| FDC |
|
4/21/231828Z
|
!FDC 3/5804 T11 PART 1 OF 2 ODP YAP INTL, YAP ISLAND, .
TAKEOFF MINIMUMS AND (OBSTACLE) DEPARTURE PROCEDURES AMDT 2...
TAKEOFF OBSTACLE NOTES: RWY 7: TREES BEGINNING 16 FT FROM DER, 286
FT LEFT OF CENTERLINE, UP TO 107 FT MSL.
TREES BEGINNING 102 FT FROM DER, 263 FT RIGHT OF CENTERLINE, UP TO
51 FT AGL/122 FT MSL.
TREES, FENCE BEGINNING 135 FT FROM DER, 281 FT LEFT OF CENTERLINE,
UP TO 24 FT AGL/109 FT MSL.
TREES BEGINNING 320 FT FROM DER, 343 FT LEFT OF CENTERLINE, UP TO
112 FT MSL.
TREES BEGINNING 415 FT FROM DER, 310 FT LEFT OF CENTERLINE, UP TO
26 FT AGL/124 FT MSL.
TREE 749 FT FROM DER, 521 FT LEFT OF CENTERLINE, 139 FT MSL.
TREE 1142 FT FROM DER, 478 FT RIGHT OF CENTERLINE, 147 FT MSL.
TREE 1310 FT FROM DER, 536 FT RIGHT OF CENTERLINE, 60 FT AGL/181 FT
MSL.
TREE 1571 FT FROM DER, 748 FT RIGHT OF CENTERLINE, 59 FT AGL/188 FT
MSL.
TREES, BUILDINGS BEGINNING 1630 FT FROM DER, 624 FT RIGHT OF
CENTERLINE, UP TO 195 FT MSL. RWY 25: POLE 9 FT FROM DER, 53 FT
LEFT OF CENTERLINE, 1 FT AGL/92 FT MSL.
MSL. 2304211828-2504211828EST
END PART 1 OF 2
!FDC 3/5804 T11 PART 2 OF 2 ODP YAP INTL, YAP ISLAND, .
TERRAIN, FENCES BEGINNING 47 FT FROM DER, 398 FT RIGHT OF
CENTERLINE, UP TO 129 FT MSL.
TREE 411 FT FROM DER, 422 FT LEFT OF CENTERLINE, 37 FT AGL/108 FT
MSL.
TREE 493 FT FROM DER, 370 FT RIGHT OF CENTERLINE, 37 FT AGL/150 FT
MSL.
POLE 927 FT FROM DER, 745 FT RIGHT OF CENTERLINE, 177 FT MSL.
TREE 1475 FT FROM DER, 89 FT LEFT OF CENTERLINE, 49 FT AGL/151 FT
MSL. 2304211828-2504211828EST
END PART 2 OF 2
|
