PBEAAYE - Airport Diagram
LiveATC.net: Live Air Traffic - From Their Headsets to You

Y30
Local Y30
PBEAAYE
PublicPUB

3 miles NE of TOPINABEE, MI, US
View on Map
LiveATC.net: Live Air Traffic - From Their Headsets to You
Status
Operational
Coordinates
45° 31' 52"N 84° 33' 25"W
Elevation
690' MSL
Pattern Alt
1690' MSL
Mag Variation
7°W
Declination
6°W
Fuel
None Listed
FSS
LANSING (LAN)
Sectional
LAKE HURON
ARTCC
MINNEAPOLIS (ZMP)
Data Effective
2/19/26-3/19/26
KSLH (7nm) LIFR
10:15 AM EDT
Light Snow and Mist
Overcast 600'
0.75sm
28°F
25°F
30.00"Hg
080° 16kts
Gusts 27kts
AO2 PK WND 09027/04 PRESFR
METAR KSLH 151415Z AUTO 08016G27KT 3/4SM -SN BR OVC006 M02/M04 A3000 RMK AO2 PK WND 09027/04 PRESFR
+ Add Your Business

Y30 FBOs

No FBOs (Fixed Base Operators) are listed for this airport.
X

Send Message to Airport Company
Enter your information and message below.

Your Information

Processing

Common

CTAF 122.9

FAA A/FD Pages

Terminal Area Forecast

KPLN (10nm)
Sun, 3/15 9:14 AM EDT
Sun, 3/15 9:00 AM EDT - Mon, 3/16 8:00 AM EDT
LIFR
Temporary 9:00 AM EDT - 12:00 PM EDT
Heavy Snow and Blowing Snow
Broken 900'
0.25sm
Calm
IFR
9:00 AM EDT - 4:00 PM EDT
Light Snow and Mist
Broken 1,500'
1sm
100° 13kts
Gusts 22kts
LIFR
4:00 PM EDT - 11:00 PM EDT
Snow and Ice Pellets and Blowing Snow
Broken 800'
0.5sm
080° 18kts
Gusts 35kts
LIFR
11:00 PM EDT - 3:00 AM EDT
Light Ice Pellets and Snow and Blowing Snow and Mist
Overcast 900'
0.75sm
040° 19kts
Gusts 33kts
IFR
3:00 AM EDT - 5:00 AM EDT
Light Freezing Rain and Ice Pellets and Mist
Broken 900'
1.5sm
030° 16kts
Gusts 28kts
IFR
5:00 AM EDT - 8:00 AM EDT
Light Freezing Rain and Snow and Ice Pellets and Mist
Broken 700'
2sm
020° 14kts
Gusts 26kts
TAF KPLN 151314Z 1513/1612 10013G22KT 1SM -SN BR BKN015
   TEMPO 1513/1516 1/4SM +SN BLSN BKN009
   FM152000 08018G35KT 1/2SM SNPL BLSN BKN008
   FM160300 04019G33KT 3/4SM -PLSN BLSN BR OVC009
   FM160700 03016G28KT 1 1/2SM -FZRAPL BR BKN009
   FM160900 02014G26KT 2SM -FZRASNPL BR BKN007
Y30
No NOTAM Available
No
UNATNDD
PEABEAAYE INC
3299 TRYBAN RD
CHEBOYGAN, MI 49721
Phone: 231-268-8750
CRAIG PASSENO
3299 TRYBAN RD
CHEBOYGAN, MI 49721
Phone: 231-268-8750
LANSING FSS (LAN)
Toll Free: 1-800-WX-BRIEF
LAN
--
--
N/A
Yes
No
No
Tie-Down
No
None
None
None
None
None

Runway 01/19

2470 ft. x 90 ft.
TURF
Fair
NONE


--
--
--
--
  Runway 01 Runway 19
True Heading Not ListedNot Listed
Traffic Pattern
Markings
Markings Condition
Latitude N/A N/A
Longitude N/A N/A
Elevation -- --
Threshold Crossing Height -- --
Visual Glide Path Angle -- --
Visual Slope Indicator -- --
Approach Lights
Centerline Lights
Runway End Identifier Lights
A110-1TREES ALL QUADRANTS.
A110-2DEER & BIRDS INVOF ARPT.
A110-3WINTER OPNS SKIS ONLY. NO SNOW REMOVAL.
A110-4+60 FT WINDSOCK LCTD AT N END.
A110-5FOR CD CTC MINNEAPOLIS ARTCC AT 651-463-5588.
A33-01/19_CONDRWY SFC ROUGH; UNEVEN TRRN.
A42-01_MARK01/19 DSPLCD THLDS MKD WITH CONES.
A57-01APCH RATIO 0:1 TO DTHR OVR 60 FT TREES, 60 FT L/R.
A57-19APCH RATIO 0:1 TO DTHR OVR 60 FT TREES, 55 FT L/R.
A75-TROPES NOT PRVDD. TIEDOWN FEES APPLY CK WITH MGMT.
E111PRVDD OBSTNS IN APCH SFC ARE RMVD/LWRD TO PRVD 20:1 CLNC FM RWY END OR THRS LCTD/MKD TO PRVD 10:1 CLNC OVR OBSTNS.
PBEAAYE (IATA: Y30) is a public airport located in TOPINABEE, MI, US.
