AIR HARBOR
PublicPUB

6 miles N of GREENSBORO, NC, US
View on Map
LiveATC.net: Live Air Traffic - From Their Headsets to You
Status
Operational
Coordinates
36° 10' 25"N 79° 48' 11"W
Elevation
822' MSL
Pattern Alt
1822' MSL
Mag Variation
9°W
Declination
6°W
Fuel
100LL
FSS
RALEIGH (RDU)
Sectional
CINCINNATI
ARTCC
WASHINGTON (ZDC)
Data Effective
10/1/26-10/29/26
KGSO (8nm) VFR
10:54 PM EDT
Broken 25,000'
10sm
71°F
65°F
30.08"Hg
210° 4kts
AO2 SLP174 T02170183 51009 $
METAR KGSO 030254Z 21004KT 10SM BKN250 22/18 A3008 RMK AO2 SLP174 T02170183 51009 $
+ Add Your Business

W88 FBOs

Promote Listing
Murphy Aviation
UNICOM: 122.8
Phone: (336) 288-4275
No Rating Available
0 Reviews (Read | Sign In To Write)
Phillips 66
As of 9/25
 100LL JET A JET A (FSII) MOGAS UL94
Self Serve 6.35
Full Serve
Fuel Notes
Prices include tax
X

Send Message to Airport Company
Enter your information and message below.

Your Information

Processing

Common

CTAF 122.8
UNICOM 122.8

FAA A/FD Pages

Terminal Area Forecast

KGSO (8nm)
Fri, 10/2 7:20 PM EDT
Fri, 10/2 8:00 PM EDT - Sat, 10/3 8:00 PM EDT
VFR
8:00 PM EDT - 8:00 AM EDT
Broken 25,000'
Scattered 15,000'
Few 5,000'
6sm
240° 4kts
IFR
Temporary 8:00 AM EDT - 11:00 AM EDT
Broken 700'
N/A
Calm
MVFR
8:00 AM EDT - 2:00 PM EDT
Broken 1,500'
Scattered 700'
6sm
050° 9kts
Gusts 16kts
MVFR
2:00 PM EDT - 8:00 PM EDT
Broken 1,500'
6sm
050° 9kts
MVFR
3:00 PM EDT - 7:00 PM EDT
Light Rain
Broken 2,000'
6sm
Calm
TAF KGSO 022320Z 0300/0324 24004KT P6SM FEW050 SCT150 BKN250
   FM031200 05009G16KT P6SM SCT007 BKN015
   TEMPO 0312/0315 BKN007
   FM031800 05009KT P6SM BKN015
   PROB30 0319/0323 6SM -RA BKN020
W88
EffectiveExpiresCategoryNOTAM
Domestic
10/2/26
2210Z
12/2/26
2359Z
!RDU 10/045 W88 OBST TOWER LGT (ASR 1031381) 361450.00N0793909.00W (8.6NM ENE W88) 1016.7FT (259.8FT AGL) U/S 2610022210-2612022359
10/1/26
1203Z
12/30/26
1303Z
!RDU 10/004 W88 OBST TOWER LGT (ASR 1001690) 361316.50N0794146.10W (6.0NM ENE W88) 1096.1FT (309.1FT AGL) U/S 2610011203-2612301303
9/27/26
2343Z
1/25/27
2343Z
!RDU 09/392 W88 OBST TOWER LGT (ASR 1004739) 361312.00N0794831.00W (2.8NM N W88) 1234.9FT (415.0FT AGL) U/S 2609272343-2701252343
9/22/26
0930Z
11/6/26
0930Z
!RDU 09/328 W88 OBST TOWER LGT (ASR 1322193) 360650.39N0794232.86W (5.7NM SE W88) 977FT (230FT AGL) U/S 2609220930-2611060930
9/6/26
1542Z
12/5/26
2359Z
!RDU 09/093 W88 OBST TOWER LGT (ASR 1024877) 360701.00N0794203.00W (5.9NM SE W88) 976.0FT (255.9FT AGL) U/S 2609061542-2612052359
9/4/26
2216Z
12/3/26
2316Z
!RDU 09/048 W88 OBST TOWER LGT (ASR 1005949) 360511.30N0794341.90W (6.3NM SE W88) 1057.7FT (239.8FT AGL) U/S 2609042216-2612032316
8/29/26
1525Z
11/27/26
1625Z
!RDU 08/398 W88 OBST TOWER LGT (ASR 1006347) 360509.00N0794537.90W (5.6NM SSE W88) 1321.2FT (555.1FT AGL) U/S 2608291525-2611271625
8/15/26
2000Z
12/31/26
2359Z
!RDU 08/190 W88 AD AP CLSD EXC PPR 336-558-4459 2608152000-2612312359
7/28/26
2248Z
10/26/26
2248Z
!RDU 07/464 W88 OBST TOWER LGT (ASR 1005963) 361653.30N0793807.50W (10.5NM NE W88) 1065.0FT (319.9FT AGL) U/S 2607282248-2610262248
No
1200-DUSK
AFT HRS EMERG CALL 336-669-5462.
GUILFORD LAKE AVIATION
150 AIR HARBOR RD22
GREENSBORO, NC 27459
Phone: 336-288-4275
RON MURPHY
150 AIR HARBOR ROAD
GREENSBORO, NC 27459
Phone: 336-669-5462
RALEIGH FSS (RDU)
Toll Free: 1-800-WX-BRIEF
RDU
Sunset to Sunrise
--
N/A
Yes
No
No
Hanger, Tie-Down
NOT a Landing Rights Airport
NOT an Airport of Entry
Major
Major
None
None
Pilot Instruction
Aircraft Rental

