EIELSON AFB - Airport Diagram
LiveATC.net: Live Air Traffic - From Their Headsets to You

PAEI
EIELSON AFB
PrivatePVT

17 miles SE of FAIRBANKS, AK
View on Map
LiveATC.net: Live Air Traffic - From Their Headsets to You
Operational
64° 39' 56"N 147° 06' 05"W
548' MSL
1548' MSL
19E
None Listed
FAIRBANKS (FAI)
FAIRBANKS
ANCHORAGE (ZAN)
4/18/24-5/16/24
PAEI VFR
8:56 PM AKDT
Broken 6,500'
10sm
48°F
30°F
29.92"Hg
180° 3kts
AO2A SLP139 T00911011 $
PAEI 010456Z 18003KT 10SM BKN065 09/M01 A2992 RMK AO2A SLP139 T00911011 $
List Your Business

PAEI FBOs, Flight Schools and Ground Support

No FBOs, flight schools or aircraft ground support businesses are listed for this airport.

PAEI Ground Transportation (Taxi, Limo, Car Service)

No ground transportation services are listed for this airport.

PAEI Hotels

No hotels are listed for this airport.

PAEI Restaurants

No restaurants are listed for this airport.

PAEI Other Airport-Related Businesses

No other airport-related businesses are listed for this airport.
X

Send Message to Airport Company
Enter your information and message below.

