
RANCHO MURIETA FSS (RIU)
Toll Free: 1-800-WX-BRIEF
RIU
--
--
N/A
Yes
Yes
No
Tie-Down
NOT a Landing Rights Airport
NOT an Airport of Entry
Minor
Minor
None
None
Pilot Instruction
Aircraft Rental

Runway 17/35

3500 ft. x 50 ft.
ASPH
Good
NONE


--
--
--
--
  Runway 17 Runway 35
True Heading 185°5°
Traffic Pattern Right Left
Markings BSC BSC
Markings Condition GOOD GOOD
Latitude 35° 43' 59"N 35° 43' 24"N
Longitude 118° 25' 09"W 118° 25' 13"W
Elevation -- --
Threshold Crossing Height -- --
Visual Glide Path Angle -- --
Visual Slope Indicator -- --
Approach Lights
Centerline Lights No No
Runway End Identifier Lights No No
A110-1<NO NIGHT OPERATIONS.
A110-3FLY-IN CAMPGROUND ON ARPT.
A110-4FOR CD CTC JOSHUA APCH AT 661-277-3843.
KERN VALLEY (IATA: L05) is a public airport located in KERNVILLE, CA.