Runway 09/27

2460 ft. x 65 ft.
ASPH TURF
Fair
NONE
NSTD

--
--
--
--
  Runway 09 Runway 27
True Heading Not ListedNot Listed
Traffic Pattern Left Left
Markings NSTD
Markings Condition POOR
Latitude N/A N/A
Longitude N/A N/A
Elevation -- --
Threshold Crossing Height -- --
Visual Glide Path Angle -- --
Visual Slope Indicator -- --
Approach Lights
Centerline Lights
Runway End Identifier Lights
A110-2RWY 09 LNDG UPHILL.
A110-3RWY 09 HAS +60 FT DROP-OFF 220 FT FM THR.
A110-4RWY 27 HAS 8 FT DROP-OFF 10 FT FM THR; LEFT & RIGHT.
A110-5GRVL ACES ROAD 60 FT FROM RWY 27 END.
A110-6DEER ON & INVOF ARPT.
A110-7ACFT HNGR ACES IMDT ADJNT TO RWY; PARKED PLANES LEFT SIDE OF RWY 27.
A110-8FOR CD CTC GREENSBORO APCH AT 743-222-6129.
A17-M1AFT HRS EMERG CALL 336-669-5462.
A32-09/27N 25 FT WID IS ASPH. S 40 FT WID IS TURF.
A40-09/27NSTD MIRL; EDGE LGTS VARY FROM 60-75 FEET FROM PAVEMENT S SIDE; 8 FT FM PAVEMENT N SIDE; NGT LNDGS HAVE NO INDICATION OF PVMT LCTN.
A42-09_CONDRWY NRS FADED. RWY 09/27 MKD WITH YELLOW CONES INDICATING RWY WID UP TO 100 FT.
A42-09_MARKDUE TO RWY WID.
A58-2751 FT TREES 123 FT FM THR OFFSET 10-92 FT RIGHT OF CNTRLN AND 37 FT TREES 107 FT FR THR OFFSET 62 FT LEFT OF CNTRLN.
A70-100LLFUEL AVBL 24 HR CREDIT CARD SVC.
E111EXISTED PRIOR TO FAA ACT.
AIR HARBOR (IATA: W88) is a public airport located in GREENSBORO, NC, US.