Your Information

Processing
-- --

ATIS

ATIS
Hours: 1600-0800Z++
 119.9

Ground

GND/P
 121.8

Tower

LCL/P
 127.2

Other

OPS
SOURDOUGH
 139.6
PTD
 139.3
RANGE CTL
SUAIS RADIO
 125.3
SFA
 118.6

Terminal Area Forecast

PAEI
Tue, 4/30 1:45 PM AKDT
Tue, 4/30 2:00 PM AKDT - Wed, 5/1 8:00 PM AKDT
VFR
2:00 PM AKDT - 11:00 PM AKDT
Overcast 22,000'
Broken 15,000'
Broken 6,000'
6sm
29.91"Hg
330° 9kts
Light, In Cloud (Rime): 6,000-10,000'
MVFR
Becoming 11:00 PM AKDT - 11:00 AM AKDT
Light Showers and Rain
Overcast 6,000'
Broken 4,000'
Scattered 2,000'
4.97sm
30.00"Hg
VRB° 6kts
Light (Mixed): 4,000-7,000'
Light, In Cloud (Rime): 7,000-10,000'
IFR
Temporary 3:00 AM AKDT - 9:00 AM AKDT
Light Rain and Snow and Mist
Overcast 4,000'
Broken 2,000'
Scattered 1,000'
1.99sm
Calm
Light (Mixed): 2,000-5,000'
Light, In Cloud (Rime): 5,000-9,000'
VFR
Becoming 11:00 AM AKDT - 8:00 PM AKDT
Showers in vicinity
Overcast 10,000'
Broken 4,000'
Few 2,000'
6sm
30.03"Hg
020° 9kts
Light, In Cloud (Rime): 4,000-9,000'
TAF PAEI 302145Z 3022/0204 33009KT 9999 BKN060 BKN150 OVC220 620604 QNH2992INS
   BECMG 0107/0108 VRB06KT 8000 -SHRA SCT020 BKN040 OVC060 610403 620703 QNH3000INS
   TEMPO 0111/0117 3200 -RASN BR SCT010 BKN020 OVC040 610203 620504
   BECMG 0119/0120 02009KT 9999 VCSH FEW020 BKN040 OVC100 620405 QNH3002INS TX14/0102Z TN01/0114Z
PAEI
Military
5/6/240000Z !PAEI V0390/24 EIL AERODROME IFR TAKE-OFF MINIMUMS AND (OBSTACLE) DEPARTURE PROCEDURES AMENDMENT RWY 14: TREES 3606 FT FROM DER 1378 FT LEFT OF CENTERLINE, 85 FT AGL/654 FT MSL; RWY 32: DRILL 1605 FT FROM DER 296 FT RIGHT OF CENTERLINE, 583 FT MSL TREES 1633 FT FROM DER 666 FT RIGHT OF CENTERLINE, 85 FT AGL/639 FT MSL TREES 394 FT FROM DER 364 FT LEFT OF CENTERLINE, 85 FT AGL/636 FT MSL TREES 3576 FT FROM DER 1425 FT LEFT OF CENTERLINE, 85 FT AGL/634 FT MSL 13 GS ANT 849 FT FROM DER 515 FT LEFT OF CENTERLINE, 57 FT AGL/594 FT MSL DRILL 1609 FT FROM DER 299 FT RIGHT OF CENTERLINE, 583 FT MSL DRILL 1724 FT FROM DER 711 FT RIGHT OF CENTERLINE, 583 FT MSL DRILL 1605 FT FROM DER 296 FT RIGHT OF CENTERLINE, 583 FT MSL DRILL 1722 FT FROM DER 708 FT RIGHT OF CENTERLINE, 583 FT MSL 2405060000-2408042359
5/6/240000Z !PAEI V0389/24 EIL AERODROME INSTRUMENT APPROACH PROCEDURE LIMITED TACAN RWY 14 MINIMA WITH LAST SDP CAT AB 950/55 423 (500-1), CAT CDE 960-1 1/4 423 (500-1 1/4); RWY 14 HELICOPTER VISIBILITY REDUCTION BELOW RVR 4000 NOT AUTHORIZED; VDP NOT AUTHORIZED. 2405060000-2408042359
5/6/240000Z !PAEI V0388/24 EIL AERODROME INSTRUMENT APPROACH PROCEDURE LIMITED RNAV (GPS) RWY 14 LNAV MINIMA: CAT AB 1000/55 463 (500-1), CAT CDE 1000-1 3/8 465 (500-1 3/8); RWY 14 HELICOPTER VISIBILITY REDUCTION BELOW RVR 4000 NOT AUTHORIZED; VDP AT 1.3 NM. 2405060000-2408042359
