ALAMO LANDING FLD - Airport Diagram
LiveATC.net: Live Air Traffic - From Their Headsets to You

L92
Local L92
ALAMO LANDING FLD
PublicPUB

2 miles W of ALAMO, NV, US
View on Map
LiveATC.net: Live Air Traffic - From Their Headsets to You
Status
Operational
Coordinates
37° 21' 48"N 115° 11' 44"W
Elevation
3757' MSL
Pattern Alt
4757' MSL
Mag Variation
11°E
Declination
14°E
Fuel
None Listed
FSS
RENO (RNO)
Sectional
LAS VEGAS
ARTCC
LOS ANGELES (ZLA)
Data Effective
3/19/26-4/16/26
KDRA (60nm) VFR
4:53 PM PDT
Clear
10sm
75°F
2°F
30.12"Hg
040° 5kts
AO2 SLP169 T02391167 10244 20189 56022
METAR KDRA 042353Z AUTO 04005KT 10SM CLR 24/M17 A3012 RMK AO2 SLP169 T02391167 10244 20189 56022
+ Add Your Business

L92 FBOs

No FBOs (Fixed Base Operators) are listed for this airport.
X

Send Message to Airport Company
Enter your information and message below.

Your Information

Processing

Common

CTAF 122.9
ACTVT REIL RWY 14 & 32; PAPI RWY 14 & 32; HIRL RWY 14/32; TWY LGTS - CTAF.

FAA A/FD Pages

Terminal Area Forecast

KVGT (69nm)
Sat, 4/4 4:20 PM PDT
Sat, 4/4 5:00 PM PDT - Sun, 4/5 5:00 PM PDT
VFR
5:00 PM PDT - 8:00 PM PDT
Few 25,000'
6sm
040° 8kts
VFR
8:00 PM PDT - 10:00 AM PDT
Scattered 25,000'
6sm
330° 7kts
VFR
10:00 AM PDT - 4:00 PM PDT
Scattered 25,000'
6sm
070° 8kts
VFR
4:00 PM PDT - 5:00 PM PDT
Broken 25,000'
Few 12,000'
6sm
110° 7kts
TAF KVGT 042320Z 0500/0524 04008KT P6SM FEW250
   FM050300 33007KT P6SM SCT250
   FM051700 07008KT P6SM SCT250
   FM052300 11007KT P6SM FEW120 BKN250
L92
No NOTAM Available
No
UNATNDD
LINCOLN COUNTY
PO BOX 90 181 N. MAIN ST
PIOCHE, NV 89043
Phone: 702-449-2418
WENDY RUDDER
P.O. BOX 509
ALAMO, NV 89001
Phone: (702) 449-2418
RENO FSS (RNO)
Toll Free: 1-800-WX-BRIEF
RNO
--
ACTVT REIL RWY 14 & 32; PAPI RWY 14 & 32; HIRL RWY 14/32; TWY LGTS - CTAF.
N/A
Yes
Yes
No
Buoy
No
None
None
None
None
None

Runway 14/32

4362 ft. x 60 ft.
ASPH
Good
NONE
HIGH

12,000lbs
--
--
--
  Runway 14 Runway 32
True Heading 148°328°
Traffic Pattern Right
Markings NPI NPI
Markings Condition GOOD GOOD
Latitude 37° 22' 07"N 37° 21' 30"N
Longitude 115° 11' 58"W 115° 11' 30"W
Elevation 3,757' 3,709'
Threshold Crossing Height 41 ft. AGL 40 ft. AGL
Visual Glide Path Angle 3.25° 2.75°
Visual Slope Indicator P2L P2L
Approach Lights
Centerline Lights
Runway End Identifier Lights Yes Yes
A11LEASED TO LINCOLN COUNTY FROM US BUREAU OF LAND MANAGEMENT
A110-1FOR CD CTC NELLIS APP AT 702-652-4172.
A43-14UNUSBL BYD 4 NM.
A81-APTACTVT REIL RWY 14 & 32; PAPI RWY 14 & 32; HIRL RWY 14/32; TWY LGTS - CTAF.
E111E111: VFR USE.
ALAMO LANDING FLD (IATA: L92) is a public airport located in ALAMO, NV, US.
