S90
Local S90
ELK CITY
PublicPUB

0 miles SW of ELK CITY, ID, US
View on Map
LiveATC.net: Live Air Traffic - From Their Headsets to You
Status
Operational
Coordinates
45° 49' 22"N 115° 26' 23"W
Elevation
4097' MSL
Pattern Alt
5097' MSL
Mag Variation
13°E
Declination
18°E
Fuel
None Listed
FSS
BOISE (BOI)
Sectional
GREAT FALLS
ARTCC
SEATTLE (ZSE)
Data Effective
6/11/26-7/9/26
KP69 (20nm) VFR
5:52 PM PDT
No Clouds
N/A
77°F
61°F
29.70"Hg
Calm
AO1 SLP039 T02500161
METAR KP69 260052Z AUTO 00000KT 25/16 A2970 RMK AO1 SLP039 T02500161
+ Add Your Business

S90 FBOs

No FBOs (Fixed Base Operators) are listed for this airport.
X

Send Message to Airport Company
Enter your information and message below.

Your Information

Processing

Common

CTAF 122.9

FAA A/FD Pages

Terminal Area Forecast

KHRF (61nm)
Thu, 6/25 5:20 PM MDT
Thu, 6/25 6:00 PM MDT - Fri, 6/26 6:00 PM MDT
VFR
6:00 PM MDT - 10:00 PM MDT
Showers in vicinity
Broken 11,000'
6sm
360° 9kts
VFR
10:00 PM MDT - 11:00 AM MDT
Showers in vicinity
Overcast 10,000'
6sm
360° 5kts
VFR
12:00 AM MDT - 5:00 AM MDT
Light Showers and Rain
Broken 7,000'
N/A
310° 6kts
VFR
11:00 AM MDT - 6:00 PM MDT
Light Showers and Rain
Broken 7,000'
6sm
160° 6kts
TAF KHRF 252320Z 2600/2624 36009KT P6SM VCSH BKN110
   FM260400 36005KT P6SM VCSH OVC100
   PROB30 2606/2611 31006KT -SHRA BKN070
   FM261700 16006KT P6SM -SHRA BKN070
S90
No NOTAM Available
No
UNATNDD
ELK CITY AREA ALLIANCE
GEN DELIVERY
ELK CITY, ID 83525
Phone: 208-842-2311
DEBBIE TAYLOR
PO BOX 345
ELK CITY, ID 83525
Phone: (208) 842-2494
BOISE FSS (BOI)
Toll Free: 1-800-WX-BRIEF
BOI
--
--
N/A
Yes
No
No
Tie-Down
No
Minor
Minor
None
None
None

Runway 14/35

2600 ft. x 150 ft.
TURF
Fair
NONE


--
--
--
--
  Runway 14 Runway 35
True Heading Not ListedNot Listed
Traffic Pattern Left Left
Markings
Markings Condition
Latitude N/A N/A
Longitude N/A N/A
Elevation -- --
Threshold Crossing Height -- --
Visual Glide Path Angle -- --
Visual Slope Indicator -- --
Approach Lights
Centerline Lights
Runway End Identifier Lights
A110-1LAND RY 14 TKOF RY 35 WHEN WIND CONDITIONS ALLOW.
A110-2RWY NOT MAINTAINED IN THE WINTER.
A110-4RWY 14 & 35 IS NOT MARKED & NO THLD DEFINED. RWY IS CURVED TO THE NW; NO LINE OF SITE FM ONE RWY END TO THE OTHER.
A110-5FOR CD CTC SEATTLE ARTCC AT 253-351-3694.
A110-6NMRS TREES OVR 60 FT AND HOUSES OVR 20 FT TALL ON APCH.
A30-14/35IS A CURVED RWY.
A52-35ADDNL OBSTNS: +100' RIDGE AT 1200'; ON CNTRLN +35' RIDGE AT 500' ON CNTRLN; 250'TREES & TERRAIN AT 2500' ON CNTRLN.
A57-14CTLG OBST EXCEEDS 45 DEG SLP.
ELK CITY (IATA: S90) is a public airport located in ELK CITY, ID, US.