5/6/240000Z !PAEI V0387/24 EIL AERODROME INSTRUMENT APPROACH PROCEDURE LIMITED ILS OR LOC/DME RWY 14 ILS NOT AUTHORIZED, LOCALIZER ONLY AUTHORIZED WITH FOLLOWING LIMITATIONS: MINIMA S-LOC CAT AB 1000/55 463 (500-1), CAT CDE 1000-1 3/8 465 (500-1 3/8); RWY 14 HELICOPTER VISIBILITY REDUCTINON BELOW RVR 4000 NOT AUTHORIZED; VDP AT 2.9 NM. 2405060000-2408042359
4/30/241903Z M0615/24 NOTAMC M0610/24
4/30/241902Z M0614/24 NOTAMC M0611/24
4/30/241739Z LCL SORTIES OR DEPLOYING TO, OR OUT OF EIELSON AFB MUST HAVE MAINT PRSNL REQ TO CMPLT OPS; INCLG DE-ICE PSNL DURING COLD WX. DEPLOYED ACFT TRANS ALERT SUPPORT NA BYD INITIAL BLOCK IN
4/30/241734Z M0613/24 NOTAMC M0612/24
4/30/241733Z L0014/24 NOTAMC L0013/24
4/30/241340Z TWY F O4-E --TAXIWAY LIGHT DAMAGED AND WIRES EXPOSED. USE CAUTION WHEN IN AREA
4/30/241340Z TWY K SOUTH SIDE OF WEATHER SHELTER 2 -- TAXIWAY LIGHT DAMAGED AND EXPOSING WIRES. USE CAUTION IN AREA.
4/30/241339Z RWY 14/32 EDGE LIGHTS UNSERVICEABLE DUE TO EXCEEDING ALLOWABLE OUTAGES.
4/30/241053Z M0606/24 NOTAMC M0604/24
4/30/240720Z M0605/24 NOTAMC M0603/24
4/29/241324Z M0601/24 NOTAMC M0600/24
4/27/242339Z FLEET & LAV SERVICES UNAVAILABLE
4/27/242339Z AERODROME FIRE BOTTLES AND POWER EQUIPMENT LIMITED.
4/27/242338Z BUILDING 1300 SOUTHERN MOST OBSTRUCTION LIGHTS OTS
4/25/242150Z EFFECTIVE 01 MAY - 20 MAY, AIRSTAIRS WILL BE USED FOR COMMERCIAL TRAFFIC ONLY DUE TO HEAVY COMMERCIAL INBOUNDS AND OUTBOUNDS
4/25/241908Z 01 MAY - 03 MAY 2024: R-2205 A/F WILL BE ACTIVE WITH GROUND DEMOLITIONS ACTIVITIES VICINITY OF MANCHU RANGE, MOOSE CREEK RANGE COMPLEX FROM 0900 - 1800L (1700 - 0200Z). ALL NON-APPROVED AIRCRAFT WILL REMAIN CLEAR.
4/25/241907Z ** 29 APR - 02 MAY 2024: R-2205 B/G WILL BE ACTIVE WITH UAV/UAS ACTIVITIES 29 APR 2024 FROM 1500 - 2300L (2300 - 0700Z); 30 APR - 02 MAY 2024 FROM 0800 - 2300L (1600 - 0700Z). ALL NON-APPROVED AIRCRAFT WILL REMAIN CLEAR
4/25/241906Z 01 MAY - 03 MAY 2024: R-2205 B WILL BE ACTIVE WITH UAV/UAS ACTIVITIES VICINITY OF ISBC (ROZ:  4 CORNER BOX​ - UL: N 6441.27 W 14649.47​ (06W WS 08116 74040); ​LL: N 6440.59 W 14649.53​ (06W WS 08035 73173); ​LR: N 6440.58 W 14649.10​ (06W WS 08607 73123); ​UR: N 6441.27 W 14649.06​ (06W WS 08655 74017)), MAXIMUM ALTITUDE 1000FT AGL, FROM 0800 - 1600L (1600 - 0000Z). ALL NON-APPROVED AIRCRAFT WILL REMAIN CLEAR.
4/25/241904Z 29 APR - 03 MAY 2024: R-2205 C/H WILL BE ACTIVE WITH AERIA BOMBING/STRAFING ACTIVITIES ASSOCIATED WITH RED FLAG VICINITY OF STUART CREEK IMPACT AREA FROM VUL 1: 0800 - 0930L (1600 - 1730Z); VUL 2: 1000 - 1400L (1800 - 2200Z); VUL 3: 1400 - 1600L (2200 - 0000Z); VUL 4: 1600 - 2000L (0000 - 0400Z). ALL NON-APPROVED AIRCRAFT WILL REMAIN CLEAR.
