BENJAMIN RIVERA NORIEGA - Airport Diagram
LiveATC.net: Live Air Traffic - From Their Headsets to You

TJCP
ICAO TJCPIATA CPXLocal CPX
BENJAMIN RIVERA NORIEGA
PublicPUB

1 miles N of ISLA DE CULEBRA, PR, Puerto Rico
View on Map
LiveATC.net: Live Air Traffic - From Their Headsets to You
Status
Operational
Coordinates
18° 18' 47"N 65° 18' 14"W
Elevation
43' MSL
Pattern Alt
1043' MSL
Mag Variation
14°W
Declination
11°W
Fuel
None Listed
FSS
SAN JUAN (SJU)
Sectional
PUERTO RICO-VIRGIN ISLANDS
ARTCC
SAN JUAN (ZSU)
Data Effective
2/19/26-3/19/26
TIST (19nm) VFR
10:53 AM AST
Scattered 3,000'
10sm
85°F
70°F
30.06"Hg
080° 15kts
Gusts 25kts
AO2 SLP180 T02940211 51009 $
METAR TIST 151453Z 08015G25KT 10SM SCT030 29/21 A3006 RMK AO2 SLP180 T02940211 51009 $
+ Add Your Business

TJCP FBOs

No FBOs (Fixed Base Operators) are listed for this airport.
X

Send Message to Airport Company
Enter your information and message below.

Your Information

Processing

Common

CTAF 122.9

FAA A/FD Pages

Terminal Area Forecast

TIST (19nm)
Sun, 3/15 7:33 AM AST
Sun, 3/15 8:00 AM AST - Mon, 3/16 8:00 AM AST
VFR
8:00 AM AST - 9:00 AM AST
Scattered 4,000'
Few 3,000'
6sm
090° 11kts
VFR
9:00 AM AST - 7:00 PM AST
Showers in vicinity
Scattered 5,000'
Few 3,000'
6sm
100° 18kts
Gusts 28kts
VFR
7:00 PM AST - 8:00 AM AST
Scattered 5,000'
6sm
090° 14kts
TAF TIST 151133Z 1512/1612 09011KT P6SM FEW030 SCT040
   FM151300 10018G28KT P6SM VCSH FEW030 SCT050
   FM152300 09014KT P6SM SCT050
TJCP
No NOTAM Available
No
SR-SS
PUERTO RICO PORTS AUTHORITY
GPO BOX 362829
SAN JUAN, PR 00936
Phone: (787) 729-8715
JORGE SANTIAGO
PO BOX 1303
CEIBA, PR 00735
Phone: 787-742-0022
SAN JUAN FSS (SJU)
Toll Free: 1-800-WX-BRIEF
TJSJ
Sunset to Sunrise
--
N/A
RTG BCN OTS INDEF.
Yes - Lighted
No
Yes
None
Landing Rights Airport
NOT an Airport of Entry
None
None
None
None
Charter Service

Runway 13/31

2596 ft. x 60 ft.
ASPH
Poor
NONE
MED

12,000lbs
--
--
--
  Runway 13 Runway 31
True Heading 121°301°
Traffic Pattern Left Left
Markings BSC BSC
Markings Condition FAIR FAIR
Latitude 18° 18' 53"N 18° 18' 40"N
Longitude 65° 18' 25"W 65° 18' 02"W
Elevation 43' 7'
Threshold Crossing Height -- --
Visual Glide Path Angle -- --
Visual Slope Indicator -- --
Approach Lights
Centerline Lights
Runway End Identifier Lights
A110-1LOW ALT MANEUVERING REQUIRED FOR FINAL ALIGNMENT TO RWY. VARIABLE DEGS OF TURBULENCE MAY BE EXPECTED.
A110-10LDG FEE FOR ALL ACFT.
A110-13600 FT AGL ANT 1/2 MILE EAST OF ARPT.
A110-14RWY 13, 480 FT HILL, 12/ MILE FROM RWY END.
A110-15RAPIDLY RISING TERRAIN NW.
A110-16FOR CD CTC SAN JUAN CERAP AT 787-253-8664/8665
A110-5ACFT DEPARTING ARPT NORTHBOUND BE ALERT FOR TRAFFIC DESCENDING ON FINAL FOR CHARLOTTE AMALIE ST THOMAS, CYRIL E KING (STT).
A110-6BIRDS ON & INVOF RWY
A110-8UNATNDD SS-SR. EMERGS ONLY. OPNS BETWEEN SS-SR WILL BE AN OWN RISK.
A33-13/31_CONDRWY/TXY PVMT CRACKING, LOOSE STONES.
A40-13/31RWY 13/31 MIRL-SEVERAL LTS OTS INDEF.
A57-13ALSO 30 FT. TREE, 436 FT. DSTC, 0 FT. B.
A58-316 FT FENCE, 0-200 FT DSTC, 90-150 FT R/L; 15 ROAD, 0-200 FT DSTC, 100-150 FT R/L.
A80RTG BCN OTS INDEF.
E111VFR WX ONLY. MIN TRAFFIC PTN 1000' AGL. NO NGT OPNS. LND RWY 13 ONLY (EXCP FOR ADVERSE WX CONDS) APCH FM NW THRU BAHIA FLAMENCO ON HEADING OF 172 DEG. FLY THRU LAGUNA DEL FLAMENCO UNTIL APROX PARALLEL TO HIWAY IN PASS ALTER HEADING TO 153 DEG; LEFT TURN TO FINAL APCH RWY 13.
BENJAMIN RIVERA NORIEGA (ICAO: TJCP, IATA: CPX) is a public airport located in ISLA DE CULEBRA, PR, Puerto Rico.
