SCAMMON BAY - Airport Diagram
LiveATC.net: Live Air Traffic - From Their Headsets to You

PACM
SCAMMON BAY
PublicPUB

0 miles N of SCAMMON BAY, AK
View on Map
LiveATC.net: Live Air Traffic - From Their Headsets to You
Operational
61° 50' 40"N 165° 34' 25"W
22' MSL
1022' MSL
12E
None Listed
KENAI (ENA)
BETHEL
ANCHORAGE (ZAN)
4/18/24-5/16/24
PACZ (14nm) VFR
4:55 PM AKDT
Clear
10sm
38°F
25°F
29.89"Hg
050° 13kts
Gusts 26kts
AO2 PK WND 08026/0021 SLP129 T00311038
PACZ 010055Z AUTO 05013G26KT 10SM CLR 03/M04 A2989 RMK AO2 PK WND 08026/0021 SLP129 T00311038
List Your Business

PACM FBOs, Flight Schools and Ground Support

No FBOs, flight schools or aircraft ground support businesses are listed for this airport.

PACM Ground Transportation (Taxi, Limo, Car Service)

No ground transportation services are listed for this airport.

PACM Hotels

No hotels are listed for this airport.

PACM Restaurants

No restaurants are listed for this airport.

PACM Other Airport-Related Businesses

No other airport-related businesses are listed for this airport.
X

Send Message to Airport Company
Enter your information and message below.

Your Information

Processing
123.0 123.0

AWOS-3P

AWOS-3P
907-558-5501
 118.425

FAA A/FD Pages

Airport Diagrams

  • No Documents

Airport Minimums

Departure Procedures

  • No Documents

Hotspot

  • No Documents

Standard Term. Arrival

  • No Documents

Instrument Approach

Terminal Area Forecast

No TAF is available for this location.
PACM
Domestic
4/30/242017Z !SCM 04/006 SCM RWY 10/28 REDL U/S 2404302017-2410302111EST
3/29/242006Z !SCM 03/002 SCM SVC AUTOMATED WX BCST SYSTEM NOT AVBL 2403292006-2405251500EST
FDC
3/14/241337Z !FDC 4/7197 SCM ODP SCAMMON BAY, SCAMMON BAY, AK.
TAKEOFF MINIMUMS AND (OBSTACLE) DEPARTURE PROCEDURES AMDT 2...
TAKEOFF MINIMUMS RWY 10: 1000-3 WITH MINIMUM CLIMB OF 440 FT PER NM TO 1300 OR STANDARD WITH MINIMUM CLIMB OF 602 FT PER NM TO 1300 OR 2200-3 FOR VCOA.
DEPARTURE PROCEDURE RWY 10: CLIMB ON HEADING 101 TO 2100 BEFORE PROCEEDING ON COURSE.
ALL OTHER DATA REMAINS AS PUBLISHED.
2403141337-2603131337EST
10/18/231115Z !FDC 3/7446 SCM IAP SCAMMON BAY, SCAMMON BAY, AK.
RNAV (GPS) RWY 10, ORIG...
LNAV MDA NA. CONST EQUIP 22 MSL 1500FT SE OF RWY 28 (2016-AAL-7-NRA).
2310181115-2405291115EST
10/18/231115Z !FDC 3/7445 SCM IAP SCAMMON BAY, SCAMMON BAY, AK.
RNAV (GPS) RWY 28, AMDT 1A...
LP MDA NA. LNAV MDA NA. CONST EQUIP 22 MSL 1500FT NW OF RWY 28 (2016-AAL-7-NRA).
2310181115-2405291115EST
No
UNATNDD
ALASKA DOT&PF CENTRAL REGION
PO BOX 196900
ANCHORAGE, AK 99519-6900
Phone: (907) 269-0749
JOSEPH LARAUX
PO BOX 505
BETHEL, AK 99559
Phone: (907) 543-2498
KENAI FSS (ENA)
Toll Free: 1-866-864-1737
SCM
--
ACTVT MIRL RWY 10/28 - CTAF.
ACTVT ROTG BCN - CTAF.
N/A
Yes - Lighted
Yes
No
None
NOT a Landing Rights Airport
NOT an Airport of Entry
0
0
0
0
0
0
None
None
None
None
None

Runway 10/28

3001 ft. x 75 ft.
DIRT
Good
NONE
MED

--
--
--
--
  Runway 10 Runway 28
True Heading 113°293°
Traffic Pattern Left Right
Markings NSTD NSTD
Markings Condition
Latitude 61° 50' 46"N 61° 50' 34"N
Longitude 165° 34' 54"W 165° 33' 57"W
Elevation 12' 18'
Threshold Crossing Height -- --
Visual Glide Path Angle -- --
Visual Slope Indicator -- --
Approach Lights
Centerline Lights
Runway End Identifier Lights No
A110-1RWY CONDITION NOT MONITORED; RECOMMEND VISUAL INSPECTION PRIOR TO USING.
A110-2BIRDS ON RWY.
A110-4WX CAMERA AVBL ON INTERNET AT HTTPS://WEATHERCAMS.FAA.GOV/.
A110-7BE ALERT: GUSTY CROSSWINDS COMMON.
A110-8RWY EDGES SOFT AND SLOUGHING TOWARDS TUNDRA.
A110-9COLD TEMPERATURE AIRPORT. ALTITUDE CORRECTION REQUIRED AT OR BELOW -21C.
SCAMMON BAY (ICAO: PACM, IATA: SCM) is a public airport located in SCAMMON BAY, AK.