4/25/241410Z ARFF REDUCED LEVEL OF SERVICE (YELLOW) FOR A-10, F-15, F-16, F-22, F-35, C-12, C-21, CV-22, U-2, C-20, C-22, C-32, C-37, C-40, C-130, AC-130, E-3, E-8, B-1, B-2, B-52, C-17, KC-46 (767), KC-135 (707), E-4 (747), KC-10 (DC-10), VC-25 (747) AND LIKE AIRCRAFT.SEE AP1 FOR REDUCED LEVEL OF SERVICE INFORMATION. CONTACT CEF (CHIEF 2 FOR FURTHER ARFF INFO AT DSN 377-2613/COMM: 907-377-2613. CONTACT AMOPS FOR ASSISTANCE DSN 377-1861 OR COMMERCIAL 907-377-1861.
4/25/241409Z ARFF CRITICAL LEVEL OF SERVICE (RED) FOR C-5, 747-8I AND LIKE AIRCRAFT. SEE AP1 FOR OPTIMUM LEVEL OF SERVICE INFORMATION.CONTACT CEF (CHIEF 2 FOR FURTHER ARFF INFO AT DSN 377-2613/COMM:907-377-2613. CONTACT AMOPS FOR ASSISTANCE DSN 377-1861 OR COMMERCIAL 907-377-1861.
4/17/242316Z EIELSON AFB IS IN BASH PHASE 2 FROM 16 APR - 31 MAY
4/14/240033Z TWY F (TWY A - TANKER ROW 10) IS RESTRICTED TO ACFT WITH A WINGSPAN OF 160FT OR LESS. AIRCRAFT WITH A WINGSPAN OF 161-198FT MUST USE EASTERN MOST CENTERLINE.
4/12/240035Z PAXON LOW MOA AND DELTA MOA COMPLEX INCLUDES DELTA 1, 2, 3, 4, & 5 AS CHARTED. TIMES OF USE: 22 - 26 APR AND 29 APR - 3 MAY, 1030 - 1300 LOCAL (UTC-8DT): 22 - 26 APR AND 29 APR - 2 MAY, 1630 - 1900 LOCAL (UTC-8DT). CONTROLLING AGENCY: FAA, ANCHORAGE ARTCC. USING AGENCY: USAF, 354 FIGHTER WING, EIELSON AFB, AK. NOTICE: IFR TRAFFIC MAY BE RE-ROUTED SOUTH OF THE FOX 3, PAXON AND TOK ATCAA AIRSPACE BORDERS. ACTUAL TIMES OF USE WITHIN THIS WINDOW MAY VARY. CONTACT EIELSON RANGE CONTROL AT 800-758-8723 OR VHF 125.3 OR 126.3, A FLIGHT SERVICE STATION OR ANCHORAGE ARTCC FOR ACTUAL ACTIVATION TIMES.
4/1/241041Z !PAEI M0461/24 EIL TWY E HLDG PSN SIGN FOR ILS NORTH SIDE NOT LGTD 2404011041-2405312359
3/28/241723Z 2 SET OF AIRSTAIRS AVAILABLE AND WILL GO TO PRIORITY AIRCRAFT.
3/28/240517Z TANKER ROW PARKING SPOT 3 (PAPA/QUEBEC ROW SPOTS 8-10) CLOSED
3/28/240517Z OBST **DANGER** EXERCISE CAUTION AROUND TWY F(O4-E) DUE TO MISSING MANHOLE COVER LOCATED ON THE WESTSIDE OF THE TAXIWAY TRAFFIC CONES IN VICINITY**
3/26/241732Z TWY G (NORTH AND SOUTH) PARKING SPOTS CLOSED. EAST AND WEST TAXIING STILL AVAILABLE FOR FIGHTER ACFT ONLY
3/25/240851Z TWY A,C & E WIND CONES & CORRESPONDING OBSTRUCTION LIGHTS UNLIT.
3/23/240310Z RWY 14/32 DISTANCE MARKER (RDM) NORTHEAST SIDE AT 6000FT (RWY14) 8000FT (RWY32) NOT ILLUMINATED
3/22/241031Z BUILDING 1121 OBSTRUCTION LIGHTS UNLIT
3/4/240706Z EIELSON AFB CANNOT SUPPORT B-52 OPERATIONS DUE TO PARKING RESTRICTIONS AND LACK OF EQUIPMENT.
3/4/240705Z AERODROME TAC AZIMUTH UNUSABLE R108 CW R118 AT 4300' BEYOND 38.5 NM.
3/4/240703Z TWY K SPOTS 5-7 CLSD DUE TO PAVEMENT DAMAGE.
Yes
1600-0800Z++
U S GOVT USAF
5010 CSGP
EIELSON AFB, AK 99702
CHIEF AIRFIELD MANAGEMENT
343 CSG/OTM
EIELSON AFB, AK 99702
Phone: 907-377-3201
FAIRBANKS FSS (FAI)
Toll Free: 1-866-248-6516
PAEI
--
--
N/A
Yes
No
No
Hangar
NOT a Landing Rights Airport
NOT an Airport of Entry
0
0
0
0
0
0
None
None
None
None
None

Runway 14/32

14530 ft. x 150 ft.

CONC
GRVD
HIGH
61 /R/C/W/T
--
--
--
--
  Runway 14 Runway 32
True Heading 159°339°
Traffic Pattern Right Left
Markings PIR PIR
Markings Condition GOOD GOOD
Latitude 64° 41' 03"N 64° 38' 49"N
Longitude 147° 07' 05"W 147° 05' 06"W
Elevation 534' 548'
Threshold Crossing Height 54 ft. AGL 44 ft. AGL
Visual Glide Path Angle 2.7° 2.7°
Visual Slope Indicator P4L P4L
Approach Lights ALSF1 ALSF1
Centerline Lights No No
Runway End Identifier Lights No No
A110-1TRANS ALERT SVC AVBL H24.
A110-11PACAF FTR ARR EXP RDCD RWY SEP; SIMILAR TYPE/DAY - 3000 FT; DISSIMILAR TYPE, NGT, WET RWY, BHND FRMN OR RCR LESS THAN 17 - 6000 FT; FTR LDG BHND NON FTR - 9000 FT; RCR VALIDATED AS COND WARRANT.
A110-16EXTSV FUEL DELAYS DURG RED FLAG ALASKA EXER APR-OCT.
A110-20AIR TERM & GND HANDLING SVC 1630-0030Z++ WKDAY; PPR OR EXP DELAY - AFLD MGMT.
A110-21ALASKA ANG 168TH AREFS OPS - D317-377-8800/C907-377-8800. ANG OPS H24 - D317-377-1861/3201.
A110-3CRYPTO MTRL TSNT CREW NOT AVBL. VIP 30 MIN PPR WITH CHOCK TIME - AFLD MGMT. LTD FLEET SVC. NO POTABLE WATER.
A110-30PPR 5 DAYS - 24 HR PRIOR TO ARR - ARFLD MGMT D317-377-1861/C907-377-1861. PPR GOOD +/- 30 MIN ARR TIME; COORD PPR AFT TIME BY FONE OR PPR CNLD. EXP ARR TIME RSTRN EXC AIR EVAC & DV CODE 7 & UP.
A110-31BIRD WATCH COND MOD LCL PAT LTD TO MIN RQR WITH OG/CC APVL; TGL, FORMATION TKOF/LNDG NA; LOW APCH LTD TO 300 FT AGL. BIRD WATCH COND SVR; TKOF, PAT & LNDG NA EXC EMERG.
A110-32MOOSE ON & INVOF RWY.
A110-33N & S BARRIER RUNOUT REDUCED TO 950 FT.
A110-38PTNS OF APRON O ROW & S RAMP NOT VIS FROM TWR.
A110-40CONTINGENCY OPS - AMGR.
A110-41TRAN ALERT: TSNT MAINT LTD TO F16 SVCG UPON AIRCREW REQ. F16 THRU FLIGHT/BPO/PREFLIGHT INSP NA.
A110-45H24 OPS; OFFL BUS ONLY. QUIET HR 0800-1500Z; UNCTLD TKOF/LDG NA; EXCEPTIONS RQR OG/CC APVL.
A110-46RADIO/NAV/WX RMRKS - (F) 1500-0700Z ++ DAILY.
A110-48PAEW ON RWY WHEN TWR UNMANNED.
A110-49MAINT OPS CNTR PPR 48 HR FM ETA - D317-377-1205. UHF PREF PAT FREQ.
A110-5OVHD TFC PAT ALT 2000 FT MSL; RECTANGULAR TFC PAT ALT 1500 FT MSL.
A110-50PRIME KNGHT NOT AVBL.
A110-52FAIRBANKS FSS - 474-0137. FLT ADZY OR RSTRD & MIL OPRG AREA STATUS - EIELSON RANGE CTL SUAIS RADIO 125.3 OR 1-800-758-8723.
A110-53SEE AP1 SUP RMKS: BASE OPS COMSEC RESPONSIBILITY NA; LTD SECRET & COMSEC STORAGE AVBL. TOP SECRET & COMSEC INFO - COMMAND POST D317-377-1500.
A110-6AVOID SMALL ARMS RANGE 2.5 NM E OF RWY 32 END; WKEND 1700-0100Z++; SFC - 3500 FT AGL.
A110-60CTN: NSTD LGT; 2000 FT RWY EDGE LGT BTN D - C TWY; 12 FT FM RWY EDGE.
A110-65CTN: FIRE HYDRANTS 64 FT NE OF TWY H CNTLN.
A110-66LOAD/OFF LOAD ENG RUN NA. ERO SVC AVBL FOR AMC ACFT.
A110-67VHF PTD FREQ UNMNT.
A110-69LOOP TWY E OF CORROSION HANGAR 1348 THRU 4/8 BAY AREA RSTRD TO WINGSPAN 45 FT OR LESS.
A110-7CARGO & ACR CTC COMMAND POST 3 HR PRIOR & 30 MIN PROIR TO LNDG.
A110-72RWY 14/32 BAK-12 DEP END CABLES IN RAISED POSITION; BAK-12 AER 14/32 AVBL WITH 20 MIN PRIOR NOTICE. NORTH BARRIER RUNOUT REDUCED TO 950 FT, HOOK EQUIPPPED ACFT BE ALERT.
A110-73DE-ICE TYPE 1 AVBL, ANTI-ICE TYPE 4 UNAVBL.
A110-76FICON & RWY COND CODE NOT RPRTD.
A110-77ARFF STATUS CRITICAL LVL OF SVC (CLS) 62% FOR USAF CAT 10; REDUCED LVL OF SVC (RLS) 81% FOR USAF CAT 9.
A110-78TSNT CTC PTD AT LEAST 30 MIN PRIOR TO ARR. EIELSON AFB IS A 1 MOG STATION.
A110-79NO PALLET TRAINS LONGER THAN T3 WITH OVERHANG WILL BE ACPTD DUE TO 25K LOADER SUPPORT.
A110-8BASH PHASE II APR, MAY, AUG & SEP. GULLS, DUCKS & GEESE POSE HAZARD WHEN STANDING WATER ON FLD. RPT BIRD & ANIMAL STRIKES INVOF ARPT TO AFLD MGMT - D317-377-186, PTD OR 354 FW/SE D317-377-4110.
A110-80WX SVC H24 EXC AFLD/TWR CLOSURE - D377-1160/3140/C907-377-1160/3140; AN/FMQ-19 AUTOMATED OBS SYS AUGMENTED BY HUMAN OBSN. FMQ19 907-377-5846.
A110-81TSNT CTC 15 OWS DURG AFLD CLOSURE FOR WX BRIEFING - D576-9755/C618-256-9755; IF PSBL 3 HR PN.
A110-82ATTENDED CONTINUOUSLY. OBO 0800-1600Z.
A110-9FILE FLT PLAN 2 HR BFR DEP. ARR RQR CUSTOMS 1.5 HR PPR - COMMAND POST. U.S. IMMIGRATION SVC NOT AVBL.
EIELSON AFB (ICAO: PAEI, IATA: EIL) is a private airport located in FAIRBANKS, AK.
